- Page 1 DeviceEdge_ORIN NX/NANO Series AIE-KN31/KN41/ KO21/KO31 USER MANUAL...
- Page 2 Document Change History Version Date Description Authors V1.0 2023/02/04 Initial Release. Joann Tung AIE-KN31/AIE-KN41/AIE-KO21/AIE-KO31 User Manual...
- Page 3 Aetina be liable to any person for any direct, indirect, special or other consequential damages arising from the use of any information contained herein, even if nvidia is expressly advised of the possibility of such damages.
- Page 4 All other product names or trademarks are properties of their respective owners. No ownership is implied or assumed for products, names or trademarks not herein listed by the publisher of this document. For more information about this and other Aetina products, please visit our web-site at: http://www.Aetina.com/...
- Page 5 Because of Aetina’s high quality-control standards and rigorous testing, most of our customers never need to use our repair service. If an Aetina product is defective, it will be repaired or replaced at no charge during the warranty period. For out of warranty repairs, you will be billed according to the cost of replacement materials, service time and freight.
- Page 6 Safety Precautions Please read the following safety instructions carefully. It is advised that you keep this manual for future references: 1. All cautions and warnings on the equipment should be noted. 2. Make sure the power source matches the power rating of the device. 3.
-
Page 7: Table Of Contents
4.1 Prepare the Materials ..................... 16 4.2 Hardware Connection ..................... 16 4.3 Setup Details ......................16 5. EdgeEye ..................17 5.1 Aetina 360 Edge Administration Platform ............... 17 5.2 Feature ........................18 5.3 System Requirements .................... 18 5.4 Order Information ....................19... -
Page 8: Product Specification
NVIDIA® Jetson Orin NX/NANO. The system is with smart button for one-key recovery function to address critical system failure and real-time monitoring for status of device through the AIM (Aetina Intelligent Management). 1.1 Features ● Support NVIDIA Jetson Orin NX/NANO ●... -
Page 9: Configuration
1.2 Configuration Table 1.1 Lists the SKU configuration currently available for the AIE-KN31/AIE-KN41/AIE-KO21/AIE- KO31. System configuration Specification AIE-KO21 / AIE-KO31 AIE-KN31 / AIE-KN41 Module Compatibility Nvidia Jetson ORIN NANO 4G/8G Nvidia Jetson ORIN NX 8G/16G Storage 128GB M.2 2242 NVMe PCIe SSD Display 1 x HDMI Type A Audio... -
Page 10: Hardware Information
2. Hardware Information 2.1 I/O Interface Figure 2.1 I/O Interface 2.2 External Connector Summary Location External Connector Description Front Power Power pushbutton DC IN 2-Pin Euro block RJ-45 GbE Port HDMI RJ-45 Gigabit Ethernet connector (PoE PD function) USB3.2 Gen 2 Type-A connector USB 2.0 Type-C (OTG only) Rear DB-15... - Page 11 Type Pushbutton Power input connector Item Detail Location Front Type DC-in 12-24VDC / 2-Pin Euro block LAN Item Detail Location Front Type RJ-45 Connector HDMI Item Detail Location Front Type RJ-45 Connector Dual USB3.2 Gen1 Type-A connector Item Detail Location...
- Page 12 DB15 female connector Item Detail Location Rear Type GPIO/UART Pin NO. Description GPIO1 GPIO2 GPIO3 GPIO4 GPIO5 UART1_TX UART1_RX UATR1_CTS UATR1_RTS 3.3V DB9 male connector Item Detail Location Rear Type RS-232 Pin NO. Description AIE-KN31/AIE-KN41/AIE-KO21/AIE-KO31 User Manual...
- Page 13 DB9 male connector Item Detail Location Rear Type Pin NO. Description CAL_L CAL_H AI button (One-key recovery pushbutton) Item Detail Location Side Type Pushbutton Reset & Recovery button Item Detail Location Side Type Pushbutton AIE-KN31/AIE-KN41/AIE-KO21/AIE-KO31 User Manual...
-
Page 14: Power Consumption
2.3 Power Consumption The power consumption shown as below is the theoretical value with Orin NX/NANO module installed on AIE-KN31/AIE-KN41/AIE-KO21/AIE-KO31. Specification Theoretical Maximum System power Idle 2.904 W (Connect with keyboard, mouse, and HDMI display) 12.342 W (Connect with keyboard, mouse and HDMI display with CPU and Full loading GPU 100% loading) Please refer to the following power consumption of individual I/O interface according to your use... - Page 15 AIE-KN31/AIE-KN41/AIE-KO21/AIE-KO31 User Manual...
-
Page 16: Software Installation
3. Software Installation Aetina NVIDIA Jetson products have built-in BSP so the users don’t have to install it after getting the products. Since we develop our own BSP, the users may need to follow the BSP installation SOP to re-install/upgrade/downgrade the BSP. Please download the BSP installation SOP at below link. -
Page 17: Initial Setup
4. Initial Setup Before using AIE-KN31/AIE-KN41/AIE-KO21/AIE-KO31, please follow the steps below to have initial setup. 4.1 Prepare the Materials Please prepare the materials list below. A monitor with HDMI and respective cables USB keyboard and mouse Ethernet cable 4.2 Hardware Connection Here is the AIE-KN31/AIE-KN41/AIE-KO21/AIE-KO31... -
Page 18: Edgeeye
5.1 Aetina 360 Edge Administration Platform Introduction EdgeEye, the Aetina 360 Edge Administration Platform, is a browser-accessed management platform that allows you to monitor and manage edge IOT device around the world. EdgeEye can monitor device’s hardware components’ utilization and capacity and send notifications immediately. EdgeEye accomplishes this by gathering data from all connected devices and storing it on a central server, either in the cloud or on one’s intranet. -
Page 19: Feature
IntelR Core™ i3 2.3 Ghz CPU or above I 4 GB RAM I 20 GB root partition for the system I 100 GB data storage Operating System: Ubuntu 14.04+ I Docker 17.03+ Client Support all Aetina products AIE-KN31/AIE-KN41/AIE-KO21/AIE-KO31 User Manual... -
Page 20: Order Information
5.4 Order Information Model name Description AIE-KO21-1-A1 AIE-KO21 w/ ORIN NANO 4G, 1 x HDMI, 2 x USB-A, 1 x USB-C(OTG only), 1 x RJ-45 GbE PORT, 1 x FAN, 12 to 24V DC INPUT, -25°C to +70°C AIE-KO31-1-A1 AIE-KO31 w/ ORIN NANO 8G, 1 x HDMI, 2 x USB-A, 1 x USB-C(OTG only), 1 x RJ-45 GbE PORT, 1 x FAN, 12 to 24V DC INPUT, -25°C to +70°C AIE-KN31-1-A1 AIE-KN31 w/ ORIN NX 8G, 1 x HDMI, 2 x USB-A, 1 x USB-C(OTG only), 1 x... - Page 21 Aetina Corporation | Headquarters 2F-1, No.237, Sec.1, Datong Rd., Xizhi Dist., New Taipei City 221, TAIWAN Phone: +886-2-7709 2568 Fax : +886-2-7746 1102 Mail : sales@Aetina.com www.Aetina.com Copyright © 2022 Aetina Corporation. All rights reserved.
