Detailed Drawing/Spare Parts Overview - Storch ProCut Translation Of The Original Instruction

11. Detailed drawing/Spare parts overview

8
13
2
9
13
Item Code no. Designation
Repair kit frame clamp
5 57 05 76
fastener
Repair kit ball bearing slide,
11 57 05 77
upper
Repair kit ball bearing
12 57 05 78
slide, bottom
4 57 05 79 Repair kit transformer
Repair kit deflector roll
13 57 05 81
(upper or bottom)
Repair kit cutting bow
7 57 05 82 fastening screw
(upper or bottom)
3 57 05 83 Repair kit bearing rail
Repair kit wire tensioner
8 57 05 84
including spring
Fuse transformer 10 A
for 4 57 00 04
(Set of 2 units)
Not
illus- Replacement wire (set of
57 00 48
tra- 5 units)
ted
Not
illus-
57 05 87 Repair screw set
tra-
ted
68
7
1
5
4
7 10 3
Set no.
Quantity
1 1
2 1
3 1
4 1
5 1
6 1
7 1
8 1
1
1
1
5
4
Repair kits for ProCut foam board cutter
Set 1
Translation of the original instruction
11
12
