- Page 1 DeviceEdge_Orin Nano/NX Series AIE-CO21/CO31 AIE-CN31/CN41 USER MANUAL...
- Page 2 Document Change History Version Date Description V1.0 2023/06/15 Initial Release. V1.1 2023/10/30 Update DS information AIE-KO21/AIE-KO31/AIE-KN31/AIE-KN41 User Manual...
- Page 3 Aetina be liable to any person for any direct, indirect, special or other consequential damages arising from the use of any information contained herein, even if nvidia is expressly advised of the possibility of such damages.
- Page 4 All other product names or trademarks are properties of their respective owners. No ownership is implied or assumed for products, names or trademarks not herein listed by the publisher of this document. For more information about this and other Aetina products, please visit our web-site at: http://www.Aetina.com/...
- Page 5 Because of Aetina’s high quality-control standards and rigorous testing, most of our customers never need to use our repair service. If an Aetina product is defective, it will be repaired or replaced at no charge during the warranty period. For out of warranty repairs, you will be billed according to the cost of replacement materials, service time and freight.
- Page 6 Safety Precautions Please read the following safety instructions carefully. It is advised that you keep this manual for future references: 1. All cautions and warnings on the equipment should be noted. 2. Make sure the power source matches the power rating of the device. 3.
-
Page 7: Table Of Contents
4. Recovery Mode ................ 16 5. Initial Setup ................17 Prepare the materials ..................17 Hardware connection ..................17 Setup details......................17 6. EdgeEye ................... 18 Aetina 360 Edge Administration Platform ............18 Feature ......................... 19 System Requirements ..................19 AIE-KO21/AIE-KO31/AIE-KN31/AIE-KN41 User Manual... -
Page 8: Introduction
DeviceEdge Orin Nano/NX series – AIE-CO21/AIE-CO31/AIE-CN31/AIE-CN41 is a standard system, supporting for NVIDIA Jetson Orin Nano/NX. The system is with smart button for one-key recovery function to address critical system failure and real-time monitoring for status of device through the AIM (Aetina Intelligent Management). 1.1 Features ⚫... -
Page 9: Specification
1.2 Specification ◼ System configuration Specification AIE-CO21 AIE-CO31 AIE-CN31 AIE-CN41 Nvidia Jetson Orin Nvidia Jetson Orin Nvidia Jetson Orin Nvidia Jetson Orin Module Compatibility Nano 4G Nano 8G NX 8G NX 16G AI Performance 20 TOPS 40 TOPS 70 TOPS 100 TOPS 512 Core NVIDIA 1024 Core NVIDIA... - Page 10 Idle: Connect with Keyboard, Mouse and HDMI Display Full loading: Connect with keyboard, mouse, HDMI display and LAN with CPU and GPU 100% loading Dimension 130 x 90.2 x 72 mm (5.11 x 3.55 x 2.83 in) (W x D x H) Mounting Wall Mount / Din Rail (optional) Net Weight...
-
Page 11: Hardware Information
2. Hardware Information 2.1 I/O Interface Figure 2.1 AIE-CO21/AIE-CO31/AIE-CN31/AIE-CN41 I/O Interface 2.2 External Connector Summary Location External Connector Description Front Power Power pushbutton DC-IN 2-Pin Terminal block RJ-45 GbE Port HDMI HDMI 2.0 Type A Port USB 1 USB3.2 Gen 2 Type-A Connector USB 2 USB3.2 Gen 2 Type-A Connector OTG Type-C... -
Page 12: External I/O Interface
2.3 External I/O Interface ◼ Power Item Description Location Front Type Pushbutton ◼ Power input connector Item Description Location Front Type DC-in 12-24 VDC / 2-Pin Terminal Block ◼ LAN Item Description Location Front Type RJ-45 Connector Notes LED Static ON: LAN Link is active. LED Blinking: Data is being transmitted. - Page 13 ◼ OTG Type-C connector Item Description Location Front Type Type-C USB connector Notes support OTG function only ◼ DB15 female Port Item Description Location Rear Type GPIO/UART/I Pin # Definition Notes Pin # Definition Notes GPIO1 (GPIO01 / IN/OUT GPIO2 (GPIO11 / IN/OUT PQ.05 453) PQ.06 454)
- Page 14 ◼ CAN DB9 Port Item Description Location Rear Type Notes 5.7kVrms Isolation Pin # Definition Pin # Definition CAN_L CAN_H ◼ Reset & Recovery Button Item Description Location Side Type Pushbutton AIE-KO21/AIE-KO31/AIE-KN31/AIE-KN41 User Manual...
-
Page 15: Power Consumption
2.4 Power Consumption The power consumption shown as below is the theoretical value for AIE-CO21/AIE-CO31 Type Theoretical Maximum System power Idle 3.4 W (Connect with keyboard, mouse, and HDMI display) 25.08 W (Connect with keyboard, mouse, HDMI display and LAN with CPU and Full loading GPU 100% loading) The power consumption shown as below is the theoretical value for AIE-CN31/AIE-CN41. -
Page 16: Mechanical Dimensions
2.5 Mechanical Dimensions ◼ System & Mounting Dimensions AIE-KO21/AIE-KO31/AIE-KN31/AIE-KN41 User Manual... -
Page 17: Software Installation
3. Software Installation Aetina NVIDIA Jetson products have built-in BSP so the users don’t have to install it after getting the products. Since we develop our own BSP, the users may need to follow the BSP installation SOP to re-install/upgrade/downgrade the BSP. Please visit the Aetina website or contact with Aetina FAE at Tech_support@aetina.com for installation guides, BSPs and technical tips. -
Page 18: Initial Setup
5. Initial Setup Before using AIE-CO21/ AIE-CO31 & AIE-CN31/ AIE-CN41 series, please follow the steps below to have initial setup 5.1 Prepare the materials Please prepare the materials list below. ◼ A monitor with HDMI and respective cables ◼ USB keyboard and mouse ◼... -
Page 19: Edgeeye
Introduction To help clients efficiently and systematically manage edge devices deployed in different locations, Aetina offers several cloud management platforms. For example, EdgeEye, an Aetina browser-accessed management platform, allows clients to conveniently manage edge devices via intranet-connected cell phones, tablets, or laptops, no matter where the devices are deployed. -
Page 20: Feature
Safari:5.1+ Server Hardware Minimum Requirements: IntelR Core™ i5 2.3 Ghz CPU or above 32 GB RAM 200 GB root partition for the system Operating System: Linux Ubuntu 18.04+ Browser Google Chrome 9.0+ Client Support all Aetina products AIE-KO21/AIE-KO31/AIE-KN31/AIE-KN41 User Manual... - Page 21 Aetina Corporation | Headquarters 2F-1, No.237, Sec.1, Datong Rd., Xizhi Dist., New Taipei City 221, TAIWAN Phone: +886-2-7709 2568 Fax : +886-2-7746 1102 Mail : sales@Aetina.com www.Aetina.com Copyright © 2022 Aetina Corporation. All rights reserved.
