Spartan-3AN FPGA Board
XCM-108-700AN
User's Manual
HuMANDATA LTD.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Spartan-3AN and is the answer not in the manual?

Questions and answers

Related Manuals for Humandata Spartan-3AN

Summary of Contents for Humandata Spartan-3AN

  • Page 1 Spartan-3AN FPGA Board XCM-108-700AN User’s Manual HuMANDATA LTD.

  • Page 2: Table Of Contents

    Table of Contents Revision History ....................1  Introduction ....................1  1. Specifications ..................... 2 2. Overview ......................3 2.1. Name of Parts .......................3 2.2. Block Diagram ......................4 2.3. Power Supply ......................4 2.4. JTAG Connector ....................5 3. Configuration Switch ..................6 4.
  • Page 3 HuMANDATA will revise the diagram. When a problem can be solved only by replacing components or modifying the product, HuMANDATA will take back the product to replace it with a properly functioning product.

  • Page 4: Revision History

    Update a block diagram in Section 2.2  Introduction Thank you for buying our product XCM-108-700AN. This is an evaluation board equipped with a Xilinx FPGA Spartan-3AN, power, reset, and clock circuit. It can provide you with very convenient and easy-to-use environment.

  • Page 5: Specifications

    1. Specifications Model Name XCM-108-700AN FPGA XC3S700AN-4FGG484C User I/Os User Switch User LEDs On-Board Clock 50 [MHz] (External inputs are available) Status LEDs 3 (POWER, DONE, AWAKE) Power-On Reset 240 [ms] typ. (Configuration Reset Signal) JTAG Connector SIL 7-pin socket, 2.54 [mm] pitch DC 3.3 [V] Power Input (Internal power is generated by an on-board regulator.)

  • Page 6: Overview

    2. Overview 2.1. Name of Parts User LED User Switch Oscillator 50 MHz Power Circuit JTAG FPGA AWAKE LED Config. Switch DONE LED Power LED Component Side User I/Os (CNA) Unusable User I/Os (CNB) Solder Side XCM-108-700AN v1.1...

  • Page 7: Block Diagram

    2.2. Block Diagram VIO(B) INPUT External CLK User I/Os CNB JTAG JTAG Oscillator Buffer Config. Switch Power-On Reset Spartan-3AN Typ. 240 ms XC3S700AN DONE LED -4FGG484C Power Circuit AWAKE LED 1.2V User LED Power LED (3.3V) User Switch User I/Os CNA 3.3 V INPUT...

  • Page 8: Jtag Connector

    2.4. JTAG Connector This connector is used to configure the FPGA and program the internal configuration device in-system. Pin assignment is as follows. Signal Name Direction JTAG Pin VCC(3.3V) OUT(POW) You can use Xilinx download cable. Notice Please pay attention not to attach cables in reverse. XCM-108-700AN v1.1...

  • Page 9: Configuration Switch

    2 - 4 : Mode Select Please see the table above. 5 - 7 : SPI Configuration Mode Please see a Spartan-3AN data sheet for more details. 8 : Suspend Please see a Spartan-3AN data sheet for more details. XCM-108-700AN v1.1...

  • Page 10: Fpga Configuration

    4. FPGA Configuration To configure the FPGA via JTAG, please refer to the following steps. 1. Double-click [Configuration Target Device] in [Processes] tab. 2. Select [Configure devices using Boundary-Scan (JTAG)]. 3. Open the bit file you made. 4. Confirm [Verify] is not checked in [Device Programming Properties] dialog. 5.

  • Page 11: Additional Documentation And User Support

    6. Additional Documentation and User Support The following documents and other supports are available at http://www.hdl.co.jp/en/spc/XCM/xcm-108/ Circuit Schematic  Pin List  Dimensional drawing  PCB drawing  Net List  … and more. XCM-108-700AN v1.1...
  • Page 12 Spartan-3AN FPGA Board XCM-108-700AN User’s Manual Ver. 1.1 ........... Nov. 12, 2009 HuMANDATA LTD. Address: 1-2-10-2F, Nakahozumi, Ibaraki Osaka, Japan ZIP 567-0034 Tel: 81-(0)72-620-2002 (Japanese) Fax: 81-(0)72-620-2003 (Japanese/English) URL: http://www.hdl.co.jp/en/ (Global) http://www.hdl.co.jp/ (Japan)
