5. Before First Use

DANGER
Ris o s ocation!
Keep any packaging materials away from children and
pets – these materials are a potential source of danger, e.g.
su ocation.
» Remove all the packing materials.
» Remove and review all components before use.
» Check the appliance for transport damages.
» Before connecting the appliance to the power supply,
check that the power supply voltage and current rating
corresponds with the power supply details shown on the
appliance rating label.

6. Accessories Function

Multi-surface brush (R)
Parquet brush (T)
Upholstery nozzle (U)
Dusting brush (V)
Crevice tool (W)

7. Assembly

NOTICE
The appliance can be used without the extension
tube (M). When the extension tube (M) is not used, attach the
accessories (R/ T/ U/ V/ W) directly to the flexible hose (P).
1. Insert the flexible house (P) into the hose intake (B) then
rotate it clockwise until securely attached (Fig. 1).
1
2
1
P
B
Mode:
»
Suitable for cleaning rugs and
low pile carpets.
Mode:
»
Suitable for cleaning tiles and
hard floors.
Suitable for cleaning wood
floors, such as parquet and
laminate floorings.
Suitable for cleaning on fabric
surfaces such as mattresses,
couches, chairs and other fabric
based pieces.
Suitable for cleaning on window
blinds, shelves and wooden
surfaces.
» Suitable for cleaning in folds,
crevices or corners.
» Suitable for hard-to-reach
areas, such as behind
furniture and between and
under car seats.
2. Insert the handle of the flexible hose (P) into the extension
tube (M) (Fig. 2). When the flexible hose (P) is inserted
correctly, there should be a click sound.
2
M
3. Push the tube unlock switch (N) while pulling out the inner
part of the extension tube (M) to adjust the length (Fig. 3).
3
N
M
4. Insert the extension tube (M) into the connector of the
accessories (R/ T/ U/ V/ W) (Fig. 4).
4
R T
EN
P
M
V U W
5
