Toshiba Satellite A10-S100 Specifications

TOSHIBA
Satellite® A10 Series
Feature Model(s):
Satellite A10-S100
Cel 2500/15.0"XGA/256MB/40GB/DVD-CDRW/Mdm/LAN/WinXP Pro
Satellite A10-S1001
Cel 2500/15.0"XGA/256MB/40GB/DVD-CDRW/Mdm/LAN/WinXP Home
Satellite A10-S100 SB
Cel 2500/15.0"XGA/256MB/40GB/DVD-CDRW/Mdm/LAN/WinXP Pro/ Office Small Business 2003

Product Highlights

Performance
•
Mobile Intel® Celeron® Processor at 2.50GHz
•
256MB of Main Memory (Expandable to 1024MB)
Great Features
•
40GB* hard disk drives
•
DVD-ROM/CDRW multi-function drive
•
15.0" TFT active-matrix screen display
Get On-Line
•
Integrated V.92/56K modem
•
Integrated 10/100 Ethernet LAN
•
Optional Integrated Wireless LAN
System Characteristics
CPU (See CPU Performance Disclaimer)**
•
Mobile Intel® Celeron® Processor at 2.50GHz**
L2 Cache
•
256KB Level 2 cache memory integrated on die
•
400MHz Processor System Bus Clock Speed
Memory
•
256MB expandable to 1024MB (Both slots may be occupied)
•
Expansion memory: 128MB/256MB/512MB, SODIMM,
PC2100 DDR
•
Data/Address Bus Width: 64bit/32bit
•
Intel® 852GM Chipset
Mass Storage
•
Primary Hard Disk Drive: 40GB* hard disk drives, Enhanced
IDE (ATA-5) interface, 4200rpm drive rotation; 9.5mm height,
0.2lbs, Service Removable
•
DVD-ROM/CDRW Multi-function Drive: Enhanced IDE
(ATAPI) Interface; Maximum speed: CD-R(24x), CD-RW(10x),
CD-ROM(24x), DVD-ROM(8x); Compatibility: CD-ROM, CD-R
(read/write), CD-RW (read/re-write), DVD-ROM, DVD-R (read
only), DVD-RW (read only), DVD-RAM (read only); Service
removable
•
Software Decoder: InterVideo (WinDVD®)
Graphics/Video
•
15.0" TFT active-matrix display****; internal display supports up
to 16M colors at 1024 x 768
•
Intel® 852GM Integrated graphics controller; 32MB shared
memory
•
Direct 3D support and DirectVideo
•
External Color Support/Refresh rate:
•
640 x 480: 60/75/85/100Hz Non-Interlaced @16M
800 x 600; 60/75/85/100Hz Non-Interlaced @16M
1024 x 768; 60/75/85/100Hz Non-Interlaced @16M
1280 x 1024; 60/75/85/100Hz Non-Interlaced @16M
1600 x 1200; 60/75/85Hz Non-Interlaced @16M
1920 x 1440; 60/Hz Non-Interlaced @16M
Input Devices
Keyboard: Full sized 85 keys with 12 function keys, 2.7mm key stroke,
6mm height; Dedicated Windows® keys support; HotKey function;
TouchPad pointing device
Expandability
•
2 Memory slots – Both slots may be occupied
•
1 PC Card slot support 1 Type II PC Card
Communications
•
Integrated V.92/56K modem; Data and fax support
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to change without
notice. Copyright 2004 TAIS satellite_A10-S100.doc
Due to FCC limitations, speeds of 53kbps are the maximum permissible
transmission rates during Download. Actual data transmission speeds
will vary depending on line conditions.
Ports
Physical Description
Sound
Power Supply
Battery life may vary depending on applications, power management
settings and features utilized. Recharge time varies depending on usage.
Battery may not charge while computer is consuming full power. After a
period of time, the battery will lose its ability to perform at maximum
capacity and will need to be replaced. This is normal for all batteries. To
purchase a new battery pack or see information on accessories shipping
with your computer, visit the Toshiba website at
Security
Bios
Operating System
Additional Software
Created on 2/18/2004 9:55 AM Rev. 1.0a
Part Numbers
PSA10U-3V1JG8
PSA10U-3V1JG9
PSA10U-3V1JG8S
•
Integrated 10/100 Ethernet LAN
•
Optional: Integrated Wireless LAN
•
ECP parallel printer port
•
RGB (monitor) port
•
2 Universal Serial Bus ports (USB)
•
RJ-45 LAN Port
•
RJ-11 modem port
•
Dimensions (LxWxH): 13.0" x 11.5" x 1.5"
•
Weight: 6.3lbs
•
LED Indicators: Power, Power Save Mode, HDD, CD/DVD-
ROM, DC-IN, Caps Lock, Arrow, Numeric, Main Battery
Charging Status, System Sleep / Suspend status, Wireless
Communication switch
•
Analog Devices AD1981 Codec Chip; Software Sound; Sound
Blaster Pro compatibility
•
Built-in stereo speakers; Direct 3D Sound, DirectSound
(supported by driver) and DirectMusic; MIDI Support; Sound
Volume (by Dial);
Ports: External Microphone port, headphone port
•
AC Adapter: 75W external AC Adapter, 100-240V / 50-60Hz
frequency (Universal) input voltage,
Dimensions (LxWxH): 5.3" x 2.0" x 1.1
Weight: 0.8lbs
•
Battery Pack: 6-cell, rechargeable, removable Lithium Ion (Li-
Ion) battery, 4400mAh
•
Battery Saver (in Windows XP): Stand by, HDD Auto Off,
Display Auto Off, Throttling, Hibernation
•
Battery life (main batt): 3:13H ***
•
Recharge time (main off/on): 2.6H/4-11H+
•
Slot for computer lock, Main Battery Pack (sliding lock), HDD
(three screws) and memory (by screw only), User Power-on
password, Setup Security (by help of SVPW utility), CPU serial
No. security (By help of SVPW utility), Keyboard Lock (by
HotKey), Screen Blank (by Hotkey), Screen Saver (by
software)
•
TSETUP, APM, ACPI, PnP, VESA, DPMS, DDC, SM BIOS,
PC BIOS support
•
Microsoft® Windows XP Pro (A10-S100 / A10-S100 SB) pre-
installed
•
Microsoft® Windows XP Home (A10-S1001) pre-installed
•
Microsoft® Office Small Business 2003 (See Product/Part
15V x 5A Output.
accessories.toshiba.com
