PEZTIO Q1 User Manual

PEZTIO Q1 User Manual

Wifi connected full hd 1080p wide angle
Hide thumbs Also See for Q1:

Advertisement

USER MANUAL
ANY PROBLEMS, please contact us by Email.
Here is the address:
US Customers: q1support-us@peztio.com
EU Customers: q1support-eu@peztio.com
WIFI Connected
DASH CAM
Full HD 1080P Wide Angle

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Q1 and is the answer not in the manual?

Questions and answers

Karyn
March 9, 2025

I have bought a second hand vehicle that has a Peztio 1 with it but I can’t set it up. No manual came w it.

1 comments:
Mr. Anderson
March 9, 2025

1. Power the Device: Use the car charger (5V 1A) to connect the dash cam to the vehicle’s cigarette lighter. Keep it plugged in for normal operation.
2. Insert Memory Card: Ensure the memory card is correctly inserted before use. Format it through the setup menu if needed.
3. Mount the Dash Cam: Clean the front windshield, remove the protective sticker, and attach the device securely.
4. Turn on the Device: The dash cam will start recording automatically when powered.
5. Connect to Wi-Fi (Optional):
- Download the "GoPlus Cam" app from the App Store (iOS) or Play Store (Android).
- Turn on the dash cam, press the power button (without recording) to activate Wi-Fi mode.
- On your phone, search for the Wi-Fi network named GPLUSPRO and enter the password 12345678.
- Open the "GoPlus Cam" app and connect to the dash cam.
6. Adjust Settings: Access the system settings to configure options like date/time, resolution (1080P or 720P), loop recording, motion detection, and more.
7. Start Recording: The dash cam will automatically record and save files to the memory card. Use loop recording to overwrite old files when storage is full.

This answer is automatically generated

Summary of Contents for PEZTIO Q1

  • Page 1 USER MANUAL ANY PROBLEMS, please contact us by Email. Here is the address: US Customers: q1support-us@peztio.com EU Customers: q1support-eu@peztio.com WIFI Connected DASH CAM Full HD 1080P Wide Angle...
  • Page 2: Power Source

    INTRODUCTION Welcome to use PEZTIO DASH CAM. This is Model, which equipped with WIFI function. Automatic start to record, just plug and play, video files will be saved on the memory card. Connect it to your cell phone though WIFI and check the videos on your phone album.
  • Page 3: Product Structure

    4. SOS mode Press the SOS button to Lock the video currently being recorded. (If you set the loop recording time as 3 mins, when you press the SOS button, the dash cam will lock the video currently being recorded. The length of this locked video file is 3mins.
  • Page 4: Micro Sd Card

    Name Description LCD Screen 1.5” TFT Color LCD Display. Confirms the action; Stop/Start OK Button the video recording. Down Button Move selector up; rewind Mode Button Convert the modes. Move selector down; fast Up Button forward Menu Button Enter/exit setup menu Records clear audio with the Microphone video footage.
  • Page 5: Screen Overview

    SCREEN OVERVIEW Video Mode Photo Mode...
  • Page 6: Playback Mode

    Playback Mode START TO USE 1. Install the memory card. Note: Please choose a good quality branded SD card between 8GB and 32GB (Class 10 or UHS type 1) and format the card within the setup menu before use. Please insert the card in the right direction.
  • Page 7: Wifi Mode

    -Connect the charging cable to the cigarette lighter. WIFI MODE Start to use wifi mode 1. Download the GoPlus Cam app in smartphone. IOS : search “goplus cam” in App Store. (Support iPhone and iPad for iOS 8.0 or higher) Android: search “goplus cam”...
  • Page 8 3. Open the smart phone WIFI and search for the device in the WIFI network. 4. Enter the password (12345678) for the first connection. 5. Wait for the phone to connect properly. 6. Once the connection is complete, run the APP: Goplus GoPlus Cam app usage Connect to WIFI, enter the Goplus APP.
  • Page 9: Wifi Trouble Shooting

    WIFI TROUBLE SHOOTING PROBLEM SOLUTION 1. Make sure no other device or phone is connected to the dash cam WiFi. The My phone has dash cam does not support connection searched with multiple devices at the same time. WiFi 2.Disconnect the Wifi and reconnect dash cam but again.
  • Page 10: System Setting

    internet dash cam and mobile phone, it can't when I connect access the Internet. this WiFi? Due to the limitation of WiFi transmission rate, the videos you watch is only Why the videos 640x360@60fps. are not clear when I check So, we suggest you download the videos them from...
  • Page 11: Record Mode Setting

    WIFI SSID GPLUSPRO WIFI PASSWORD 12345678 LICENSE PLATE STAMP Value LICENSE PLATE STAMP Off/On SWITCH FORMAT Cancel Cancel/OK DEFAULT Cancel Cancel/OK VERSION Value Record Mode Setting Content Option Resolution 1080P FHD 1920*1080/ 720P 1280*720 Loop Recording Off/1Minute/3Minutes/5Minutes On/OFF Exposure Value Motion Detection On/Off Record Audio...
  • Page 12: Playback Mode Setting

    Sequence On/Off Quality Fine/Normal/Economy Sharpness Strong/Normal/Soft White Balance Auto/Daylight/Cloudy/Tungsten/Fluorescent Auto/100/200/300/400 Exposure Value Anti-Shaking On/Off Date Stamp On/Off Playback Mode Setting Content Option Delete Delete Current/ Delete All Protect Lock Current/Unlock Current/Lock All/ Unlock All TROUBLE SHOOTING PROBLEM SOLUTION Video Image is Remove the protective lens cover, clean blurred.
  • Page 13 The date & time This time is the time when the product DASH leaves the factory. Please calibrate in the CAM is incorrect. settings. With the card previously installed, you now need to push the card further inwards slightly, using your finger nail, until you hear and feel a small latch.
  • Page 14 Reset the DASH CAM to the default settings within the Setup Menu and try Unresolved again. Should the problem persist issues. contact us by support e-mail. ANY PROBLEMS, please contact us by Email. Here is the address: US Customers: q1support-us@peztio.com EU Customers: q1support-eu@peztio.com...
