PASADENA ALCOVE SHOWER
INSTALLATION MANUAL | MANUEL D'INSTALLATION | MANUAL DE INSTALACIÓN
DOOR PANEL
PANNEAU DE PORTE
PANEL DE PUERTA
Questions, problems, need help?
Call our customer service department at
1-866-839-2888, 8 a.m. - 5 p.m., EST, Monday - Friday
Questions, problèmes ou besoin d'aide?
Contactez notre service à la clientèle au
1-866-839-2888, du lundi au vendredi de 8 h à 17 h HNE.
Preguntas, problemas o necesita ayuda?
Llame a nuestro departamento de servicio al cliente al
1-866-839-2888, 8 am. – 5 pm., HDE, Lunes a Viernes.
P. 1
2022-04-26
www.ovedecors.com | customerservice@ovedecors.com
Advertisement
Related Manuals for OVE PASADENA PA0600300
Summary of Contents for OVE PASADENA PA0600300
- Page 1 PASADENA ALCOVE SHOWER INSTALLATION MANUAL | MANUEL D’INSTALLATION | MANUAL DE INSTALACIÓN DOOR PANEL PANNEAU DE PORTE PANEL DE PUERTA Questions, problems, need help? Call our customer service department at 1-866-839-2888, 8 a.m. - 5 p.m., EST, Monday - Friday Questions, problèmes ou besoin d’aide? Contactez notre service à...
- Page 2 SHOWER DIMENSIONS DIMENSIONS DE LA DOUCHE DIMENSIONES DE LA DUCHA Measurements Rule of Measure Mesures Règle de la mesure Medidas Regla de medida Shower width Distance from the leftmost edge of the shower to the rightmost edge Largeur de la douche Distance de l’extremité...
- Page 3 SHOWER DIMENSIONS DIMENSIONS DE LA DOUCHE DIMENSIONES DE LA DUCHA DIM D DIM W DIM DP DIM O Measures: inch [millimeter] Mesures: pouce [millimètre] Medidas: pulgadas [milímetros] P. 3...
- Page 4 INSTALLATION STRUCTURE OVERVIEW VUE D’ENSEMBLE DE LA STRUCTURE D’INSTALLATION VISIÓN GENERAL DE LA ESTRUCTURA DE INSTALACIÓN 1. Before you start the installation of your product consult the illustration 1 below showing a side-view of the completed installation. 2. Illustration 2 shows the recommended wall structure and measurements for the product installation. NOTE: Customer must follow and comply with the local and national building and plumbing codes.
- Page 5 PACKAGE CONTENT CONTENU DE L’EMBALLAGE CONTENIDO DEL PAQUETE P. 5...
- Page 6 PACKAGE CONTENT CONTENU DE L’EMBALLAGE CONTENIDO DEL PAQUETE P. 6...
- Page 7 PART LIST LISTE DES PIÈCES LISTA DE PIEZAS PART # DESCRIPTION QUANTITY CODE # DE PIÈCE DESCRIPTION QUANTITÉ CODE PARTE # DESCRIPCIÓN CANTIDAD CÓDIO Oil Rubbed Bronze: 99STR3865-WM Wall track (Door Panel) Chrome: 99STR3859-WM Glissière (Panneau de Porte) Satin Nickel: 99STR3871-WM Riel de la pared (Panel de Puerta) Black: 99STR3865-WM Oil Rubbed Bronze: 99STR3877-WM...
- Page 8 SUPPLIED HARDWARE LIST QUINCAILLERIE FOURNIE CONTENIDO DE HARDWARE Wall Anchor Screw Screw Fitting Ancrage mural Raccord Tarugo Tornillo Tornillo Accesorio ø8x30mm ST5x30mm ST4x12mm Allen key Capuchon Clé Allen Capuchón Llave Allen 2.5mm TOOLS REQUIRED (not supplied) OUTILS REQUIS (non fournis) HERRAMIENTAS NECESARIAS (no incluido) Drill and drill bits Pencil...
- Page 9 REVERSIBILITY RÉVERSIBILITÉ REVERSIBILIDAD This instruction is drawn up for a door opening from right to left (see illustration A). For an installation for a door opening from left to right (see illustration B), use the same instructions, but switch around the panels: mirror effect. Utilisez ces instructions pour une ouverture de la porte de droite à...
- Page 10 SAFETY INFORMATION INFORMATION SUR LA SÉCURITÉ INFORMACIÓN DE SEGURIDAD CAUTION Please carefully read the following important safety information before handling or installing this shower. There is a risk of serious injury while handling this product. To minimize these risks, please note: •...
- Page 11 SAFETY NOTICE AVIS DE SÉCURITÉ AVISOS DE SEGURIDAD NOTICE Any modification or alteration from what is specified in this instruction manual will void any and all warranty on this product. The distributor is not responsible for any damage to the unit or personal property caused by improper installation. If you disregard instructional warnings, you will void your warranty and possibly deal with water damage.
- Page 12 WALL TRACK INSTALLATION INSTALLATION DE LA GLISSIÈRE INSTALACIÓN DEL RIEL DE PARED 1.1-1.2. Position the wall track (A) as illustrated. Level the track (A) and mark the track holes positions. 1.3. Remove the track and drill pilot holes in the marked locations with a ø5/16” (8mm) drill bit. 1.4.
- Page 13 SHOWER DOOR INSTALLATION INSTALLATION DE LA PORTE DE DOUCHE INSTALACION DE LA PUERTA DE DUCHA 2.1. Apply a clear silicone to the pivot profile (B). 2.2-2.3. Insert the door panel (C) into the pivot profile (B), making sure the top edge of the door panel (C) is flush to the top of the pivot profile (B), as well as the entire side of the panel being snug in the pivot profile.
- Page 14 SHOWER DOOR INSTALLATION INSTALLATION DE LA PORTE DE DOUCHE INSTALACION DE LA PUERTA DE DUCHA 3.1. Insert the door bottom seal strip (E) into the door panel (C). 3.2. Insert the pivot profile (B) into the wall track (A). 3.1. Insérez le bande d’étanchéité du bas de la porte (E) sur la porte (C). 3.2.
- Page 15 SHOWER DOOR INSTALLATION INSTALLATION DE LA PORTE DE DOUCHE INSTALACION DE LA PUERTA DE DUCHA 4.1-4.2. Insert the magnetic strip (F) on the door panel (C). 4.3 Insert the wall track (H) into the magnetic track (G), place the magnetic track (G) to the magnetic strip (F). 4.4 Close the door, level the wall track (H) and mark the position of it to the wall.
- Page 16 SHOWER DOOR INSTALLATION INSTALLATION DE LA PORTE DE DOUCHE INSTALACION DE LA PUERTA DE DUCHA 5.1 Place the wall track (H) back on its wall mark. Level the track (H) and mark the track holes positions. 5.2. Remove the track and drill pilot holes in the marked locations with a ø5/16” (8mm) drill bit. 5.3.
- Page 17 HANDLE INSTALLATION INSTALLATION DE LA POIGNÉE INSTALACIÓN DE LA MANIJA 6.1-6.2. Secure the door panel (C) by drilling guide holes through the wall track (A) and screwing it in place using fittings (DD), screws (CC) and caps (EE). Measure approximately 3” 15/16 (100mm) from the top and bottom, and at the center height of the wall track (A). 6.3-6.4.
- Page 18 SEALING SCELLAGE SELLADO Ensure that the door closes tightly and opens smoothly. Ensure that there is a firm connection between the fixed panel(s) and the support bar. Apply a clear silicone water sealant around the outside perimeter of any fixed shower components. Allow 24 hours for silicone to dry. Improper application of silicone sealant may cause your shower to leak.
- Page 19 MAINTENANCE AND CARE ENTRETIEN ET MAINTENANCE MANTENIMIENTO Y CUIDADO For daily maintenance, use a wet cloth and a soft liquid cleaner on all glass and acrylic surfaces. Doing so will prevent soap or hard water buildups that can etch the glass or acrylic surface over time if left to dry. Never use abrasive cleaners containing some acetone, chlorine or strong bleach, scrapers, metallic brushes, nor other objects or the products which can graze or tarnish surfaces.
- Page 20 LIMITED Product Warranty The DISTRIBUTOR is a distributor of the following Products: • Shower Doors (warranty period 5 years). • Acrylic Surfaces (warranty period 5 years against blistering, cracking or chipping in the acrylic surface). • Acrylic Shell Structure (warranty period 5 years against loss of water through fiberglass laminate of the acrylic body). •...
- Page 21 ANNEX GUIDELINES UTILISATION DE L’ANNEXE USO DEL ANEXO HOW TO USE THE ANNEX TO FIND ADEQUATE DIMENSIONS The dimensions provided in the tables of this ANNEX will vary based on the exact configuration of the shower kit you purchased. Refer to the dimensions fitting for your shower configuration.
- Page 22 ANNEX DIMENSIONS DRAWINGS DESSINS DE DIMENSIONS POUR ANNEXE DIBUJOS DIMENSIONALES DEL ANEXO DIM DP DIM O DIM D DIM W Finished Wall Surface Measure this dimension from the finished wall to the center of your wall track. Surface du mur fini DIM X Mesurez cette dimension à...
- Page 23 ANNEX IMPERIAL MEASUREMENTS (INCHES) ANNEXE MESURES IMPÉRIALES (POUCES) ANEXO MEDIDAS IMPERIALES (PULGADAS) CONFIG BASE PA0500*0* DPC25 (25 3/8in) 29 3/8 1 5/16 29 3/8 25 3/8 13 3/4 NB1* PA0600*F* DPC29 (29in) 34x32x2 3/4in 31 5/8 74 3/4 31 1/8 32 3/16 13 3/4 29 13/16...
- Page 24 ANNEX METRIC MEASUREMENTS (MILLIMETERS) ANNEXE MESURES MÉTRIQUES (MILLIMÈTRES) ANEXO MEDIDAS MÉTRICAS (MILÍMETROS) CONFIG BASE PA0500*0* DPC25 (645mm) 1829 1829 NB1* PA0600*F* DPC29 (737mm) 864x813x70mm 1899 1829 PA0600*0* DPC29 (737mm) 1829 1829 NB1* Note: The * character in the Configuration ID can be replaced by any alphanumerical character. It can be skipped while matching your ID to this table. Note: Le charactère * dans le Configuration ID peut être remplacé...
