- Page 2 GENERAL BEST PRACTICES FOR ASSEMBLY: Determine you have adequate space for assembly. Assembly by two adults is recommended. Assemble on soft surfaces to prevent damage to product finish. Keep children away during assembly. This item contains small parts which can be swallowed by children.
- Page 3 PARTS LIST Post x1pcs Table Top x1pcs Legs x4pcs Mounting plate x1 pcs Bottom post x 1 pc HARDWARE LIST Spring Washer x 8 pcs Allen Bolt x 4 pcs Flat Washer x 8 pcs Allen Key x 1pcs Ø5/16'' x 32mmL Ø5/16'' Ø5/16'' Nut x 4pcs...
- Page 4 STEP 1 Hardware needed Insert Wood Dowel (5) into Legs (C). Align the inserted wood dowels with the holes of Post (B). Secure the Legs (C) to Post (B) with Flat Washer (3), Spring Washer (2) and Nut (6) using Wrench (7). Fully tighten nuts.
- Page 5 STEP 2 Hardware needed Return the assembled post to upright position. Align the holes of Mouting Plate (D) and slide it into place as shown. Attach the Mounting Plate (D) to Post (B) with Flat Washer (3), Spring Washer (2) and Bolts (1) using Allen Key (4). Fully tighten bolts. Place the Table Top (A) upside down on a smooth surface.
