FUNCTIONAL DESCRIPTION

2
1. Tri-LEDs
2. 1/4" Hex drive chuck
3. Control switch
4. Trigger
5. Handle
6. Bit holder
7. Speed control
8. Belt clip
ASSEMBLY
Recharge only with the charger
WARNING
specified for the battery. For
specific charging
operator's manual supplied with your charger
and battery.
Inserting/Removing the Battery
To insert the battery, slide the pack into the body
of the tool. Make sure it latches securely into place.
To remove the battery, push in the release buttons
and pull the battery pack away from the tool.
Always lock the trigger or remove
WARNING
the battery pack
is not in use.
Only use
WARNING
reco mmended
may be hazardous.
Use only sockets and other accessories
specifically designed
wrenches and drivers. Other sockets and
accessories might shatter or break causing
injury.
Attaching and Removing Accessories
This impact driver is intended for use with drill and
driver bits.
1. To attach an accessory, press the shank into the
hex drive chuck.
2. To remove the accessory, pull out the ring and
remove the accessory. Release the ring.
1
6
8
instructions, read
any time the tool
accessorie s
for thi s tool. Others
for use on impact
To learn more about the ONE-KEY™ functionality
for this tool, go to milwaukeetool.com/One-Key. To
download the ONE-KEY™ app, visit the App Store or
Google Play from your smart device.
Solid Blue
Blinking Blue
3
Blinking Red
4
5
WARNING
7
protection
AS/NZS 1337.1.
When working in dusty situations, wear
appropriate respiratory protection or use a
suitable dust extraction solution.
Using the Control Switch
The control switch may be set to three positions:
forward, reverse and lock. Due to a lockout mecha-
nism, the control switch can only be adjusted when
the ON/OFF switch is not pressed. Always allow the
motor to come to a complete stop before using the
control switch.
For forward (clockwise) rotation, push in the control
the
switch from the right side of the tool. Check the
direction of rotation before use.
For reverse (anticlockwise) rotation, push in the
control switch
direction of rotation before use.
To lock the trigger, push the control switch to the
centre position. The trigger will not work while the
control switch is in the centre locked position.
Always lock the trigger or remove the battery pack
before performing
accessories, storing the tool and any time the tool is
not in use.
Allow the tool to come to a complete stop before
changing speeds. Press the selector button
cycle between the settings.
Mode 1
RPM 0 - 1700
IPM 0 - 1400
Starting, Stopping and Controlling Speed
1.
To start the tool, grasp the handle(s) firmly and pull
the trigger.
NOTE: The TRI-LEDs are turned on when the
trigger is pulled and will go off shortly after the
trigger is released.
To vary the speed, increase or decrease the
2.
pressure on the trigger. The further the trigger is
pulled, the greater the speed.
3. To stop the tool, release the trigger. Ensure the
tool has come to a complete stop before laying the
tool down.
4
ONE-KEY™
ONE-KEY™ Indicator
Wireless mode is active and ready
to be configured
ONE-KEY™ app.
Tool is actively communicating with
the ONE-KEY™ app.
Tool is in security lockout and can
be unlocked by the owner via the
ONE-KEY™ app.

OPERATION

To reduce the risk of injury,
always wear
marked to comply
from the left side of the tool. Check
maintenance,
Selecting Speed
2 3
0 - 2450 0 - 3150
0 - 3000 0 - 3750
via the
proper eye
with
changing
to
4
0 - 3900
0 - 4400
