- Page 1 4K Compatible Signage Player USDP-R1000SH/H Simplified User Manual June 16, 2021 Version 1.0 Copyright © 2021 MEDIAEDGE Corporation...
- Page 2 (Monday to Friday 10:00 to 12:00 and 13:00 to 17:00 *Closed on national and company-designated holidays) USDP-R1000SH/USDP-R1000H Included Items USDP-R1000SH/H main unit: 1 pc AC adapter, power cable: 1 each Remote control (with 2 AAA batteries) × 1 ...
- Page 3 This is a 4K UHD player that playback content files in the unit's internal storage, USB storage, or streams (data encoded in H.265, H.264, or MPEG-2) delivered by a server or live encoder. You can update the content via USB storage as well as over the network. MEDIAEDGE-SVS server USB memory Network camera...
- Page 4 ■ I-2-2. USDP-R1000SH/USDP-R1000H Front Side Power lamp Built-in storage lamp Information lamp Error lamp Remote control lamp [RIGHT/MENU/ENTER] key Idle lamp LCD screen [UP] key [DOWN] key Remote control receiver [PWR] key [LEFT/CANCEL] key [F2] key [F1] key Power lamp Built-in storage lamp Information lamp Error lamp...
- Page 5 (5) Remote control lamp ··························· Lights up upon receiving light from the remote control. (6) Not-in-Use lamp ································· Not used. (7) Remote control receiver ······················· It has a built-in infrared receiver for the remote control. (8) LCD screen ······································· Displays status and settings menu. (9) [UP] key ···········································...
- Page 6 (1) Power connector ···············This is a slot for connecting the AC adapter included in the package. *Do not use any product other than the AC adapter included in the package. (2) COM ······························Used for serial connections. (3) LAN ·······························This a slot for connecting the LAN cable. (4) SDI OUT 1/2 ····················3G/HD-SDI output terminal.
- Page 7 Speaker Monitor Analog voice LAN port LAN port AC adapter To output sound from the analog audio terminal ● Connect the USDP-R1000 to the monitor. ● You can select SDI/HDMI/analog audio output for the audio output in the settings. To listen to the sound through external speakers, set the audio output to analog audio output, and connect the speakers to the LINE OUT jack of the USDP-R1000 using an analog audio cable.
- Page 8 Shutdown Follow the method below to shutdown USDP-R1000: ● Press the POWER key on the remote control. ● Press the [PWR] key while holding down the [LEFT/CANCEL] key on the front panel. ● Select [5. SHUTDOWN] > [Power off] from the front panel settings menu. ●...
- Page 9 ● Select address] press IP address [RIGHT/MENU/ENTER] key. 000.000.000.000 ● Set the IP address. Use the [LEFT/CANCEL] and [RIGHT/MENU/ENTER] IP address 192.168.000.020 keys to change the number of digits and use the [UP] and [DOWN] keys to change the numbers. Press the RIGHT/MENU/ENTER key at the 12th digit to complete the IP address settings.
- Page 10 MEDIAEDGE Finder installed on the PC. Click the [PRESENTATION URL] of the detected USDP-R1000 to launch the browser. ＊ You can download MEDIAEDGE Finder from our website. In addition to USDP-R1000, HDMA-4100, MEDIAEDGE-STB4H, MEDIAEDGE LEB Pro2/Pro/Express/Recorder, MEDIAEDGE Decoder are detected.
- Page 11 ■ I-3-2. Display Settings I-3-2-1. Settings on Front Panel ● When USDP-R1000 starts up, the status is displayed as USDP-R1000SH shown on the right. STOP ● Press the [RIGHT/MENU/ENTER] key to switch to the MENU 1.VIDEO settings menu. ● Press the [RIGHT/MENU/ENTER] key. VIDEO 1.Video format ●...
- Page 12 I-4. Web Console Open USDP-R1000 in a web browser (Microsoft Edge, Internet Explorer 11, Google Chrome, or Mozilla Firefox that runs on Windows). If you do not know the IP address of the USDP-R1000, first go to Network Settings. Example: If the IPv4 address of USDP-R1000 is 192.168.0.20, enter the URL as follows: http://192.168.0.20 192.168.0.20 Enter the username and password when the following screen is displayed.
