- Page 1 Product instruction Manual...
- Page 2 Product User Manual iVEX-PL Series Notice on Copyright and Trademark Usage Products and company names mentioned in this manual are trademarks or registered trademarks belonging to the company. WARRANTY If the product is not normally installed due to a defect under normal use conditions, The manufacturer will repair it free of charge through the place of purchase.
- Page 3 Outline Index PC System Recommended Specifications • Component information * CPU: Intel Core 2 Duo 2.4 GHz or higher (when using 1920x1080 30fps) Intel Core i7 2.8 GHz or higher (when using 1920x1080 60fps) • Product classification and part names * Resolution: 1280x1024 or higher (32-bit color) •...
-
Page 4: Component Information
Component information Before starting the installation, carefully check the following components enclosed in the product box to ensure that no parts are missing during installation. Basic Components Optional components (purchased separately) Picture Explanation Picture Explanation Picture Explanation Picture Explanation L-Wrench set Hex Bolt Set Sealing (M5,M4,M3,... - Page 5 Product division and part names Please familiarize yourself with the part names of each product as they are important to provide fast and accurate service for problems in each part. iVEX-PL-30 Series Round Type Straight Type Front Cover Front Cover Series Detailed name Detailed name...
- Page 6 Product division and part names Please familiarize yourself with the part names of each product as they are important to provide fast and accurate service for problems in each part. iVEX-PL-10 Series GE Glass + Protection Grid Straight front Round front Type cover Type cover Type...
-
Page 7: Safety Rules
About the contents of the manual Please read the product user manual carefully before installing and using this product, and keep the manual in a separate place for future reference. Safety rules 3. Work attention 1. Explosive hazard - This product complies with applicable standard code EN/IEC 60079-14, EN/IEC 60079-17, etc. - Confirm that the installation method meets the explosion-proof regulations and specifications. - Page 8 Identification method Product specification inspection [ENG Ver.] [KOR Ver.] Explosion Proof Certification Label Description Precautions Manufacturer and address Model name Serial number: 10 digits of product model code – 2 digits for production year and month – consists of manufacturing serial number Operating temperature: Ambient temperature (-40˚C≤Ta≤+Tx˚C, -40˚C≤Ta≤Tx˚C or Tx˚C) T Class (Tx or Tx...
- Page 9 Identification method Product Certification Number Inspection Cable gland inspection • Manufacture : Shinhwa Industrial Electric. Certification IVEX-PL-1X Series Certification Number • Entry threads : NPT 1/2”-14 According to ANSI/ASME B1.20.1 • Model No : ECG • Protection type : Ex d ⅡC, IP65 IECEx IECEx DEK 15.0030X •...
-
Page 10: Checklist Before Product Installation
Checklist before product installation Check product operation information and appearance status Check the specifications of the L wrench [IVEX-PL-30] [Box] [IVEX-PL-10] * On the product label on the product packaging box and on the tag on the sunshield portion of the product After checking the information necessary for initial operation such as IP address, ID, password, etc. - Page 11 Select product installation location When selecting a location to install the product, be sure to install it in a place that does not have any inconsistencies as in the case below. Things to consider when installing the product When selecting the initial location to install the product, consider the following. If the environment in which the product is installed is smaller than the bottom size of the product's mount bracket, there is a risk of the product falling, making it unsuitable for installation.
- Page 12 Product installation and precautions The manufacturer is not responsible for any problems caused by installing a bracket other than the genuine bracket provided by the manufacturer. Installation using the product's mount bracket Installation using wall mount brackets and ceiling brackets [Loctite 263] [Loctite 263] [Wall mount]...
- Page 13 Product installation and precautions The manufacturer is not responsible for product failure damage caused by lightning or surge caused by improper grounding of the product. Wall Bracket Usage Guide Ground (ground) installation • M5 copper tube terminal • Material: copper, tin alloy [WB-02 Use] [WB-01 Use] - When installing the two types of wall brackets provided by the manufacturer,...
- Page 14 Connect the product and explosion-proof installation materials in the order below. Connect the product and explosion-proof installation materials in the order below. IVEX-PL Series products IVEX-PL Series products (integrated explosion-proof armored cable) Elbow ( NPT ½” to NPT ½” ) Cable gland ( PF 22 ) Reducer ( NPT ½”...
- Page 15 Product installation and precautions When working with the network cable through the RJ-45 tool, it is essential to check through the tester as there is a possibility of network failure due to miswiring or operator error. Configuration diagram for each built-in cable Connection diagram between joint boxes [Joint box] [PoE Hub]...
-
Page 16: Periodic Cleaning
Maintenance after product installation When replacing or maintaining the camera, be sure to move to a safe area, not an explosion-proof area. Periodic cleaning Disassembly/assembly of products for inspection - Regular cleaning should be performed so that no more than 5mm of dust - After separating the sun shield and mount bracket as shown in disassemble the ring bracket and remove the bolts on the exterior. -
Page 17: Network Connection And Setup
Network Connection and Setup You can set the network environment of the camera according to the user's network connection configuration. Installing the camera directly in a LAN environment Installing the camera directly in a LAN environment External remote pc CAMERA CAMERA Internet External remote pc... - Page 18 Network Connection and Setup (IVEX-PL-10 Series) The IP address range of the user's computer and the IP address range of the camera must match for normal web viewer access. Using the IP Search program PC network settings depending on whether an IP sharer is used Network settings Network settings Control Panel >...
- Page 19 Network Connection and Setup (IVEX-PL-10 Series) Web viewer access can be checked in normal operation through Google Chrome and Microsoft Edge browsers. Change IP Settings in Web Viewer Web viewer access Please log in to access this site. Authorization required for HTTP://10.20.30.40 Your connection to this site is not secure.
- Page 20 Network Connection and Setup (IVEX-PL-10 Series) When setting RTSP, you must first check if the ‘554 PORT’ of the router is open. Firmware update method RTSP settings - Press the ‘ADMIN’ icon at the top of the web viewer to enter the SETUP menu. - Service: Set whether to use RTP/RTSP.
- Page 21 Network Connection and Setup (IVEX-PL-30 Series ) The IP address range of the user's computer and the IP address range of the camera must match for normal web viewer access. Using the IP Search program PC network settings depending on whether an IP sharer is used Network settings Control Panel >...
- Page 22 Network Connection and Setup (IVEX-PL-30 Series) Web viewer access can be checked in normal operation through Google Chrome and Microsoft Edge browsers. Change IP Settings in Web Viewer Web viewer access admin 1234 - If you press the ‘SETUP’ icon in - Run a web browser such as Chrome or Edge on the user's computer.
- Page 23 Network Connection and Setup (IVEX-PL-30 Series) When setting RTSP, you must first check if the ‘554 PORT’ of the router is open. Firmware update method RTSP settings - Press the ‘SETUP’ icon at the top of the web viewer to enter the SETUP menu. RTSP SECURITY : Set whether to use RTP/RTSP.
- Page 24 How to set OSD (IVEX-PL-30 Series – HD version) If you have purchased an analog output product with AHD output, please refer to this manual. How to set up the system OSD menu screen description - The main menu is composed of - This is a menu to select the video output format that is important for HD video.
- Page 25 Installation Inspection Check Sheet 1. When receiving the product, prior to on-site installation, be sure to perform on-site installation only when there is no problem after inspecting the pre-checklist according to the following order. 2. Please note that service measures may be charged for problems that occur during on-site delivery without prior checklist inspection. Checking list Check Remove the IP address tag attached to the product's mount bracket after installing and fixing the device.
- Page 26 Technical Drawing – PL Series Before/after product installation, refer to technical drawings to review site conditions. IVEX-PL-30 Series IVEX-PL-10 Series...
- Page 27 Technical Drawing – Mount Bracket Before/after product installation, refer to technical drawings to review site conditions. Wall mount bracket (IVEX-PL-10 Series) Wall mount bracket (IVEX-PL-30 Series)
- Page 28 Technical Drawing – Mount Bracket Before/after product installation, refer to technical drawings to review site conditions. Sealing bracket (IVEX-PL-30 Series)
- Page 29 Memo...
