Summary of Contents for GAUSSIAN ROBOTICS Phantas S1

  • Page 1 Maintenance Guide Phantas S1 Technical support & operation center...
  • Page 2: Table Of Contents

    Content 01-Clean the Exterior 05-Clean/Replace Side Brush 09-Clean/Replace Rubber Strips 02-Clean Dust Tank 06-Clean/Replace Roller Brush Assembly 03-Clean Wastewate 07-Clean/Replace Dust Collector 04-Clean/Replace Air Filter 08-Clean Squeegee...
  • Page 3: 01-Clean The Exterior

    01-Clean the Exterior Phantas S1 3.Clean 1.Switch to Manual Mode 2.Push manually Use wet, lint-free wipe to clean the Click [a]Manual Mode, [b]Push, Push it to the place for maintenance. exterior. [c]Confirm the switch Notice: Don’t wipe the sensors.
  • Page 4 01-Clean the Exterior Phantas S1 4.Use dry and lint-free wipe to 5.Clean the lens of laser on anti- 6.Wipe the screen and top lid. smoothly clean lidar, cameras and collision shell and PSD-side tracking sensors. sensor. Notice: Use dry and lint-free cloth to smoothly wipe the sensing components...
  • Page 5: 02-Clean Dust Tank

    02-Clean Dust Tank Phantas S1 1.切换为推行模式 1.Switch to Manual Mode 2.Push manually 3.Press “OPEN”to open the top 点击右侧“手自动切换图标”,调出 Click [a]Manual Mode, [b]Push, lid. Push it to the place for maintenance. 切换手动模式界面,选择“推行”之 [c]Confirm the switch 后点击“确认切换”;...
  • Page 6 02-Clean Dust Tank Phantas S1 5. Remove the top cover of dust 4.Take out the dust tank 6.Pull the sealing strip out and tank and take out dust bag . Remove all assemblies from the empty the trash. Notice: lift the white sheet up to dust tank.
  • Page 7: 03-Clean Wastewate

    03-Clean Wastewater Phantas S1 1.Switch to Manual Mode 2.Push manually 3.Press “OPEN”to open the top Click [a]Manual Mode, [b]Push, lid. Push it to the place for maintenance. [c]Confirm the switch...
  • Page 8 03-Clean Wastewater Phantas S1 6.Pour out wastewater 4.Remove the wastewater tank 5.Clean the filter Dump the wastewater into the Remove all assemblies from the Open the cover of the wastewater sewer or cleaning pool, rinse the wastewater tank. tank, remove the filter from it, and...
  • Page 9: 04-Clean/Replace Air Filter

    04-Clean/Replace Air Filter Phantas S1 2.Press the button from left to right 1.Open the lid to find the air filter. 3.Take out the filter, clean it or to open the filter shell. replce with a new one.
  • Page 10: 05-Clean/Replace Side Brush

    05-Clean/Replace Side Brush Phantas S1 1.Open the side window 2.Grab the rubber boot and pull 3.Clean side brush with wipes or down to remove the side brush. replace it. Align the magnetic catch and push Do not hold the bristles.
  • Page 11: 06-Clean/Replace Roller Brush Assembly

    06-Clean/Replace Roller Brush Assembly Phantas S1 1.Open the side window. 2.Press the button and take the 3.Take front and rear brush off the roller brush assembly out. assembly and clean them with steel wire bristle brush or replace them.
  • Page 12: 07-Clean/Replace Dust Collector

    07-Clean/Replace Dust Collector Phantas S1 1.Open the side window. 2.Press the button and take the 3.Empty and clean or replace it. dust collector out.
  • Page 13: 08-Clean Squeegee

    08-Clean Squeegee Phantas S1 1.Use wet wipes to clean the 2.Clean the gap between the inner 3.Use wet wipes to clean the surface of inner and outer strips. and outer strips. exterior.
  • Page 14: 09-Clean/Replace Rubber Strips

    09-Clean/Replace Rubber Strips Phantas S1 1.Switch to manual mode 2.Push it to the place for 3.Open the side protection skirt Click [a]Manual Mode, [b]Push, maintenance. first, press down and remove the [c]Confirm the switch shell of squeegee then move the lid...
  • Page 15 09-Clean/Replace Rubber Strips Phantas S1 5.For install, insert the inner strip(the shorter 4.Press the silver button on 6.Install the shell back. one) first. squeegee to pull the 2 rubber Push the shell upward and cover Press and hold the silver button and insert strips out.
  • Page 16 Questions? www.smartservant.nl/ helpdesk...
