Toshiba Satellite A55-S1063 Specifications

Satellite A55-S1063 Detailed Product Specification

Model Name Description
A55-S1063 Microsoft® Windows® XP Home, Intel® Celeron® M Processor 370, 256MB, 40GB
(5400 RPM), DVD-ROM/CD-RW, 15" XGA TruBrite™, Intel® Extreme Graphics,
802.11b/g, TV-Out, 1-year Limited Warranty
2
Operating System
• Microsoft® Windows® XP Home Edition
3
Processor and Chipset
•
Intel Celeron® M Processor 370
o [1.50GHz, 1MB L2, 400MHz FSB]
•
Intel® 852GM Chipset
4
Memory
•
Configured with 256MB SDRAM. (Both slots may be occupied)
•
256MB (Min)/1024MB (Max), 2 memory slots using 256MB,
512MB, or 1024MB PC2700 DDR 333MHz SDRAM 2.5V
SODIMM memory modules
5
Hard Disk Drive
•
40GB (5400 RPM); Enhanced IDE (ATA-6) hard disk drive;
9.5mm height; user removable
Fixed Bay Optical Disk Drive
• CD-RW/DVD-ROM drive maximum speed and compatibility:
o CD-ROM (24x:read), CD-R (24x:write), CD-RW
(24x:write), DVD-ROM (8x:read)
6
Display
• 15.0" diagonal TruBrite™ TFT active-matrix LCD display at
1024x768 native resolution (XGA)
7
Graphics
• Intel Extreme Graphics 2 with 16MB-64MB dynamically allocated
shared graphics memory
Sound
• 16-bit stereo software sound
o Supports Direct 3D Sound, DirectSound, Direct Music,
MIDI (playback)
• Sound Volume Control Dial
• Built-in stereo speakers
• SRS Labs audio enhancements
o SRS TruSurround XT® virtual surround sound
o SRS WOW™ stereo enhancement
Input Devices
• Keyboard
o 85 key US keyboard
o Hot Key Functions (Fn)
o Windows Key Function
o Application Key Function
• TouchPad™ pointing device
Communications
• Toshiba V.92 software modem
• 10/100 Base-TX Ethernet
• Atheros® 802.11b/g wireless-LAN
8
9
10
© Copyright 2005 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Satellite A55-S1063 BTS Rev. 1.00 2005-08-16 CBB T20050726 CB1.20
1
Expandability
• 2 main memory slots. Both slots may be occupied.
• 1 PC Card slot support 1 Type II, PCMCIA R2.01, PC Card16,
CardBus
Ports
• RGB (monitor) port
• TV-out (S-Video)
• 3 Universal Serial Bus (USB) ports (v2.0)
• External Microphone jack
• Headphone jack
• RJ-45 LAN port
• RJ-11 modem port

Physical Description

• Dimensions (WxDxH Front/H Rear): 13.3'' (338mm) x 11.0''
(274mm) x 1.17'' (27mm)[F]/1.46'' (38mm)[R] without feet
• Weight: Starting at 5.9lbs (2.7 kg) depending upon configuration
• Indicators: DC-In, Power, Battery, Hard Drive, CD-DVD ROM
Access, Caps Lock, Arrow Lock, Numeric Lock, Main Battery
Charging Status, Sleep Suspend Mode, Wireless
• Chassis Description
o Case material: Polycarbonate ABS
o LCD Cover Color: Hyper Silver Metallic/Premium Black
• Physical Security
o Slot for cable lock
o Items protected by a screw: Memory, hard Disk drive
o Items protected by a sliding lock: Battery pack
• Software Security
o Passwords: User power-on password, supervisor
password, hard disk drive password
o Hotkey locks: Screen Blank, Keyboard
o Screen Saver (by software)

Power Supply

•
60W (15V 4.0A) Auto sensing external AC Adapter, 100-240V /
50-60Hz frequency (Universal) input.
•
Dimensions (WxDxH): 1.95'' (49.5mm) x 4.51'' (114.5mm) x 1.14''
(29mm)
•
Weight: starting at 0.58 lbs (262g)
12
Battery
•
6-cell (4400mAh) rechargeable, removable Lithium Ion (Li-Ion)
battery pack
•
Dimensions (WxDxH): 8.15'' (207mm) x 0.78'' (20mm) x 1.78''
(45mm)
•
Weight: starting at 0.73 lbs. (330g)
•
Battery Life (measured by MobileMark™)
o Included 6-cell battery: 2 hours, 45 minutes
• Recharge Time
o Main Battery Off/On – approximately 2.5
hours/approximately 5.0 hours to 11.0 hours
BIOS
•
APM 1.2, ACPI v1.0b, PNP v1.0, VESA, DPMS, DDC, SM BIOS
v2.3, PCI BIOS v2.1 support
Part Number UPC
PSA50U-0NN02E 032017415058
13
11
