- Page 1 800-CON modules (set of 2) Transfer modules for measurement device and module topologies - valid for basic devices of the 800 series User manual and technical data Janitza electronics GmbH Vor dem Polstück 6 D-35633 Lahnau Support tel. +49 6441 9642-22 Email: info@janitza.com...
- Page 2 800-CON Modules www.janitza.com Suitable basic devices and number of module slots: Slot assignment of the 800-CON Suitable basic devices / modules (set of 2) on the basic Number of free slots device UMG 801 (from FW 1.5.0) / 10 slots 0 slots Tab.
- Page 3 Nonetheless, we wish to point out that updates of this document are not always possible at the same time as technical refinements are implemented in our products. Please see our website under www.janitza.com for the current version. Please see our website under www.janitza.com for the current version. Information about the GridVis software.
-
Page 4: Table Of Contents
4. Mounting 4. 1 Mounting the 1st transfer module with output bus connector 4. 2 Mounting the 2nd transfer module with input bus connector 4. 3 Connection of device and module series with the 800-CON transfer modules (set of 2) - Page 5 800-CON Modules 5. Connections/controls 5. 1 Designation and description 5. 2 Marking of the 800-CON module - rating plate 6. Installation 6. 1 Data transfer with 800-CON module 6. 2 Data cable for connecting the 800-CON transfer modules 7. Operation and button function of the measurement device and module topology 8.
-
Page 6: Information On The Devices And The User Manual
In order · This user manual is valid for the 800-CON module to make the texts more readable, distinctions are not made. We ask for your understanding for these simpli- (set of 2). -
Page 7: Defective Device/Disposal
· When doing so, please bear the terms for transpor- tation in mind. INFORMATION Please return defective or damaged devices, modules or components to Janitza electronics GmbH in ac- cordance with the shipping instructions for air or road freight (complete with accessories). Observe special regulations for devices with built-in... -
Page 8: Safety
800-CON Modules www.janitza.com Safety The chapter on Safety contains information which 2.3 Product safety must be observed to ensure your personal safety The devices, components and modules reflect and avoid material damage. current engineering practice and accepted safety standards, but hazards can arise nonetheless. -
Page 9: Hazards When Handling The Device, Components And Modules
Equip stranded conductors with wire material damage! ferrules! · Do not use Janitza meters, modules or compo- · Hazardous voltages can be present in all cir- nents for critical switching, control or protection cuitry parts that are connected to the power applications where the safety of persons and supply. -
Page 10: Electrically Qualified Personnel
800-CON Modules www.janitza.com 2.5 Electrically qualified personnel 2.7 Safety information for handling current transformers To avoid bodily injury and material damage, only electrically qualified personnel are permitted to work The field of transformer technology groups the on the devices and their components, modules,... - Page 11 800-CON Modules WARNING Risk of injury or damage to the meter due to high measured currents/measured voltages at the connections of the current transformers! High measurement currents can cause temperatures of up to 80 °C (176 °F) on the connections of the current transformers ·...
-
Page 12: Product Description
800-CON Modules www.janitza.com Product description 3.1 800-CON module (set of 2) INFORMATION The module set, consisting of 2 transfer modules, When setting up your measurement device and mod- transmits the JanBus communication of a basic ule topology, note the following: device via a data line (for type, see Technical data) ·... -
Page 13: Incoming Goods Inspection
800-CON Modules 3.2 Incoming goods inspection 3.3 Intended use The prerequisites for trouble-free and safe operation The modules / the components of the modules include proper transport, storage, · Are only for use in the industrial sector. setup and assembly, as well as proper operation ·... -
Page 14: Eu Conformity Declaration
· complies with Part 15 of the FCC Rules for Class 33.03.059 “Mounting” supplement B digital devices (limits to protect against harmful Tab. Scope of delivery 800-CON transfer module (set of 2) interference in a residential installation). · generates, uses and can radiate high-frequency... -
Page 15: Operating Concept
800-CON Modules 3.10 Operating concept 3.11 GridVis network analysis software ® The UMG 800-CON (set of 2) expansion and transfer With the GridVis software, you have the perfect tool ® module is used for connecting remote measurement for programming, reading out, visualizing and analyz- points as previously described in Sect. -
Page 16: Mounting
This will avoid an incorrect connection of remote JanBus sys- Fig.: Input bus connector for the 800-CON transfer module at the tems! Cf. Sect. “6.1 Data transfer with 800-CON input of a series of measurement devices and modules. - Page 17 800-CT8-A module device Output bus connector click! DIN rail Fig.: Side view of basic device, modules 800-CT8-A and 800-CON ATTENTION Material damage due to voltage being applied to the basic device during installation! Coupling while energized can destroy your basic device or the module! ·...
-
Page 18: Mounting The 2Nd Transfer Module With Input Bus Connector
(internal) Input bus connector INFORMATION Always install the 800-CON transfer module with output bus connector at the end of your measure- ment device and module topology. 4.2 Mounting the 2nd transfer module with input bus connector For spatially distant module series, mount the 2nd... - Page 19 (continuing module series (see Sect. “6. Installation” on p. 24)). · In addition to the usage information for the basic device and the 800-CON transfer module (set of 2), Input bus connector please also note any other usage information for...
-
Page 20: Connection Of Device And Module Series With The 800-Con Transfer Modules (Set Of 2)
4.3 Connection of device and module series with INFORMATION the 800-CON transfer modules (set of 2) If the basic device does not recognize the module(s) To ensure trouble-free operation of your device during the power-up procedure, the module functions series with modules and thus your system, connect are not supported. - Page 21 · For the connection between the transfer modules, use a stranded twisted pair, shielded data cable with a 1:1 cable connection (see Sect. “6.2 Data cable for connecting the 800-CON transfer modules” on p. 25)! · Always connect your transfer modules via shield clamps with a strain relief! ·...
-
Page 22: Connections/Controls
Connections/controls 5.1 Designation and description INFORMATION INFORMATION The transfer modules (800-CON) of the set of 2 The transfer modules are supplied with the neces- are suitable as output or input modules! sary screw terminals and bus connectors (JanBus However, make sure to mount the correct bus... -
Page 23: Marking Of The 800-Con Module - Rating Plate
Vor dem Polstück 6 35633 Lahnau / Germany RD 96 • 5231212 0500/0001 5.2 Marking of the 800-CON module - rating plate Made in Germany • www.janitza.com Janitza electronics GmbH Vor dem Polstück 6 35633 Lahnau / Germany 800-CON •... -
Page 24: Installation
Installation 6.1 Data transfer with 800-CON module WARNING Your 800-CON transfer modules (set of 2) in combi- Risk of injury due to high currents and high electri- nation with a basic device (e.g. „Tab. Suitable basic cal voltages! devices“ on p. 2) and, for example, current mea-... -
Page 25: Data Cable For Connecting The 800-Con Transfer Modules
800-CON Modules 6.2 Data cable for connecting the 800-CON transfer modules Recommendation: Use the following data lines for smooth communica- tion in your measurement device and module topolo- gy to connect the 800-CON transfer modules: Twisted pair, shielded data cable with color code to DIN 47100 (4 x 2 x 0.25) - Lapp Unitronic LiYCY (TP) 1 : 1 - Cable connection! -
Page 26: Device Views - 800-Con Transfer Module
· The figures are for illustration purposes only and are not to scale. · Dimensions in mm (in). The set of 2 delivered transfer modules (800-CON) can be used for output or input. Bus connector for the output transfer module... -
Page 27: Technical Data
(cable connection 1:1) - To connect the transfer modules, use a stranded twisted pair, see Sect. “6.2 Data cable for connecting the 800-CON transfer mod- shielded data cable (cable connection 1:1)! ules” on p. 25. -
Page 28: Dismounting
DIN rail Bus connector Sockets Bottom bolts Connecting terminal Fig. Example "Dismantling 800-CON output transfer module" INFORMATION For trouble-free operation of your module series with transfer modules, please refer to Sect. “6.1 Data transfer with 800-CON module” on p. 24. -
Page 29: Service And Maintenance
