- Page 1 OPERATING INSTRUCTIONS WIRELESS TUNER WT-770 Please follow the instructions in this manual to obtain the optimum results from this unit. We also recommend that you keep this manual handy for future reference. TOA Corporation...
-
Page 2: General Description
GENERAL DESCRIPTION The TOA WT-770 is a VHF high band tuner that permits simultaneous use of up to two optional wireless tuner modules WTU-770 and WTU-771. To ensure its reliability, the WT-770 employs a compressor/expander system noise reduction circuit to minimize the influence of hight-frequency noise generated from digital equipment such as personal computers and word processors as well as a combined noise/tone squelch circuit. -
Page 3: Front Panel
NOMENCLATURE [Front Panel] Power Switch Press this switch to turn power on. To turn power off, press this switch again. Power Indicator lights when the power is switched on. Power Indicator Tuner Receptacle Insert an optional tuner module WTU-770 or WTU- 771. - Page 4 TUNER MODULE INSTALLATION AND REPLACEMENT CAUTION These servicing instructions are for use by qualified personnel only. To avoid electric shock do not perform any servicing other than that contained in the Operating Instructions unless you are qualified to do so. Refer all servicing to qualified service personnel. 1.
- Page 5 If the microphone is equipped with a sensitivity control, adjust the control so that the level indicator lights yellow when spoken loud. CONNECTIONS When using with the 900 series amplifiers, connect the output of WT-770 with the following modules of 900 series. YW-600 : Direct mount type to the tuner. Requires no antenna cable.
-
Page 6: Installation Precautions
(when YW-620 is used.) 6.1 mm (0.24") 48m (160ft.) 7.4 mm (0.29") 48~70m (160~230 ft. ) 3 x 1 6 tapping screw WT-770 (Supplied with the MB-14) Fiber washer (Supplied with the MB-14) Mounting screw (Supplied with the MB-14) WT-770... -
Page 7: Block Diagram
OFF. The squelch circuit of TOA's wireless systems consists of both the tone and noise squelches, and is not actuated if only same RF carrier as the receiving frequency is received. It is so designed as to be actuated and output a signal only when the received RF carrier contains a very exact pre-determined tone frequency component. -
Page 8: Specifications
Approx. 2.2 kg (4.91 Ib.) Finish Panel : black Module and blank panel : resin (black) WT-770 equipped with WTU-770 or WTU-771 Receiving Frequency 169.445 MHz~171.905 MHz (FCC Part 90/USA) 174.250 MHz~215.250 MHz (FCC Part 74/USA,D.O.C/CANADA) 173.8 MHz~175.0 MHz (MPT1345/UK) 202.1 MHz~203.7 MHz (DOC 60/AUSTRALIA)
