Toshiba Satellite A55-S1066 Specifications

Satellite A55-S1066 Detailed Product Specification
Model Name Description
A55-S1066 Microsoft® Windows® XP Home, Intel® Celeron® M Processor 370, 512MB, 40GB
(5400 RPM), DVD-ROM/CD-RW, 15" XGA TruBrite™, Intel® Extreme Graphics,
802.11b/g, TV-Out, 1-year Limited Warranty
2
Operating System
• Microsoft® Windows® XP Home Edition
3
Processor and Chipset
• Intel Celeron® M Processor 370
o 1.50GHz, 1MB L2, 400MHz FSB
• Chipset
o Intel 852GM Chipset
4
Memory
• Configured with 512MB DDR SDRAM (both memory slots may be
occupied)
• 512MB (Min)/1024MB (Max), 2 memory slots using 256MB, 512MB,
or 1024MB PC2700 DDR 333MHz SDRAM 2.5V SODIMM
memory modules
5
Hard Disk Drive
• 40GB (5400RPM); Enhanced IDE (ATA-6) hard disk drive; 9.5mm
height; user removable
Fixed or Slim SelectBay or Ultra SlimBay Optical Disk Drive
• CD-RW/DVD-ROM
o Maximum speed and compatibility: CD-ROM (24x:read),
CD-R (24x:write), CD-RW (24x:write), DVD-ROM
(8x:read)
7
Display
• 15" diagonal TruBrite™ TFT active-matrix LCD display at 1024x768
native resolution (XGA)
8
Graphics
• Intel Extreme Graphics 2 with 16MB-64MB dynamically allocated
shared graphics memory
Sound
• Built-in stereo speakers
• SRS Labs audio enhancements
o SRS TruSurround XT® virtual surround sound
• Sound Volume Control Dial
Input Devices
• Keyboard
o 85 key US keyboard
o Hot Key Functions (Fn)
o Windows Key Function
o Application Key Function
• TouchPad™ Enable/Disable (FN+F9 or by help of software)
• Control Buttons:
o CD/DVD control buttons (Skip to Previous/Next Track,
Play, Stop)
Communications
• Toshiba V.92 software modem
• Intel PRO/100 VE Network Connection - 10/100 Base-TX Ethernet
• Atheros® 802.11b/g wireless-LAN
9
10
11
© Copyright 2005 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
A55-S1066 BTS Rev. .92 2005-12-07 MCL T20051031 CB1.20
1
Expandability
• 2 main memory slots. Both slots may be occupied.
• 1 PC Card slot support 1 Type II, PCMCIA R2.01, PC Card16,
CardBus
Ports
• Video
o RGB (monitor) output port
o S-Video output port
• Audio
o Microphone input port
o Headphone output port
• Data
o Universal Serial Bus (USB v2.0) – 3 ports
o RJ-45 LAN port
o RJ-11 modem port
Physical Description for this Product Series
• Dimensions (WxDxH Front/H Rear): 1.33" (338mm) x 10.8"
(274mm) x 1.06" (27mm)[F]/1.50" (38mm)[R] without feet
• Weight: Starting at 6.0 lbs (2.7 kg) depending upon configuration
6
• Indicators:
o DC-In, Power, Battery, Hard Drive, CD-DVD ROM
Access, Caps Lock, Arrow Lock, Numeric Lock, Main
Battery Charging Status, Sleep Suspend Mode, Wireless
• Chassis Description
o Case material: Polycarbonate ABS
o LCD Cover Color: Hyper Silver Metallic
o Base Color: Premium Black
• Physical Security
o Slot for cable lock;
o Items protected by a screw: Memory, hard Disk drive
• Software Security
o Passwords: User power-on password, supervisor
password
o Hotkey locks: Screen Blank
Power Supply
• 60W (15V 4.0A) Auto sensing external AC Adapter, 100-240V / 50-
60Hz frequency (Universal) input.
• Dimensions (WxDxH): 1.95" (49.5mm) x 4.51" (114.5mm) x 1.14"
(29mm)
• Weight: starting at .58 lbs (262 g)
13
Battery
• 6-cell (400mAh) rechargeable, removable Lithium Ion (Li-Ion)
battery pack
• Dimensions (WxDxH): 8.15" (207mm) x .78" (20mm) x 1.78"
(45mm)
• Weight: starting at 0.73 lbs (330 g)
• Battery Life (measured by MobileMark™)
o Included 6-cell battery: 2 hours, 45 minutes
o Opptional 12-cell battery: 5 hours, 33 minutes
• Recharge Time
o Main Battery Off/On – approximately 2.5
hrs/approximately 5.0 to 11.0 hrs
BIOS
• APM, ACPI v1.0b, PNP v1.0, VESA, DPMS, DDC, SM BIOS v2.3,
PCI BIOS v2.1 support
Part Number UPC
PSA50U-0NU02E 032017499089
14
12
