- Page 1 Maintenance Manual Vacuum 40 Technical Service and Operation & Maintenance Center Keep Exploring Keep Innovating...
-
Page 2: Revision Record
Gaussian Robot Maintenance Manual Gaussian is the only commercial company on service robot in the cleaning industry which has received ISO9001 international certification, China Robot CR certification, UL security certification from America, and CE security certification from Europe. By far, Gaussian has provided over 2000 customers from 40 countries and regions globally with cleaning services over 200 million kilometers, as among the most outstanding enterprises in the marketability of commercial mobile robot and unmanned equipment. - Page 3 Contents Appearance cleaning Air filter replacement Dust push cloth cleaning Dust bag replacement Dust box and deflector cleaning Roller brush replacement Roller brush cleaning Side brush replacement Side brush cleaning Dust push cloth replacement Charging pile appearance cleaning...
- Page 4 Maintenance Manual-Appearance cleaning Vacuum 40 [Switch machine mode to manual] [Push the machine to maintenance [Scrub Appearance] Click floating button in point] Use non-shedding wet cloth to scrub bottom right corner choose the machine appearance (do not manual operation. scrub the camera and the sensor).
- Page 5 Maintenance Manual-Appearance cleaning Vacuum 40 [Scrub the exterior sensor] [Scrub the horizontal view laser] [Scrub the top view camera and screen] Use non-shedding clean soft cloth to scrub the laser, camera, and sensor gently. Use non-shedding clean soft cloth to scrub the top view camera gently.
- Page 6 Maintenance Manual-Dust push cloth cleaning Vacuum 40 [Switch machine mode to manual] [Push the machine to maintenance [Remove the dust push plate] point] Click the floating button in the bottom right corner Open the rear shell of the machine and remove and choose manual operation.
- Page 7 Maintenance Manual-Dust push cloth cleaning Vacuum 40 [Dust push cloth washing] [Install new dust push cloth] Wash the dust push cloth in the barrel and dry it. Fetch new dust push cloth and mount it on the dust push plate. Mount the dust push plate on the machine, and the dust push cloth cleaning is complete.
- Page 8 Maintenance Manual-Dust box and deflector Vacuum 40 cleaning [Switch machine mode to manual] [Push the machine to maintenance [Open the side buckle and pull out point] the bottom shell] Click the floating button in the bottom right corner and choose manual operation.
- Page 9 Maintenance Manual-Dust box and deflector Vacuum 40 cleaning [Dust box] Insert the clean dust box, close the bottom shell, and buckle it up.
- Page 10 Maintenance Manual-Roller brush cleaning Vacuum 40 [Open the side buckle and pull out [Remove the roller brush] [Clean the roller brush] the bottom shell] Unscrew the roller brush bolt, and then the roller Clean the roller brush plug and remove the hair brush cover plate will pop up.
- Page 11 Maintenance Manual-Side brush cleaning Vacuum 40 [Remove the side brush] [Clean the side brush] Push the machine to maintenance point, and Remove the hair on the side brush with hand, and remove it by pressing down the side brush with then align it to the locating pin.
- Page 12 Maintenance Manual-Charging pile appearance Vacuum 40 cleaning [Push the machine away from the [Scrub the charging pile] charging pile] Pull out the plug of the charging pile, and scrub the appearance with wrung wet towel. Do not scrub Switch the machine to manual mode, and push the the charging electrode.
- Page 13 Maintenance Manual-Air filter replacement Vacuum 40 [Push the machine to maintenance [Open the head cover and the dust [Mount the air filter back] point] box cover] After cleaning the removed air filter, mount it back. Do follow the arrow indication on the air filter, and Switch the machine to manual and push it to the Open the head cover and the dust box cover.
- Page 14 Maintenance Manual-Dust bag replacement Vacuum 40 [Push the machine to maintenance [Open the head cover and the dust [Mount back the filter bag] point] box cover] After cleaning the removed dust bag, mount it back, and put on the dust box cover and head Switch the machine to manual and push it to the Open the head cover and the dust box cover.
- Page 15 Maintenance Manual-Roller brush replacement Vacuum 40 [Open the side buckle and pull out [Remove the roller brush] [Replace the roller brush] the bottom shell] Unscrew the roller brush bolt, and then the roller Take out the new brush with the dented end facing brush cover plate will pop up.
- Page 16 Maintenance Manual-Side brush replacement Vacuum 40 [Remove the side brush] [Replace the side brush] Push the machine to maintenance point, and Take out the new side brush and align it to the remove it by pressing down the side brush with locating pin.
- Page 17 Maintenance Manual-Dust push cloth Vacuum 40 replacement [Push the machine to maintenance [Remove the dust push plate] [Install new dust push cloth] point] Open the rear shell of the machine and remove Take out the new dust push cloth and mount it on the dust push plate and dust push cloth.
- Page 18 Attachment-periodic table of consumable Vacuum 40 replacement Power Consumption High Consumption Scenario Medium Consumption Scenario Low Consumption Scenario Scenario Level Description ●Work 3-4H on wearproof cement, waterstone, and other mildly ●Epoxy floor level, PVC, and other plastic ground cleaned by dust ●Work 4-6H every day for supermarket, logistics, etc.
- Page 19 Attachment- maintenance spot checklist Vacuum 40 GS40 Robot-daily cleaning spot checklist Equipment Responsible Spot Check Year GS40 Robot Operator User MM, 2022 Name Person and Month Spot Check Spot Check Item Spot Check Date Cycle Part Content Daily Power contact is normal...
- Page 20 Let service robots serve every corner of the world Keep Exploring Keep Innovating Technical Service and Operation & Maintenance Center 400-888-3065...
