- Page 1 LioN-M I/O modules Technical Manual 0930 DSL 700 | 0930 DSL 701...
- Page 2 Technical Manual 0930 DSL 700 | 0930 DSL 701 LioN-M I/O modules for DeviceNet 0930 DSL 700 16 digital channels (p-switching), channels can be used universally as inputs or outputs, with rotary address switches Version 2.10 / 2007-Sept-03 Specifications subject to alteration! Page 2 of 12...
- Page 3 Technical Manual 0930 DSL 700 | 0930 DSL 701 LioN-M I/O modules for DeviceNet 0930 DSL 701 16 digital inputs (p-switching), with rotary address switches Version 2.10 / 2007-Sept-03 Specifications subject to alteration! Page 3 of 12...
-
Page 4: Table Of Contents
Technical Manual 0930 DSL 700 | 0930 DSL 701 Content About this Manual 1.1. Explanations of symbols used 1.1.1 Use of notes 1.1.2 Use of hazard notes Safety Guidelines 1.2.1 Certified usage Qualified personnel Directions for field installation Pin assignment Bus and System supply Sensor/Actuator connection (M12 female connector, 5 poles) System/Actuator connection (0930 DSL 700) -
Page 5: About This Manual
0930 DSL 700 | 0930 DSL 701 1. About this Manual Please read the assembly and operating instructions Lumberg Automation – Belden Deutschland GmbH in this Manual carefully before putting the LioN-M Im Gewerbepark 2 type module into operation. The Manual should be 58579 Schalksmühle... -
Page 6: Qualified Personnel
Technical Manual 0930 DSL 700 | 0930 DSL 701 The error-free, secure operation of the product The user has to comply with the safety and accident requires proper transport, storage, set-up and prevention regulations that apply to the specific assembly, as well as careful operation. The intended activity being performed during project planning, operation of the device can only be guaranteed installation, commissioning, maintenance and test-... -
Page 7: Pin Assignment
Technical Manual 0930 DSL 700 | 0930 DSL 701 3. Pin assignment Connection Function Connection Function 3.1 Bus and System supply (0930 DSL 700) 0930 DSL 700 0930 DSL 701 Bus and System/Sensor supply (0930 DSL 701) Drain Drain System +24 V System / +24 V... -
Page 8: Communication With The Module
Technical Manual 0930 DSL 700 | 0930 DSL 701 Communication with the module Addressing 4.1.1 Rotary address switches Two rotary switches, located above the 7/8“ bus con- nections behind a clear cover, are used for direct adjustment of the DeviceNet address (MAC_ID). The switches for setting the tens and the ones of the address are indicated. -
Page 9: Bit Assignment
Technical Manual 0930 DSL 700 | 0930 DSL 701 4.3 Bit assignment The DeviceNet telegram permits transmission of a maximum of 8 bytes (64 bits) of information data. The information data with these modules consists of two bytes input data and one byte output data. The output byte contains the control values of the individual outputs. -
Page 10: Technical Data
Technical Manual 0930 DSL 700 | 0930 DSL 701 5. Technical data 5.5 Technical data power supply – 5.1 General data Actuators (only 0930 DSL 700) Degree of protection IP 67 Rated voltage U 24 V (only in locked position) Voltage range 19–30 V DC Operating temperature range... -
Page 11: Technical Data - Outputs
Technical Manual 0930 DSL 700 | 0930 DSL 701 5.7 Technical data – Outputs Output circuit Type 1.6 A according to IEC 61131-2 Rated output current per channel: 1.6 A (please see Info 1) Signal state "1" max. 1.9 A Signal state "0"... - Page 12 Technical Manual 0930 DSL 700 | 0930 DSL 701 Lumberg Automation – Belden Deutschland GmbH Lumberg Automation Support & Service Im Gewerbepark 2 Lumberg Automation offers you comprehensive technical 58579 Schalksmühle assistance, helping you with the application of Lumberg GERMANY Automation products.
