Summary of Contents for PEZTIO Dashcam-M1
-
Page 2: Model Introduction
MODEL INTRODUCTION Front & Cabin Dual 1080P Lens Peztio M1 equipped with dual cameras (a front and a cabin cam) and both of them can record videos in 1080P (1920*1080), vividly capture the videos of both front side road and in-cabin driver and passengers, ideal for the taxi driver. -
Page 3: Package Content
Loop Recording The Loop recording video can be set the timing 1 min, 2 mins or 3 mins. It will overwrite the oldest unprotected video with the lasted footage, make space for your memory card. 3.18 inches High-Definition IPS Screen Built-in 3.18-inch HD large IPS screen, with 4 real-time display modes for you to master the situation on both the front side of the car and passenger cabin. -
Page 4: Product Structure
PRODUCT STRUCTURE Content Description Stand Attach the camera to the windscreen. Front Lens Record the front side video. Push the reset hole to reset the dash Reset Key cam (recommend to use a needle). Power Slot Connect to the car cigarette charger. Card Slot Insert the SD card from here. - Page 5 Content Description AV Jet External equipment (not included). Screen 3.18-inch HD IPS screen. Cabin Cam Record the cabin video. Captures decent cabin images when IR lights the passenger cabin is dark. 1. Upwards / switch display modes 2. Long press to switch albums from UP Key front/cabin camera in video playback mode.
-
Page 6: Start To Use
PARAMETERS Display Screen 3.18-inch IPS Screen G-Sensor Support IR Camera Cabin Camera Support Resolution Dual 1080P (front & cabin) Battery Build in 200mah Loop recording Support Lens Angle 170 Degrees Wide Angle Power Interface Mini USB Support SD card Class 10 SD Card up to 64GB Language English, German, Japanese, etc. - Page 7 S1: Insert the SD Card Please pay attention to the right SD card insert orientation following the instruction of the picture on the right. Gently insert the TF card into the slot till a “tik” sound occurred. S2: Stick it on the windscreen of your car A.
- Page 8 S3: Connect the power to dash cam and cigarette lighter Connect the car original charger to the cigarette lighter. Route the cables through the top ceiling and the A-pillar so that it does not interfere with driving. The camera will power on and auto start recording once you spark the engine.
-
Page 9: Set Up Your Camera
(will cause irreparable damage), please remove the recorder according to the instructions above. Scan the code to watch the installation video. Or search “Peztio M1” on Youtube.com SET UP YOUR CAMERA Format the SD card We recommend you format the SD card for the first time use and format the SD card once a month regularly. - Page 10 Set the date & time > Double Press the Menu button to enter the system. > Choose the “Date & Time”, press ok to enter the sub menu. > Press Up/Down to change the date/time, and press OK to confirm & jump into the next setting field. >...
- Page 11 VIDEO MODE INTRODUCTION Adjust the video options: Please press OK to stop the camera from recording then short press Menu Button to enter the video setting menu. (⭐represent the recommended settings) Interface: Content Introduction Video mode Indicates the camera is in video mode Lock Current video is protected The camera will auto adjust the...
- Page 12 Content Introduction With G-Sensor on, the camera will G-Sensor detect the collision and lock the footage, can set the sensitivity. G-Sensor Options: off / Low ⭐ / Medium / High When it is recording, it shows the Time length of the current video, when it is reminder not recording, it shows the remaining time of the SD card can record.
- Page 13 Content Introduction Exposure Set the exposure you prefer. Exposure options: from +3 to -3 With the motion sensor on, the camera Motion will start recording after it detects a detection motion. Motion detection options: on / off With this monitor on, the camera will Parking auto power on and start recording monitor...
- Page 14 Content Introduction License Shows your license number. Number License number options: on ⭐ / off Indicates the camera is connected to Charging the power supply. PLAYBACK MODE INTRODUCRTION Interface:...
- Page 15 Introduction Indicates the camera is in play back mode Indicate the current video is locked. Shows the video ID or picture ID Press OK to play the video Press down key to skip to next video Press up key to rewind while playing the video Press down key to fast forward while playing the video Manage Albums in Playback Mode...
- Page 16 CAMERA MODE INTRODUCTION Interface: Content Introduction Picture Mode Camera in picture mode Anti-Shake Prevent shaking Anti-Shake option: on(recommended) / off Resolution Picture resolution Resolution options: from VGA to 10 M Remained space The remain pictures quantity SD card can store...
- Page 17 SYSTEM SETTINGS (Press twice menu key to enter) Content Introduction IR Light To turn on/off the IR lights of cabin camera Screen Saver Screen goes off after without operation The camera goes off after a time without Auto off recording and operation Frequency Set the frequency of the light Beep...
- Page 18 Q&A Question Answer To achieve 24 hours record, please Can’t record purchase a hardwire kit individually for 24 hours. which is not included in the package. Please push the reset button and Camera keeps format the SD following the step restart introduced (see page 7) Please charge the dash cam for 15...
- Page 19 Please keep the camera connect to The camera the power supply for daily use, the shuts down battery is not to power the camera very soon. but for the emergency situation when your car is off. The cabin Please turn on the IR lights to the video is too capture the clearer cabin video.
