TCL 32E320 Service Manual page 11

CMP (YPbPr)
HDMI
Headphone
Loud Speakers
.
1.5. DDC & EDID Test
It's necessary to check whether the VGA DDC and HDMI EDID have been set well.
1.6. HDCP Test
For HDCP compatibility, it's needed to check whether the HDCP key has been set well.
2. Final Assembly Alignment
2.1. How to enter "Factory Menu"
When "HotKey" is disabled, Factory Menu could be entered by the following steps :
-
Press the Remote Control key "Menu";
-
Select "Picture", press "OK" to enter the picture submenu item "Contrast";
-
Press the "9", "7", "3" and "5"."
If "HotKey" is enabled, please pop-up "Factory Menu" as the following step :
- Press Remote Control key "Return".
How to come back to "Factory Menu" root when you are into a submenu:
-
Press Remote Control "Menu" key.
How to change item value or state into "Factory Menu" or submenu:
-
Press Remote Control ">" or "<" key.
How to exit "Factory Menu",
-
Press "Menu" or "Exit" key from Remote Control.
2.2. How to enter "P" Mode
If "HotKey" is enabled, that means you have entered "P" mode.
2.3. How to enter "Warm Up" Mode
If "Warm Up" is enabled, that means you have entered "Warm Up" mode.
Pressing "keystoke" from TV set can exit "Warm Up" mode.
Note: The White Balance (color temperature) has to be performed in subdued lighted room
after at least 1 hour of warm-up/burn-in.
Factory Alignment Specification for MT23L(H)-AP/LA
Chroma/QuantumData
DVD with HDMI compliancy
RF cable
RF cable
Page 5 of 12
Half Color & Grey bars
1080i@60Hz
Half Color & Grey bars
Movie 720p@60Hz
First channel
First channel
