- Page 1 TECHNICAL MANUAL MYCOMELIT: THE APP FOR PROFESSIONALS MYCOMELIT, L'APP PER IL PROFESSIONISTA FREE DOWNLOAD Ultra Simplebus1 audio module art. UT1010, UT1010B, UT1010W...
-
Page 2: Warning
• any purpose other than the intended use, • failure to observe the indications and warnings contained in this Manual / Instruction sheet. Comelit Group S.p.A. reserves the right to change the information provided in this Manual / Instruction Sheet at any time and without prior notice. -
Page 3: Table Of Contents
Table of contents Warning .................... 2 System functions ................29 Operating distances ................29 Description ..................4 Maximum system expansion ..............30 UT1010 ......................4 Maximum expansion per apartment.............30 Technical specifications ..............6 Wiring diagrams................31 Art. UT1010 ....................6 System performance and layouts ..........32 Installation .................. -
Page 4: Description
Available in flush-mounted or surface-mounted variants (protrusion from the wall just 10 mm and 35 mm respectively), in silver (art. UT1010), black RAL9005 (art. UT1010B) and white (art. UT1010W). To make full use of the available functions, ALL modules making up the external entrance panel must be updated to the latest firmware version, which is available to download from the website pro.comelitgroup.com... - Page 5 3. 4. 5. 13. 14. 1. Indicator LEDs 12. Terminal block for connection: call sent (green) / system busy (red) RTE programmable RTE (local lock-release input) or DO input (door open indication) lock-release enabled GND RTE or DO input reference negative IF electric door lock reference negative call in progress NO NC COM relay contacts...
-
Page 6: Technical Specifications
GENERAL DATA Type Modular Product height (mm) Product width (mm) Product depth (mm) Product weight (g) Black RAL9005, Transparent, Aluminium (art. UT1010), black (art. UT1010B), white Product colour (art. UT1010W) Coating material type Polycarbonate, Aluminium alloy Flush mounting Yes, with specific accessory Surface mounting... -
Page 7: Installation
Installation The entrance panel is available in flush-mounted or surface-mounted variants: Flush-mounted installation composition table A = Flush-mounted box B = Rain shield C = Flush-mounted module holder with finishing frame 3110/1 3110/1A 3110/2 3110/2A 3110/3 3110/3A 3110/4 3110/4A UT9181 UT9181B UT9182 UT9184H... -
Page 8: Flush-Mounted Installation
Flush-mounted installation Optional Optional BLACK... -
Page 9: Removing Nameplates (2A) / Module (2B)
CLACK! CLACK! CLACK! CLACK! CLACK! CLACK! The button has a nameplate which can be written on (A); alternatively, an adhesive label can be applied (B). The total thickness of the nameplate + adhesive label MAX 0,2 mm must not exceed 0.2 mm. You can visit the website pro.comelitgroup.com to download the PDF to print the entrance panel name cards, using the MAX 0,2 mm... -
Page 10: Installation With Side-By-Side Boxes
Installation with side-by-side boxes Before installing the boxes in the wall, fit the spacers. -
Page 11: Wall-Mounted Installation
Wall-mounted installation Optional Optional BLACK... -
Page 12: Removing Nameplates (2A) / Module (2B)
CLACK! CLACK! CLACK! CLACK! CLACK! CLACK! The button has a nameplate which can be written on (A); alternatively, an adhesive label can be applied (B). The total thickness of the nameplate + adhesive label MAX 0,2 mm must not exceed 0.2 mm. You can visit the website pro.comelitgroup.com to download the PDF to print the entrance panel name cards, using the adhesive pre-cut sheets (C) available in our catalogue (art. -
Page 13: Installation With Side-By-Side Boxes
Installation with side-by-side boxes... -
Page 14: Connections
Connections Standard connection AUDIO ENTRY SYSTEM RISER MONTANTE CITOFONICA 1595 120-230 V 12 VAC/VDC 18 Ω MAX SE NO NC UT1010 Max 20 m. Local door-opener button. Variants Variant for using the outdoor entrance panel relay Variant for using a safety door lock 1595 1595 AUDIO ENTRY... -
Page 15: Module Connection
Module connection Connection of button modules art. UT9200 AUDIO ENTRY SYSTEM RISER MONTANTE CITOFONICA 1595 120-230 V NERO BLACK 12 VAC/VDC 18 Ω MAX SE NO NC UT1010 ROSSO UT9200 (MAX 25) Max 20 m. Local door-opener button. Connection of Touchscreen module art. UT9270 MONTANTE CITOFONICA AUDIO ENTRY SYSTEM RISER 1595... -
Page 16: Connection Of Number Keypad Module Art. Ut9279M
Connection of number keypad module art. UT9279M AUDIO ENTRY SYSTEM RISER MONTANTE CITOFONICA 1595 120-230 V 12 VAC/VDC 18 Ω MAX SE NO NC UT1010 UT9279M Max 20 m. Local door-opener button. Connecting digital call module art. UT9260M MONTANTE CITOFONICA 1595 AUDIO ENTRY SYSTEM RISER 120-230 V... -
Page 17: Programming
Programming For correct programming, follow the instructions below in order Configure button type Address button modules III. Program user codes Configuring the button type to maintain during normal operation (single/dual) DIP 6: configuring button type: Single button (DIP6 ON). default Dual button (DIP6 OFF, default). -
Page 18: Programming Consecutive Smart User Codes
Programming consecutive smart user codes default DIP 6: configuring button type: Single button (DIP6 ON). Dual button (DIP6 OFF, default). BEFORE you proceed: Set the user code of the apartment S1 S2 ALL DIP-switches to OFF, including you wish to call (for example: 1) DIP 6. -
Page 19: Programming Specific User Codes
Programming specific user codes default DIP 6: configuring button type: Single button (DIP6 ON). Dual button (DIP6 OFF, default). BEFORE you proceed: Set the user code of the apartment you wish to call (for example: 25) S1 S2 ALL DIP-switches to OFF, including using the DIP-switches (see Table of DIP 6. -
Page 20: Special Programming Via Dip Switch
Special programming via DIP Switch S1 S2 Make a note of the DIP-switch settings BEFORE you proceed: ALL DIP-switches to OFF, including 1. Set the dip switches DIP 6. in accordance with the function you wish to program (see Special programming table). -
Page 21: Special Programming Table
Special programming table CODE DIP SWITCHES ON FUNCTIONS Audio-visual messages 1,7,8 Czech 1,2,7,8 Hebrew 3,7,8 Polish 1,3,7,8 Catalan 2,3,7,8 Galician 1,2,3,7,8 Basque 2,3,4,7,8 Danish 1,2,3,4,7,8 Norwegian 1,2,5,7,8 Swedish 1,2,3,5,7,8 Italian 4,5,7,8 French 1,4,5,7,8 Spanish 2,4,5,7,8 Dutch 1,2,4,5,7,8 Greek 3,4,5,7,8 English 1,3,4,5,7,8 German 2,3,4,5,7,8... - Page 22 2,4,5,8 System busy signalling time: 10 sec (default) 1,2,4,5,8 System busy signalling time: 300 sec 1,2,3,4,6,7,8 Confirmation tone on user call = enabled (default) 5,6,7,8 Confirmation tone on user call = disabled 1,2,5,6,7,8 Reset wait time (after hang-up or after lock-release): 10 sec (default) 3,5,6,7,8 Reset wait time (after hang-up or after lock-release): 1 sec 5,7,8...
-
Page 23: Twilight Sensor
Twilight sensor Button backlighting management The twilight sensor is in AUTO mode by default: the button LEDs light up at night and switch off during the day. To change the setting to ON (LEDs always on) or OFF Take note of the DIP-switch (LEDs always off), proceed settings as follows:... -
Page 24: Checking Twilight Sensor Operation
S1 S2 Reset the configuration of the DIP-switches Checking twilight sensor operation S1 S2 S1 S2 5 sec 5 sec If it is daytime and you want to check AUTO mode operation for the twilight sensor, you can proceed as follows: 1. -
Page 25: Adjusting The Brightness Of The Button Leds
Adjusting the brightness of the button LEDs S1 S2 Take note of the DIP-switch settings BEFORE you proceed: 1. Enable brightness control ALL DIP-switches to OFF, including DIP 6. 2. Set the desired function (code 161) and press the confirm cod. -
Page 26: Light-Me Function
Light-me function Thanks to this function, button backlighting is only enabled on the user’s request, by pressing the LIGHT-ME button on the audio module; this saves energy and reduces light pollution. Backlighting management for this button depends on the twilight sensor setting. It is in AUTO mode by default: the LEDs light up at night and switch off during the day. -
Page 27: Replacing The Audio Module With Programming Restore Backup
Replacing the audio module with programming restore backup If the audio module is replaced, the following instructions must be observed. The procedure should be completed within one hour of removal of the old module. Make a note of the DIP-switch settings Wait for 90 seconds Enter programming mode by moving S2 DIP-switch upwards... -
Page 28: Configuring Via Pc
Configuring via PC All device configurations can be implemented via PC and ViP Manager configuration software, which is available to download free of charge from the website pro.comelitgroup.com (See programming manual) For example: • programming the user codes associated with the buttons •... -
Page 29: System Functions
System functions 2708W/A 2708W/A 2719W 2719W 2708W/A 2708W/A 1595 1595 UT1010 UT1010 Operating distances A MAX B MAX E MAX 1 mm² (Ø 1.2 mm AWG 17) 50 m 500 m 30 m (165 feet) (1625 feet) (98 feet) 0.28 mm² (Ø 0.6 mm AWG 23) 300 m (15 feet) (990 feet) -
Page 30: Maximum System Expansion
Maximum system expansion Devices 2708W/A 2719W Maximum number of door-entry phones that can be powered from art. 1595 with 100 door-entry phones the audio sound level is 74dB(A), with 75 door-entry phones there is a greater audio sound level of 77dB(A) Maximum expansion per apartment Devices 2708W/A... -
Page 31: Wiring Diagrams
Wiring diagrams 2708W/A 2719W 2708W/A 1595 120-230 V 12 VAC/VDC 18 Ω MAX NO NC UT1010 UT9200 (MAX 25) Max 20 m. Local door-opener button. -
Page 32: System Performance And Layouts
1200 1200 230V~ 12V~ 230V~ 12V~ 1 2 3 4 1 2 3 4 1224A 1224A 1 2 3 4 1 2 3 4 1595 1595 120-230 V 120-230 V 12 VAC/VDC 12 VAC/VDC 18 Ω MAX 18 Ω MAX NO NC NO NC UT1010 UT9200... -
Page 33: Table Of User Codes
Table of user codes Code DIP-switch 1,4,6 1,5,7 1,4,5,6,7 1,6,8 1,4,7,8 2,4,6 2,5,7 2,4,5,6,7 2,6,8 2,4,7,8 1,2,4,6 1,2,5,7 1,2,4,5,6,7 1,2,6,8 1,2,4,7,8 3,4,6 3,5,7 3,4,5,6,7 3,6,8 3,4,7,8 1,3,4,6 1,3,5,7 1,3,4,5,6,7 1,3,6,8 1,3,4,7,8 2,3,4,6 2,3,5,7 2,3,4,5,6,7 2,3,6,8 2,3,4,7,8 1,2,3 1,2,3,4,6 1,2,3,5,7 1,2,3,4,5,6,7 1,2,3,6,8 1,2,3,4,7,8 4,5,7... - Page 34 C E R T I F I E D M A N A G E M E N T S Y S T E M S w w w . c o m e l i t g r o u p . c o m Via Don Arrigoni, 5 - 24020 Rovetta (BG) - Italy...
