- Page 1 INSTALLATION & OPERATION MANUAL QUANTUM Manufactured Intelligent EV charging pedestal in the UK...
-
Page 2: Product Support
Date Published: December 2023 Rolec Services Ltd are the publishers of this document and own the rights to use the text, images and all technical content contained within. Content supplied by third parties / partner organisations remains the property of that organisation and is used by agreement with the supplier. -
Page 3: Table Of Contents
Product Support Contents Product Support Safety Safety Advice within this Manual Product Overview Product Features About Load Balancing About Load Management About Demand Side Response About PME (PEN) Protection Security – Tamper Protection Security – Tamper Protection Product Specification Unpacking Standard Contents Options and Accessories Labelling... -
Page 4: Safety
Rolec Services Ltd cannot accept any responsibility for improper installation or any problems arising from improper installation. NOTE: Damage to the equipment, connected systems or to property caused by improper installation are the responsibility of the installer. -
Page 5: Product Overview
Product Overview Product Overview The Quantum EV charging pedestal is a sophisticated and resilient EV charging point, providing a combination of durability and impeccable design for all locations. This charger’s integrated LED amenity lighting also provides greater visibility of the charging bays and surrounding areas. -
Page 6: About Load Balancing
3. Only 1 chargepoint is to be installed per phase to avoid counteracting behaviour. 4. Rolec cannot be held responsible for overloads of the supply caused by other connected electrical items or failure of the vehicle to accept a reduced rate of charge. -
Page 7: About Demand Side Response
Product Overview About Demand Side Response Similar in some ways to Load Management, a Demand Side Response (DSR) system is where the chargepoint and the electricity provider are in communication with each other. The electricity provider will control the chargepoint remotely via the chargepoint software to reduce the power it draws when it is needed by higher priorities in the area and will increase power when those priorities reduce. -
Page 8: Product Specification
Product Specification Product Specification 360mm 260mm Light Sensor Illumination QR Code Socket ID User Label Instructions LED ‘Halo’ Status RFID Sensor Indicator 1 each side on 4-Way ChargePoints Charging Socket(s) 2 each side on 4-Way ChargePoints 375mm 275mm Figure 1 Pedestal General Arrangement and Dimensions Figure 2 Optional Ground Mounting Base Quantum Intelligent EV Charging Pedestal EVQM-V01-R6 Installation and Operation Manual... - Page 9 Product Specification Smart Communications Module Cable Lock Socket 2 Cable Lock (rear) Socket 1 RFID Sensor (rear) EV Charge Controller EV Charge Controller for socket 1 for socket 2 (Front Layer) (Rear Layer) RCBO – Socket 2 RCBO – Socket 1 MID Meter –...
- Page 10 Product Specification Smart Link Connection Meter Connectors 2x CT Connectors Status Indicator Power ‘IN’ ‘Halo’ Connector Connector to Power ‘OUT’ and N, E, L. Signal Connector to Socket or Cable L, N, E. Figure 4 EV Charge Controller GPRS Antenna Connection Connection to RFID Board...
- Page 11 Product Specification Connection Charging Input Unit Product Type Output Supply Colour Code Black ROLEC0411B 1x 32A 1x Type 2 (IEC 62196) Up to 7.4kW (32A) Single Phase Grey ROLEC0411G charging socket per socket 230V AC (±10 %) 50/60Hz White ROLEC0411W Single Black ROLEC0421B...
- Page 12 Certification Markings – CE & UKCA Warranty 3 years Rolec Services Ltd are a registered manufacturer (WEE/AG3499TY) within the WEEE Recycling Scheme, allowing its products at the end of their life, to be processed by an appropriate local service provider. Quantum Intelligent EV Charging Pedestal...
-
Page 13: Unpacking
IMPORTANT: Make sure all packaging is disposed of responsibly and in accordance with the current regulations in your region. Standard Contents EV Chargepoint Rolec ‘EV Connect’ Configuration Tag Rubber Mat Installation and Operation Manual 1. Examine the package and make sure the contents have not been damaged in transit. -
Page 14: Labelling
Labelling Labelling Observe any/all labels displayed on the equipment or inside the enclosure. Figure 6 Typical Product Rating and Serial Number Label Figure 8 Socket ID Label Figure 7 Configuration Tag (Back and Front) Figure 10 Typical Socket Type and power Rating Labels Figure 9 Instructions and RFID Label NOTES:... -
Page 15: Installation
Units using mobile networks require a suitable signal of 14 CSQ or better. Units using Wi-Fi connectivity require a strong, stable connection. Rolec cannot be held responsible or accountable in the event that a unit using a mobile network or Wi-Fi is installed in a location without adequate network signal. -
Page 16: If A Ground Mounting Base Will Be Used
Installation 4. Make sure the chargepoint model is correct and matches the order. NOTE: Items damaged in transit must first be reported to the courier and then to the supplier. Where possible, photographic evidence of package and/or item damage should be provided. NOTE: Incorrect or damaged units must NOT be installed. -
Page 17: Schematics
Installation Schematics Figure 11 Quantum Intelligent EV Charging Pedestal (Single-Phase) – 1x up to 7.4kW Type 2 Socket EVQM-V01-R6 Installation and Operation Manual Quantum Intelligent EV Charging Pedestal December 2023 Page 16 of 52... - Page 18 Installation Figure 12 Quantum Intelligent EV Charging Pedestal (Single-Phase) – 2x up to 7.4kW Type 2 Socket Quantum Intelligent EV Charging Pedestal EVQM-V01-R6 Installation and Operation Manual Page 17 of 52 December 2023...
- Page 19 Installation Figure 13 Intelligent EV Charging Pedestal (Single-Phase) – 4x up to 7.4kW Type 2 Socket NOTE: With the exception of power input terminals and lighting, the 4-way pedestal is essential 2x 2-way chargers in one pedestal. EVQM-V01-R6 Installation and Operation Manual Quantum Intelligent EV Charging Pedestal Page 18 of 52 December 2023...
- Page 20 Installation Figure 14 Quantum Intelligent EV Charging Pedestal (Three-Phase) – 1x up to 22kW Type 2 Socket Quantum Intelligent EV Charging Pedestal EVQM-V01-R6 Installation and Operation Manual Page 19 of 52 December 2023...
- Page 21 Installation Figure 15 Quantum Intelligent EV Charging Pedestal (Three-Phase) – 2x up to 22kW Type 2 Socket EVQM-V01-R6 Installation and Operation Manual Quantum Intelligent EV Charging Pedestal December 2023 Page 20 of 52...
-
Page 22: Install The Pedestal
Installation Install the Pedestal IMPORTANT: All electrical work must be performed in accordance with the current legislation applicable in the geographical region of the installation. CAUTION: Equipment Damage – Sensitive Equipment If you will be performing insulation resistance tests on the power supply cables, it is advised to be done BEFORE connecting the power cable to the chargepoint. -
Page 23: Install Load Balancing
Installation NOTE: All electrical work must be performed in accordance with the current legislation applicable in the geographical region of the installation. CAUTION; Equipment Damage – Sensitive Equipment If you will be performing insulation resistance tests on the power supply cables, it is advised to be done BEFORE connecting the cable to the chargepoint. -
Page 24: Overview
Installation If installing at a later date, work may be required to enable entry of the CT cable into the pedestal enclosure. Overview Power coming into the property is monitored by a Current Transformer (CT) that clamps around the property’s incoming power cable and is then connected to the chargepoint. The CT has a cable allowing it to be connected to the chargepoint. -
Page 25: Connect The Ct Cable To The Chargepoint
Installation Connect the CT Cable to the Chargepoint IMPORTANT: A suitable cable gland must be installed to the chargepoint enclosure to accept the CT cable and maintain the IP rating of the enclosure. 1. Locate the EV Charge Controller enclosure and the connector marked CT. -
Page 26: Configure Load Balancing
IMPORTANT: Charge point management/operation applications such as that provided by Monta, or any other service provider, are NOT part of the Rolec product and any agreements, contracts or fees related to their services will be between you and your chosen provider. -
Page 27: Required Items
4. Rolec Charge point ID label – This is a removable label attached to a red and black ‘tag’ that is supplied with the charge point and usually hung on one of the sockets or attached to the enclosure. - Page 28 Rolec (01205 administration tasks can be performed between Rolec and Monta. Follow the automated call menu to be put through to the ‘Monta Onboarding Team’ or ask for the team if your call is answered by a human operator. Following the call you should receive an email link that will take you the Monta onboarding system.
-
Page 29: Ev Connect Configuration
Product Overview The Rolec EV Connect Application is supplied by Rolec as a means of creating an initial connection between a smartphone or similar device and a Rolec manufactured EV charge point. -
Page 30: No Camera Or Qr Code Reader
Configuration No Camera or QR Code Reader? The processes in this manual describe the use of the smartphone camera to scan a QR code label as this is the easiest way to establish a Bluetooth connection. If there are problems such as not having a camera, or the code scanner is not available, it is possible to connect a phone to the charge point using Bluetooth alone. - Page 31 Configuration 5. All charge points within the range of the Bluetooth signal will be listed. If more than one is listed, you will need to know which charge point you want to connect to. The charge point ID is shown on the small QR code label attached to the Configuration Tag or, on the QR code label attached to the communications device inside the...
-
Page 32: Configuration For Installers
2. The LED indicator on the charge point will flash BLUE when the chargepoint is ready. 3. Open the Rolec EV Connect application on the phone. 4. Read the privacy policy and accept the terms if you are happy to proceed. -
Page 33: Installer Registration
Configuration Installer Registration 1. If using the application for the first time, you will need to register as an installer. 2. Tap the REGISTER text button. 3. Complete the fields presented on the next screens to add your details. First Name Last Name Company Name Company Registration Number... -
Page 34: Installer Projects
Configuration Installer Projects 1. On the Installations – Recent Projects screen, tap the New button. 2. Select whether you are installing a charge point in a Home or a Commercial environment. This will influence some of the settings available during configuration. Home and Commercial projects will be placed in separate groups within the application to aid their management. - Page 35 Configuration 5. Scan the removable QR Code label attached to the Configuration Tag. When the code has been read, the camera will close, and the charge point’s MAC address and Unique ID will be shown. 6. Tap the line of text showing the MAC address and ID.
- Page 36 Make sure you are fully aware of the provider’s terms and conditions and fees that may be associated with using the application/service. Your contract for these services will be with that provider and not with Rolec. Quantum Intelligent EV Charging Pedestal...
- Page 37 Configuration IMPORTANT: INSTALLERS 1. Make sure you pass this manual to the charge point owner. 2. Make sure you pass the Installation Certificate (and any associated paperwork) to the charge point owner. 3. Make sure you pass the Configuration Tag to the charge point owner. Place the removeable QR code label from the Configuration tag into the space provided on the REAR of this manual.
-
Page 38: Configuration For Owners
The LED indicator on the charge point will flash BLUE when the chargepoint is ready. Open the Rolec EV Connect application on the phone. Read the privacy policy and accept the terms if you are happy to proceed. - Page 39 Configuration 6. After a few seconds the connection process will be complete, and the Configuration screen will be displayed. 7. Enter the appropriate details into each of the fields of the form. Fields that have already been completed by the installer may not be accessible.
-
Page 40: Monta Connections
Make sure you are fully aware of the provider’s terms and conditions and fees that may be associated with using the application/service. Your contract for these services will be with that provider and not with Rolec. Monta Connections NOTE: These instructions were written using processes and screens shown by the Google Android smartphone system. -
Page 41: Commercial - Use A Charge Point With Monta
Configuration Commercial - Use a Charge Point with Monta Commercial site owners/operators who want to make their charge points visible to staff, will need to pair each charge point with a Monta Sticker that can be scanned by the drivers’ Monta App to enable a charge session. The owner/operator must first make sure all of their details are accurate and complete within the Monta portal. -
Page 42: Domestic - Use A Charge Point With Monta
3. Make sure the Charge points button is selected at the top of the screen. 4. Tap the Add a charge point button. 5. Follow the on-screen prompts to enter the charge point brand (Rolec) and model rge point rge poin then tap Continue. - Page 43 Configuration 10. Enter the charge point ID/Serial number. This number is on a removable label attached to the red and black charge point tag or may have been placed by the installer on the manual, the property fuse box, or the installation certificate.
-
Page 44: Remove A Charge Point From Monta
Configuration Remove a Charge Point from Monta 1. Open the My charge points screen. 2. Tap the gear icon 3. Tap Delete charge point. A confirmation message will be displayed. 4. If you are sure the charge point can be deleted, tap the Delete button shown on the message. -
Page 45: Monta Labels
Chargepoint Installation Completion Monta Labels The Monta ID Label located next to individual sockets or tethered cables can be used to enable charging by guests at your property, regardless of whether the driver is a Monta user. If enabled and configured in the owner’s Monta App, the guest simply scans the QR code on the label to connect to Monta where they can pay for and initiate a charge at their own cost. -
Page 46: Operation
Operation Operation As a ‘Smart’ product, this chargepoint can be operated and/or monitored by a wide range of web enabled devices. Alternatively, it may be operated manually via an RFID card/fob. 1. Refer to the status indicator guide to determine whether the chargepoint is available for use. -
Page 47: End A Charging Session
Operation NOTE: Default Hours and Randomised Delay Following the initiation of the charge session, UK regulations require chargepoints of this type to apply power for charging during the ‘default’ (off-peak) hours regardless of when the charge session was initially started. When the off-peak period is reached, power for charging will be applied after a randomised delay of up to 10 minutes. -
Page 48: About Charging Cables And Sockets
Operation About Charging Cables and Sockets The points below apply to Rolec cables and will be similar for cables made by other manufacturers. Always follow the manufacturer's advice. 1. Charging cables should be fully uncoiled when in use. 2. Charging cables should not be stretched or place strain on the chargepoint or vehicle connections. -
Page 49: Maintenance
Maintenance Maintenance Replace the LED Bulb The LED bulb in the lighting head can be easily replaced. IMPORTANT: Only install a bulb of the same specification. Other types of bulb may damage the pedestal. Bulb Type: GX53 LED Power: 9W / 230 - 240 Volts Colour Temperature: 4000K WARNING: Electrical Power Turn OFF electrical power to the pedestal before starting work. - Page 50 Maintenance 4. Inside the pedestal, locate and remove 2x 5mm hex bolts and washers that secure the clear dome to the dome base. Take care to not drop the bolts and washers when they are released from the dome. 5. Carefully lift the clear dome from the pedestal and place it to one Figure 20 Dome Bolts side.
-
Page 51: Chargepoint Maintenance
NOTE: In the event of a hardware issue, always contact your installer first. If damage has been sustained to communications devices and/or other ‘Smart’ components, it is recommended that an approved Rolec installer is called to perform the repair. Damage caused to the equipment by misuse, lack of maintenance, inappropriate maintenance or modification is not covered by the manufacturer warranty. -
Page 52: About Software Updates
Maintenance 7. Do NOT allow charging cables to become contaminated with water (or other substances). Always store cables in accordance with the manufacturer’s instructions. NOTE: Rubber ‘dust’ caps that may be attached to cables are only suitable for short term protection, or protection whilst stored in an indoor environment. They are not designed to fully protect against water ingress. -
Page 53: Suggested Inspection And Testing
Maintenance Suggested Inspection and Testing A record or inspection, testing and maintenance must be kept and may be required to support warranty claims. and 3 Quarter and 4 Quarter External Visual Inspection: External Visual Inspection: Check for physical damage. Check for physical damage. All warning labels present and All warning labels present and legible. - Page 56 Brand names, logos and trademarks used herein remain the property of their respective owners. This listing of any firm or their logos is not intended to imply any endorsement or direct affiliation with Rolec Services Ltd. and is purely to demonstrate branding opportunities. © 2023 by Rolec Services. All rights reserved.
