Blaupunkt AHDC-1.1 Operating And Installation Instructions

Reverse camera

REVERSE CAMERA

AHDC-1.1

Operating and Installation Instructions

Table of Contents

Need help?

Do you have a question about the AHDC-1.1 and is the answer not in the manual?

Page 1 REVERSE CAMERA AHDC-1.1 Operating and Installation Instructions...
Page 2 Disclaimer In no event shall Blaupunkt be liable for any Attentions direct, indirect, punitive, incidental, special consequential damages to property or life •...
Page 3 SPECIFICATION Features AHDC-1.1 CMOS Image Sensor  PAL TV System  E ective Pixels 1280 (H) x 720 (V) 750TVL Image Resolution  25 Frame Per Second  Exposure & Gain Control  1/60~1/100000sec Elctronic Shutter  Auto White Balance ...
Page 4 INSTALLATION DIAGRAM INSTALLATION LOCATION Attentions • Remove protective lm from camera lens before use. • Take extra precautions when setting up the connection near petrol tank and wires. • Connect Red Wire with reverse light.
Page 5 INSTALLATION LOCATION...
Page 6 FRONT/REVERSE CAMERA LOCATION...
Page 7 TROUBLESHOOTING If any of the following problem occur, please resort to Troubleshooting for the possible solutions. Consult Blaupunkt authorized dealer if problem persist. Problem Solution Display monitor / car radio does not Restart the display monitor / car radio. show reverse view when reversing.
Page 8 Blaupunkt Car Entertainment - Asia Paci c Competence Centre 1 331 23 017 32 01...
