Page 1 Signage Player corresponding to 4K USDP-R1000SH/H Operation Manual October 03, 2022 The 2.0th edition Copyright c 2021-2022 MEDIAEDGE Corporation...
Page 2 Revision history Versio Firmware Date Revised contents 1.0.x 2021/7/1 First edition 1.1.x 2021/11/30 The addition of HTML reproduction and a network setup with the remote control 2.0.x 2022/10/03 addition menu reproduction, Live Commander, and a HDMI-CEC function...
Page 3: Table Of Contents
II-2. The name and function of each part ............14 ■ II-2-1. The USDP-R1000SH /USDP-R1000H front ......... 14 ■ II-2-2. The back of USDP-R1000SH /USDP-R1000H main part ....... 17 ■ II-2-3. Remote control ................18 Connection of apparatus and a check of operation ..........21 ■...
Page 4 IV-1. Channel reproduction ................32 ■ IV-1-1. About channel mode ..............32 IV-2. Schedule reproduction ................35 ■ IV-2-1. About schedule reproduction ............35 ■ IV-2-2. DCM .................... 35 ■ IV-2-3. Filler reproduction ................. 35 ■ IV-2-4. Setup ..................36 V.
Page 5 ■ VII-3-3. Web control ................61 VII-4. Others ....................61 ■ VII-4-1. Remote serial ................61 ■ VII-4-2. Log .................... 62 VIII. Web console ....................64 VIII-1. The access method ................64 VIII-2. Status display ..................65 ■ VIII-2-1. Status ..................66 ■...
Page 6 ■ IX-2-5. NETWORK .................. 124 ■ IX-2-6. SYSTEM ..................126 ■ IX-2-7. INFORMATION ................127 ■ IX-2-8. SHUTDOWN ................127 X. Appendix ..................... 129 X-1. Updating control script ................129 ■ X-1-1. Outline ..................129 ■ X-1-2. Form ..................129 ■...
Page 7: Introduction
USDP-R1000 I. Introduction This chapter explains the matter I would like you to check before use of USDP-R1000, or a setup, and a matter to be careful. I-1. Notes at the time of this product being used Here, the matter to be careful when this customer support of a purchase.
Page 8 Operation manual It will not use, if thunder begins to socket, and contact the store or our sound. customer support of a purchase. Please touch neither a main part nor a plug. It becomes a cause of an electric shock. It does not put on an unstable place.
Page 9: Notes
■ About a trademark ■ About handling personal information ① MEDIAEDGE is a registered trademark of media edge incorporated company. We do not use a visitor's personal ② HDMI, High-Definition Multimedia information principle except...
Page 10 Operation manual the monitor of a computer, and the strong created the image/sound the capture stimulus and blink of light which are cannot be used without permission from a displayed footage. Having right holder on the Copyright Act other constitution in which it happens, also than being concerned...
Page 11: I-2. Before Use
■ About our homepage The latest information of our company including USDP-R1000 is sent in the homepage (https://www.mediaedge.co.jp). Since the newest driver, a utility, a product manual, FAQ, etc. are exhibited, you access our homepage by all means, and please utilize for it.
Page 12: I-3. Points Of Concern
Operation manual I-3. Points of concern ■ About the notation Priority shall be given to the actual employment method when there is difference by explanation of this book and the actual employment method. The product actual for convenience, illustration, and screen photograph of explanation may differ from each other.
Page 13: About Use Consent
Ø Buffering time becomes longer than a setup. Ø l (Only USDP-R1000SH) A SDI output has the following restrictions. Don't correspond to 4K output (12 G-SDI). Ø When a RGB output range is [0?255], it is not outputted by right luminosity or Ø...
Page 14 IPA font based on the IPA font license v1.0. Please ask the question about this case to our customer support. In addition, refer to the "open software license display" of the console screen menu lowest stage for use software. Media edge incorporated company FAX:078-265-1550 E-mail: support@mediaedge.co.jp Page8...
Page 15: About Usdp-R1000
USDP-R1000 II. About USDP-R1000 This chapter explains the outline of USDP-R1000, and the function of each part. II-1. An outline and the feature ■ II-1-1. The outline of USDP-R1000 These products are a contents file of storage with a built-in main part, or USB storage, a server, and 4K UHD player that reproduces the stream (H.
Page 16: Ii-1-2. The Feature Of Usdp-R1000
● More than one correspond to layout reproduction of contents. ● Carry the browser corresponding to HTML5. ● USDP-R1000SH corresponds to a SDI output and a HDMI output, and USDP-R 1000H corresponds to HDMI 2 output (clone output). ● Our cloud services (Marcus, Tsuitto sign, etc.) can cooperate.
Page 17: Ii-1-3. Renewable Contents
USDP-R1000 ■ II-1-3. Renewable contents II-1-3-1. Animation H. It corresponds to reproduction of the movie file and streaming which were curtailed by 265, H.264, or MPEG-2. A renewable file changes restriction according to the conditions of the contents reproduced simultaneously or others. Video ITU-T Rec.H.265 (ISO/IEC 23008-2 HEVC) The maximum resolution: 3840x2160...
Page 18 Operation manual II-1-3-3. Still picture It can expand and reduce to arbitrary ranges and can display a still picture. JPEG (Exif) Extension jpg, jpeg, png, gif, bmp Ø II-1-3-4. HTML The browser corresponding to HTML5 is carried. (What all the pages of HTML5 can display correctly is not guaranteed) Extension html, htm, asp...
Page 19: Ii-1-4. Correspondence Apparatus
MEDIAEDGE Encoder K1000S / 1000H SC6D0N1 AIO MEDIAEDGE LEB Pro2/Express2 ME-CLEB P4 MEDIAEDGE Server (SVS5 / IPTR-M1 / IPTR-M2 / IPTR-M3) (*) (*) Only relay of live Network camera H. Model corresponding to 264/H.265 (a maximum of 4K resolution) and RTSP/SRT Don't guarantee that it is correctly renewable with all the network cameras.
Page 20: Ii-2. The Name And Function Of Each Part
Operation manual II-2. The name and function of each part ■ II-2-1. The USDP-R1000SH /USDP-R1000H front USDP-R1000SH USDP-R1000H Page14...
Page 21 USDP-R1000 (1) Power supply…………… Display the state such as power indicator starting and a shutdown, follow. Putting-out-lights…… The power supply is not on. ² Green blink (every 0.5 second) ² It is under end or starting. Green lighting……… It is in operating state. ²...
Page 22 Operation manual Unusual lamp Detection of failure of equipment will light up and blink an unusual lamp. In this case, Please contact to our customer support. Page16...
Page 23: Ii-2-2. The Back Of Usdp-R1000Sh /Usdp-R1000H Main Part
SDI OUT terminal. ※ The SDI output is not equivalent to 4K output (12 G-SDI). (5) HDMI OUT………………… · It is a HDMI output terminal. (Only USDP-R1000SH) ※ Video and an audio are simultaneously outputted to a HDMI OUT terminal.
Page 24: Ii-2-3. Remote Control
Operation manual (7) LINE OUT ………………… · It is an analog audio output. (8) MIC IN……………………… It is a mike input terminal. (9) USB 3.0USB ………………. It is a terminal which connects USB storage. As for the upper part, USB1 and the lower part are recognized as USB2.
Page 25 USDP-R1000 A part of functions which can be operated with the remote control can be validated / cancelled by setup. ID setup ID setup of a remote control is performed by DIPSW in a battery case. 0 (initial state), 1-4 turn ON the switch of each number in the state where all the switches are come by off.
Page 26 Operation manual ※ ID of a remote control is a setup of a main part. (Refer to remote control) ※ Output the same remote control signal as 0 andb0 of remote control ID, 1 andb1, 2 andb2, 3 andb4, and 4 andb8. It will not operate, if ID of the remote control differs from ID set up by the main part.
Page 27: Connection Of Apparatus And A Check Of Operation
USDP-R1000 Connection of apparatus and a check of operation ■ II-2-4. Connection of apparatus Please connect USDP-R1000 and peripheral equipment to reference for the following examples of connection (in the case of USDP-R 1000H). When sound is taken out from HDMI When sound is taken out from an analog voice terminal Page21...
Page 28: Ii-2-5. Starting And A Shutdown
● Press the (POWER) key of the remote control. ● Press the [PWR] key, pressing the left / the [CANCEL] key of a front panel. If this machine carries out the completion of starting, a power USDP-R1000SH STOP indicator will light up green. Moreover, a liquid crystal display becomes a status display like the right.
Page 29: Ii-3. Initial Setting
II-3. Initial setting ■ II-3-1. Network setup II-3-1-1. A setup by a front panel ● If USDP-R1000 starts, it will become a status display USDP-R1000SH STOP like the right. ● [The right/MENU/ENTER] A key is pressed and change MENU to a setting menu.
Page 30 Operation manual ● The [bottom] key is pressed, and [Manual] is chosen Manual setting and press the right / the [MENU/ENTER] key. 1.IP address ● [1. IP address] is chosen and press the right / the IP address [MENU/ENTER] key. 000.000.000.000.
Page 31 USDP-R1000 ● If [Yes] is chosen and the right / the [MENU/ENTER] Reboot... key is pressed, a setup will be saved and USDP-R1000 will reboot. If [No] is chosen and the right / the [MENU/ENTER] key is pressed, a setup will be canceled and will return to a status display.
Page 32 Operation manual (DHCP), DNS should attach a check to [Obtain DNS server address automatically]. Preservation of a setup For saving a setup, a cursor is moved to [Save] under a screen, and the (OK) key is pressed. When USDP- R1000 need to be rebooted, it is "Settings requires rebooting the system. It is displayed as Proceed anyway?."...
Page 33 MEDIAEDGE Finder installed in PC. If it clicks [PRESENTATION URL] of detected USDP-R1000, a browser will rise. ※ MEDIAEDGE Finder is downloadable from our homepage. USDP-R5000 S/R2200 S/R 2000S, USDP-R 500H, and MEDIAEDGE LEB Pro2/Express2/MEDIAEDGE Decoder/Decoder EX other than USDP-R1000 are detected.
Page 34: Ii-3-2. Display Setup
Operation manual ■ II-3-2. Display setup II-3-2-1. A setup by a front panel ● If USDP-R1000 starts, it will become a status display USDP-R1000SH STOP like the right. ● [The right/MENU/ENTER] A key is pressed and change MENU 1.VIDEO to a setting menu.
Page 35 USDP-R1000 ● A [top]/[the bottom] key is pressed, and a proper VIDEO video output setup is chosen and press the right / the 1.Video format [MENU/ENTER] key. ● Press the left / the [CANCEL] key until a right screen Save config ? is displayed.
Page 36: Streaming Reproduction
Operation manual III. Streaming reproduction This chapter explains how to connect USDP-R1000 to MEDIAEDGE Server and MEDIAEDGE LEB, and reproduce a file and a live image by streaming. III-1. Outline ■ III-1-1. About streaming reproduction USDP-R1000 supports streaming by RTSP/RTP, SRT, HLS, and UDP, and is reproduced by receiving the stream sent out from LEB Pro2/Express2, K1000 S/K 1000H, SC6D0N1, and ME-CLEB P4.
Page 37: Iii-1-1. The State Check Of Streaming Reproduction
USDP-R1000 ■ III-1-1. The state check of streaming reproduction While USDP-R1000 plays streaming, in-stream playback-related information can be checked on the state screen of the video of the status display -> playback state -> main window of a Web console screen. ■...
Page 38: Channel Mode
Operation manual IV. Channel mode This chapter explains how to reproduce a file from the storage linked to USDP-R1000. IV-1. Channel reproduction ■ IV-1-1. About channel mode [home] and [1] Contents can be registered into a maximum of 999 channels of - [999], and it can choose and reproduce with the remote control.
Page 39 3. It is direct description about the contents to reproduce. (Example) file:///drives/default/Contents/Sample.mp4 The specified contents (Sample.mp4) are reproduced. 4. Stream URL distributed by the MEDIAEDGE server is described. (Example) rtsp://MEDIAEDGE-SVR/Content01 The specified contents (Content01) are reproduced. 5. Stream URL distributed from LEB Pro2/Express2 is described.
Page 40 Operation manual The live image of specified SC6D0N1 is reproduced. 8. Stream URL distributed from CLEB-P4 is described. (Example) When udp://SVS1 is specified: rtsp:// [IP address] /Content_Relay_1 When udp://SVS2 is specified: rtsp:// [IP address] /Content_Relay_2 The specified CLEB-P4 live image is reproduced. 9.
Page 41: Iv-2. Schedule Reproduction
When an error occurs in reproduction of a schedule file, it is possible to reproduce specific contents. In MEDIAEDGE, the contents reproduced at this time are called a filler file and filler contents. Moreover, it calls it filler reproduction to reproduce a filler file.
Page 42: Iv-2-4. Setup
Operation manual ■ IV-2-4. Setup IV-2-4-1. Detailed setup [Basic setup] > [Write-in authority of a drive] Please set the drive selected by the [default drive] of the basic setup as a [lead light]. [Network] > [Cooperation with service] When the user name and password of the attestation account on a DCM server are changed from the rated value, please set up a new user name and password.
Page 43: Menu Reproduction
USDP-R1000 V. Menu reproduction V-1. Automatic generation menu ■ V-1-1. About an automatic generation menu Based on the folder of a drive and the contents of a file which were specified, the menu divided by class for every folder is created automatically, and is displayed. If a folder is chosen from a remote control, a class will be moved, and reproduction will be started if contents are chosen.
Page 44 Operation manual The form of content.info The form of a file A contents file name / character string of a name to change It comes to be alike. Example Content01.m2t /, Statue of Liberty Content01-HD.m2t /, snowcap Please describe a file name and the name to change by UTF-8. Page38...
Page 45: V-2. User Menu
USDP-R1000 V-2. User menu A menu can be used not using the menu generated automatically but using the menu file created externally. V-3. Screen saver When there is no operation for a definite period of time at a menu mode, it is possible to display a screen saver.
Page 46: V-4-2. In The Case Of A User Menu
Operation manual ■ V-4-2. In the case of a user menu When the created menu is used, access to Web console and after setting Time zone, date and time settings, network from preferences, please come out and choose "a local drive (user menu)"...
Page 47: Serial Control Reproduction
USDP-R1000 VI. Serial control reproduction This chapter explains how to reproduce a file from the storage connected to USDP-R1000 using serial control commands. VI-1. About serial control mode Serial control mode is the mode which performs reproduction control with a serial port or the control commands from a network.
Page 48: Vi-2. Setup
Operation manual VI-2. Setup The following setup is performed from a Web console, and a [setting] button is pushed and saved. 1. [Setup] > [Basic setup] Choose [serial control mode] by [operational mode]. Ø 2. [Setup] > [Serial control mode] Choose the drive used for reproduction by [contents drive].
Page 49: Vi-4. Arrangement Of Contents
USDP-R1000 VI-4. Arrangement of contents It is necessary to arrange beforehand the movie file reproduced by serial control mode in a contents folder. A contents folder is [a setup] of a Web console. > It is determined by [a contents drive] and the [contents folder path] which were specified by [serial control mode].
Page 50 Operation manual title03.mpg Page44...
Page 51: Vi-5. The Initial State Of Serial Control Mode
USDP-R1000 VI-5. The initial state of serial control mode Current position: The title 1, chapter 1 Address mode: Title specification Repeat mode: Don't repeat. Reproduction state: Stop VI-6. The control method A command is published to a serial port or a network serial control port. Refer to "a correspondence command list"...
Page 52: Vi-7. Correspondence Command List
Operation manual VI-7. Correspondence command list Pioneer LD/DVD compatible command <arg> expresses the parameter of a command. (arg) is omissible. An address (a title number or a chapter number) is specified as <adrs>. (adrs) is omissible. Command Explanation An address mode is made into a title. An address mode is made into a chapter.
Page 53 USDP-R1000 1: Mute Release <arg>AD an audio setup (support) [ try ] 0: Mute 3: Mute Release 4: Mute (arg)RJ Reproduction is stopped and a stop marker and repeat mode are canceled. ※ In the rotation stop of HDD, it is un-corresponding. An argument ignores.
Page 54 Operation manual The error code (R is included) returned at the end is returned. A model name (USDP-R1000) is returned. Time (form: YYMMDDWWhhmmss) is returned. * YY : they are mm:minute and ss:second at the time of year, MM:moon, DD:day, WW:day-of-the-week (moon: 00 - day : 06), and hh:.
Page 55 USDP-R1000 Original extended command <arg> expresses the parameter of a command. (arg) is omissible. An address (a title number or a chapter number) is specified as <adrs>. (adrs) is omissible. Command Explanation Reproduction is stopped (a black screen is used). <adrs>MV It moves to the address position specified by the halt condition.
Page 56: Vi-8. Error Code List
The path of the folder which stored the contents for reproduction. [Setup] of a Web console > [Serial control mode] > It sets up with a [contents folder path] (initial value: MEDIAEDGE/_Serial). VI-8. Error code list The next response returns to a command.
Page 57: A Function And Operation
USDP-R1000 VII. A function and operation This chapter explains functions, such as the updating method of contents, and a remote serial. VII-1. Renewal of contents ■ VII-1-1. About updating There are two or more following methods in copying contents required for reproduction, a schedule file, etc.
Page 58 Operation manual Write-in authority of a drive The drive which transmits contents is set as a [lead light]. It is satisfactory whichever it has set to about the drive which is not used. VII-1-2-2. Network For the detailed setting method, please refer to Network settings.
Page 59: Vii-1-3. File Sharing
USDP-R1000 DCM is chosen. DCM server Set up a DCM server's address, and the port address (it is necessary to unite with a setup of DCM) to be used.To connect it with the DCM server which is outside, it is necessary to set up so that a router etc.
Page 60: Vii-1-4. Renewal Of Contents Via Usb Storage
Account Set a preset value to the account at the time of connecting with a share drive. As for [mediaedge] and a password, as for the initial value, the user name is not set Share drive authority Set up authority shared to each drive.The drive will not be shared if it sets up invalid.
Page 61: Vii-1-5. Write In Usb Storage Directly
■ VII-2-1. About Live Commander By connecting Elgato Stream Deck (the customizable LCD key) to the USB port of USDP- R1000, external control of control and other MEDIAEDGE Decoder of USDP-R1000, the USDP series products, etc. can be carried out.
Page 62: Vii-2-3. Configuration File
Operation manual 4. Since internal_HDD\MEDIAEDGE\_LiveCommander is created if a shared folder is opened by Windows PC etc., copy files, such as png relevant to stream_deck.xlsx, to this folder. 5. Check operating, if an icon is displayed on Stream Deck by the contents currently written to stream_deck.xlsx and a button is pushed.
Page 63 USDP-R1000 png file 40x40 Pixel - a 120x120 Pixel grade are suitable for an icon. Ÿ The character string can use ASCII, a number, and a sign (a Chinese Ÿ character and a pictorial symbol un-corresponding). List When controlling for oneself, specify it as "localhost". Ÿ...
Page 64 Operation manual VII-2-3-2. About the display of a button Display the character currently written to the image and Text of the file specified by Icon of the line specified by Page, Key, and Mode. An image is not drawn when there is no file specified when there was no Ÿ...
Page 65 Only in the case of one, a direct IP address can be specified for an addressee. Command and Argument: The script file name performed when a button is pushed, and an application a name and argument VII-2-3-5. The standard command according to model MEDIAEDGE Decoder and USDP series Command Argument Function #channel_change...
Page 66: Vii-3. Network
UPnP (Universal Plug and Play) is a protocol which detects automatically and acquires information, when apparatus is connected to a network. In MEDIAEDGE Finder or Windows 10, UPnP is used and the apparatus corresponding to UPnP, such as USDP-R1000 in the same network, is detected.
Page 67: Vii-3-3. Web Control
USDP-R1000 ■ VII-3-3. Web control Web control offers the function for performing reproduction control of USDP-R1000, and remote control operation from web browsers, such as PC, a tablet, and a smart phone. * In order to perform reproduction control of USDP-R1000 from a web browser using this function, please create HTML of a menu screen, JavaScript for control, etc.
Page 68: Vii-4-2. Log
Operation manual ■ VII-4-2. Log USDP-R1000 holds the log of reproduction, or a file transfer and the error which occurred in a main part, and displays it on the "status display" screen of a Web console. Moreover, reading from the exterior using Web API is also possible. The log currently held inside will be automatically deleted from an old thing, if a fixed quantity is exceeded.
Page 69 USDP-R1000 Page63...
Page 70: Web Console
Operation manual VIII. Web console From PC, if USDP-R1000 is accessed by a web browser, a setup and operation by a Web console can be performed to it. This chapter explains operation and a setup of a Web console. VIII-1. The access method Please open USDP-R1000 by a web browser (Microsoft Edge which operates on Windows, Internet Explorer 11, Google Chrome, Mozilla Firefox).
Page 71: Viii-2. Status Display
USDP-R1000 VIII-2. Status display The state and log of USDP-R1000 can be checked on this screen. The next screen will be displayed if a status display screen is opened. The display of status, a log, etc. can be changed from the selection box of the [display classification] of the upper part of a screen.
Page 72: Viii-2-1. Status
Operation manual ■ VIII-2-1. Status The present operating state of USDP-R1000 is displayed. VIII-2-1-1. The state of apparatus CPU usage rate Ø The usage rate of CPU is displayed. Memory availability Ø The remaining capacity of the memory which can be used is displayed. Used memory capacity Ø...
Page 73 MAC Address Ø The MAC Address of a LAN port is displayed. Ø In USDP-R1000SH, in "Exist" and USDP-R 1000H, it is displayed as "none." Ø A fan's loading condition is shown. It is displayed as "Exist." Ø The detection situation of an uninterruptible power supply (UPS) is displayed.
Page 74 Operation manual AC input to UPS Ø The detection situation of AC input to UPS connected is displayed. When AC input is detected: Detected and AC input are not detected: none Battery run time Ø The lapsed time (second) after UPS is in a battery-operated state is displayed. Battery rest Ø...
Page 75 USDP-R1000 VIII-2-1-3. Reproduction state Two or more windows can be displayed on this product on a screen, and the state of each display window is displayed here. Main window SMIL Ø Video Ø HTML Ø Still picture Ø Telop Ø Overlay video Overlay HTML Overlay still picture...
Page 76 Operation manual VIII-2-1-4. Storage The state of each storage connected now is displayed. There is the following kind of storage connectable with this product. Built-in storage USB1 USB2 The following value is displayed on each storage. About the storage which is not connected, it is displayed as "---."...
Page 77 USDP-R1000 Attention Please do not remove the storage under access (under contents reproduction and distribution) by any means. Please be sure to perform [safe removal]. A contents file and a file system may break and it becomes a cause of failure of storage.
Page 78 Operation manual The number of transmitted files Ø The number of transmitted files is expressed as the form of "the number of files which are several transmitted files/a transmission schedule." At the time of a transmission opening day Ø The time which started transmission is displayed. Lapsed time Ø...
Page 79 USDP-R1000 VIII-2-1-7. Cooperation with DCM Connection with a DCM server Ø The communication state with DCM is displayed by "true/false." In the case of "false", Check the condition of a Network setup or a DCM server. Page73...
Page 80: Viii-2-2. Log
Operation manual VIII-2-1-8. Remote serial Connection Ø The connection state of a remote serial is displayed by "true/false." Transmitting side peer Ø The IP address and port number of the transmitting side are displayed. Receiving side peer Ø The IP address and port number of a receiving side are displayed. ■...
Page 81: Viii-3. Setup
USDP-R1000 Transmission log The log which cooperates with DCM and transmits a file is displayed. VIII-3. Setup ■ VIII-3-1. About a setup Operation of USDP-R1000 is changed by setup. If it clicks the [setting] button of each page, an actual setup is performed, and when a reboot is required, it will reboot after the completion of a setting.
Page 82: Viii-3-2. Basic Setup
Operation manual ■ VIII-3-2. Basic setup VIII-3-2-1. Operational mode Channel mode - (initial value) Ø Operates in channel mode where you select from the registered channel numbers. In performing schedule reproduction using DCM, please set to [channel mode]. Menu mode Ø...
Page 83 USDP-R1000 operations. Built-in storage Ø USB1 Ø USB2 Ø VIII-3-2-4. Time zone Please choose the time zone where the area in which USDP-R1000 is installed belongs. VIII-3-2-5. Remote control Effective/invalid Effective - (initial value) Ø Invalid Ø A remote control is not used. Set up Remote control ID correspond, when operating two or more USDP-R1000 with...
Page 84 Operation manual normal operation. Status - (initial value) Ø A model name and the reproduction state (STOP/PLAY/LOAD/PAUSE) of the contents of a main window are displayed. IP address Ø IPv4 address of a model name and this machine is displayed. The date and time Ø...
Page 85 USDP-R1000 Attention If specification is mistaken, there is a possibility that a system may stop operating normally. Example Ø Every day morning 5 o'clock 23:30 on every 30 23 * * 0 week Sunday VIII-3-2-8. Clock Clock display It is set up whether a clock is displayed on a screen. Effective Ø...
Page 86 Operation manual The account of a timetable Ø Notation Display %H %k Time (0-23) %I %l Time (1-12) Part Second morning %P %p afternoon (English) Example Ø Notation Display %d.%m.%Y 21.05.2013 %a %b %d %y Tue May 21 13 %l:%M:%S %P 2:13:9 pm It is displayed that the following setup clicks it "is [ ...
Page 87 USDP-R1000 pixel. Position size Specify the display position and size of a clock. Although a value is specified by the coordinate system of 3840x2160, when a display is 1920x1080, it is displayed in the position and size which were reduced. (X - initial value: -- 2600 Ø...
Page 88 Operation manual Battery run time Ø Shut [ the lapsed time after UPS is in a battery-operated state / USDP-R1000 ]. Battery rest Ø Shut [ USDP-R1000 ] when battery rest of UPS is less than a preset value in the state battery-operated in UPS.
Page 89: Viii-3-3. Network
By connecting Stream Deck (the customizable LCD key) to the USB port of USDP- R1000, external control of control and other MEDIAEDGE Decoder of USDP-R1000, the USDP series products, etc. can be carried out. About directions for use and the setting...
Page 90 Operation manual The acquisition method of an IP address is set up. Acquire IPv4 address automatically (DHCP). - (initial value) ² Acquire an IP address from a DHCP server. The IP address assigned is based on a setup of DHCP. An IP address is not assigned until it is acquirable from a DHCP server.
Page 91 USDP-R1000 Use the address of the following DNS server. ² Set up the DNS server to be used. Check with a network administrator about a preset value. Priority DNS server Specify the DNS server to which give priority. An alternative DNS server use it, when a response does not return from a priority DNS server -- carry out DNS server specification.
Page 92 Operation manual Host name Ø Port number Ø Exclusion list A server's host name or IP address which carries out direct access without using Proxy is described. When you carry out multidata input, please divide and specify with a comma. VIII-3-3-4.
Page 93 USDP-R1000 VIII-3-3-5. NTP The NTP server which rectifies the time of a clock with USDP-R1000 built-in is set up. > Time settings （NTP） Acquire a NTP server's address automatically. - (initial value) Use the next NTP server. Host name Ø A NTP server's host name or an IP address is inputted.
Page 94 Operation manual VIII-3-3-7. Cooperation with service DCM to connect is set up when managing the schedule of USDP-R1000, a layout, and contents using DCM. Cooperation Effective Ø Invalid - (initial value) Ø Service The service which cooperates is DCM fixation. Ø...
Page 95 Invalid - (initial value) Ø Account Set up the account and preset value linked to a share drive. User name - (initial value: mediaedge) Ø Password - (initial value: with no preset value) Ø Share drive authority The drive will not be shared if it sets up invalid. In a [read-only] case, it reads, and is accepted, and, in the case of a [lead light], reading and writing become possible.
Page 96 Use the storage linked to USB2. An open folder The path of the folder which stores the contents made into an open object is specified. The initial value serves as [MEDIAEDGE/_WebControl]. The folder set up here is opened to the following URL. Open URL: <http://usdp-address/web_control/menu/>...
Page 97: Viii-3-4. Menu Mode
● Menu acquisition origin Choose the acquisition origin of a menu page. Choose a [server], when carrying out streaming reproduction from MEDIAEDGE Server or MEDIAEDGE LEB. When [a local drive (menu automatic generation)] is chosen, from the contents in the specified drive, a menu is generated automatically and display it. When [a local drive (user menu)] is chosen, display the menu file (HTML) in the drive specified as the [menu file path].
Page 98 (the example description: Ø http://mediaedge-svr/sample/usdp/index.asp) Specify home URL of a menu at the time of setting [menu acquisition origin] as a [server]. In reproducing a local file, there is no necessity for a setup. VIII-3-4-3. Local drive ● Contents drive...
Page 99 USDP-R1000 When the specified path does not exist, the top class of the drive specified by [the contents drive] is displayed. Right It is also possible to choose a file from the file list which clicks -- and is stored in the drive connected.
Page 100: Viii-3-5. Channel Mode
Operation manual HTML html, htm, asp SMIL smil, smi, sml The schedule file created by DCM is recognized as schedule contents. VIII-3-4-4. Screen saver When there is no operation for a definite period of time at a menu mode, it is possible to display a screen saver.
Page 101 USDP-R1000 The contents which specified USDP-R1000 at [home] that it starts in channel mode are reproduced. Moreover, the contents specified by [home] and a number can be changed with the remote control. The CANCEL key of the remote control Operation when the (CANCEL) key of the remote control is pressed is specified during contents reproduction.
Page 102 Operation manual Built-in storage: internal_HDD USB1: USB1 USB2: USB2 Right It is also possible to choose a file from the file list which clicks -- and is stored in the drive connected. Repeat Ø When reproduction of contents is completed, it is specified whether reproduction is repeated or not.
Page 103: Viii-3-6. Serial Control Mode
The path of the folder which stores the contents made applicable to reproduction is specified. Right It is also possible to choose a folder from the folder list which clicks -- and is stored in the drive connected. The initial value serves as MEDIAEDGE/_Serial. Page97...
Page 104: Viii-3-7. Reproduction
Operation manual VIII-3-6-3. Network serial control Effective/invalid Effective Ø Receive the control commands of serial control mode via a network. Invalid - (initial value) Ø Don't receive the control commands of serial control mode via a network. Standby port number - (initial value: 12000) The standby port number which receives the control commands of serial control mode via a network is specified.
Page 105 It is not based on operational mode but the operation in the case of reproducing according to a schedule file is set up. In MEDIAEDGE, a filler refers to the function which reproduces automatically the contents specified when an error occurred at the time of schedule reproduction.
Page 106 Operation manual reproduce the file according to a schedule. Invalid - (initial value) Ø Don't perform filler reproduction. Filler file - (initial value: with no preset value) Set URL or the file path of a filler file reproduced when a reproduction error is detected.
Page 107 USDP-R1000 VIII-3-7-4. SMIL Indicate by expansion according to monitor size. Effective Ø When monitor size and the layout size of SMIL do not suit, adjust and display on monitor size. Invalid - (initial value) Ø Display in the layout size of SMIL. Stop reproduction in the error of contents.
Page 108 Operation manual VIII-3-7-5. Folder reproduction The reproduction method when a folder is specified as contents is set up. Also reproduce a subfolder. Effective - (initial value) Ø The contents in a subfolder are also reproduced. Invalid Ø Only the specified contents directly under a folder are reproduced. An order to reproduce Ascending order of a file name - (initial value)
Page 109 USDP-R1000 HTML display time - (initial value: 5) The display time in the case of reproducing HTML (second) is specified. VIII-3-7-6. RTSP redirection Reproduction control (RTSP redirection) from the outside is validated. It recommends repealing, in not using it, since a RTSP server does not have attestation. Effective - (initial value) Ø...
Page 110: Viii-3-8. Serial
Operation manual The last frame Ø The retry at the time of an error When a streaming server returns an error, make re-connection until it succeeds. Effective Ø Invalid - (initial value) Ø Buffering time - (initial value: 500 milli second) Time to buffer reproduction data inside is set up in 0-1000 milliseconds.
Page 111 USDP-R1000 VIII-3-8-1. Serial port function Serial port function Remote serial Ø Use it in the remote serial mode. Schedule command Ø Output the serial command described to a schedule file or SMIL according to a schedule. Serial control Ø Use it by serial control mode. Invalid - (initial value) Ø...
Page 112 Operation manual Don't use a serial port. Communications parameter It sets up according to the apparatus which connects the following communications parameters. Transmission speed Ø Data bit length Ø Parity Ø Stop bit length Ø Flow control Ø Page106...
Page 113 When you use this mode, set the apparatus side of a connection place as server operation. Connect with K1000. Ø It is used when connecting with MEDIAEDGE Encoder K1000. Please set up a serial socket service effectively in K1000 of a connection place. Connection parameter Page107...
Page 114: Viii-3-9. Contact Control
Operation manual Set up the following connection parameters according to the apparatus which carries out remote connection. Connection place port number - (initial value: 60001) Ø Specify the port number for transmitting the communication inputted from the serial port to a network. Standby port number - (initial value: 60001) Ø...
Page 115 USDP-R1000 Contact control It is set up whether a contact control facility is used. Effective Ø Invalid - (initial value) Ø Device path - (initial value: Auto (with no preset value)) The device path of a correspondence USB point-of-contact input/output device is specified.
Page 116: Viii-3-10. Video Output
Operation manual The same operation as the time of receiving a remote control key is performed. A key name and a depression state (press/release) are needed. URL / channel number / volume/Remote control key Perform an additional setup at the time of choosing PLAY, Channel, and Volume in operation.
Page 117 USDP-R1000 Each monitor's display resolution is specified. Attention In USDP-R1000SH, a setup of 3840x2160p will not output a picture signal from a SDI output. Refresh rate Each monitor's refresh rate is set up. Rotation Each monitor's hand of cut is set up.
Page 118 The range of RGB to output is chosen. Attention When using a SDI output by USDP-R1000SH, if 0-255 is set up, the right signal will not be outputted from a SDI output. Please set it as 16-235. VIII-3-10-2. HDMI CEC...
Page 119 It is outputted from a LINE OUT terminal on the back. HDMI stereo (only USDP-R1000SH) Ø It is outputted from a HDMI terminal. SDI stereo (only USDP-R1000SH) - (USDP-R1000SH initial value) Ø It is outputted from a SDI terminal. HDMI1 stereo (only USDP-R 1000H) - (USDP-R1000H initial value) Ø...
Page 120: Viii-4. Equipment Management
Operation manual Please stop the contents under reproduction once with the remote control etc. to make change of this setup reflect. Volume The volume at the time of contents reproduction is set up by each right and left. 50 - (Initial Value) Ø...
Page 121: Viii-4-2. Remote Control
USDP-R1000 The drive which performs format and error checking is chosen (only built-in storage can be chosen). When the status of the drive is "none", built-in storage is not recognized normally. Please perform a below-mentioned drive check or format. Format The selected drive is formatted.
Page 122: Viii-4-3. A Reboot And A Shutdown
Operation manual react, even if it pushes a corresponding button. ■ VIII-4-3. A reboot and a shutdown A reboot and shutdown of USDP-R1000 are performed. ■ VIII-4-4. Initialization Setting initialization A system is returned to a setup at the time of factory shipments. Please click [execution] button, when you set up.
Page 123: Viii-4-5. Package Setup
USDP-R1000 ■ VIII-4-5. Package setup By editing and specifying the preset value file obtained by performing [acquisition of a preset value] on a [equipment management] -> [acquisition of information] screen, a preset value can be written in collectively. When a reboot rewrites a required preset value, USDP-R1000 reboots automatically.
Page 124: Viii-4-7. Renewal Of Firmware
Operation manual Specification of the update file of a version older than the firmware of a main part will not perform renewal of firmware. ■ VIII-4-7. Renewal of firmware Firmware is updated. It does not perform [version check, in returning to a previous version. please check the check box of] -- it updates compulsorily irrespective of the version of equipment.
Page 125: Viii-4-9. A User Name And Password Change
USDP-R1000 ■ VIII-4-9. A user name and password change A user name and a password are changed. When you change, please enter a user name and a password and click a [setting] button. The user name and password which were set up here are used by login in a Web console. New user name The newly registered user name is inputted.
Page 126: Front Panel
If the right / the [MENU/ENTER] key is pressed during a status display, it can go into a setting menu, and the display of a setup of this machine is performed and a change can be made. Status Setting display menu [The right/MENU/ENTER] Key USDP-R1000SH MENU 1.VIDEO PLAY It escapes from a setting menu. Page120...
Page 127: Ix-2. Setting Menu
USDP-R1000 IX-2. Setting menu ■ IX-2-1. Operation With a setting menu, the next operation is possible. Explanation If it pushes during a status display, it will go into a setting menu. It pushes, when deciding movement to a sub menu, and a [The preset value.
Page 128: Ix-2-3. Menu Item
Operation manual If [Yes] is chosen by a [top]/[the bottom] key and the right / the [MENU/ENTER] key is pressed, a setup is saved on a main part. To reflection of a setup, when a reboot is required, it reboots automatically. All the setup which changed when [No] was chosen by the [top]/[the bottom] key and the right / the [MENU/ENTER] key was pressed is canceled, and a setting menu is ended.
Page 129: Ix-2-4. Video
5. SHUTDOWN l Power off l Reboot At USDP-R1000SH, it is HDMI/SDI, and is HDMI1 / HDMI2 at USDP-R 1000H. The item which cannot be set up with the setting menu of a front panel, please set up consol. ■ IX-2-4. VIDEO IX-2-4-1.
Page 130: Ix-2-5. Network
Operation manual SDI - (initial value) Ø Ø USDP-R1000H Analog Ø HDMI1 - (initial value) Ø HDMI2 Ø Ø ■ IX-2-5. NETWORK IX-2-5-1. IPv6 The validity of IPv6 and invalidity are set up. Usually, please repeal only in the environment which validates, validates IPv6 and has a problem. Enable - (initial value) Ø...
Page 131 USDP-R1000 Subnet mask Ø A subnet mask is set up. Gateway Ø A default gateway is set up. A number is sent by a [top]/[the bottom] key, it returns to the following item by the right / the [MENU/ENTER] key, and all return to a front item by the left / the [CANCEL] key. If a cursor presses the left / the [CANCEL] key in the state of being on the leftmost, a setup will be canceled, and it will be decided if the right / the [MENU/ENTER] key is pressed in the state of being on the rightmost.
Page 132: Ix-2-6. System
The information (status display) displayed on a liquid crystal display is set up during normal operation. Status - (initial value) Ø USDP-R1000SH A model name and the reproduction state of the PLAY contents of a main window are displayed. Under a STOP stop ²...
Page 133: Ix-2-7. Information
USDP-R1000 reproduction Under PLAY reproduction ² Under a PAUSE stop ² IP address Ø USDP-R1000SH IPv4 address of a model name and this machine is 192.168.0.20 displayed. Date Ø USDP-R1000SH A model name and the present time are displayed. 2021/07/01 12:00 ■...
Page 134 Operation manual ※ When the preset value has been changed, the screen which checks preservation of a setup is displayed. Please refer to■ IX-2-2 About reflection of a setup. Furthermore, a push on the right / the [MENU/ENTER] key will perform a shutdown or a reboot.
Page 135: Appendix
If the file of a name called update.inst or [host name] .update.inst exists in the route folder or MEDIAEDGE folder of USB storage, it will recognize as an updating control script. (The initial value of a host name is the name automatically generated from the MAC Address like "USDP-xxxxxx".)
Page 136: X-1-3. The Example Of Description
● Save a system log file (compressed in ZIP format) similar to the web console capture to the root folder of the USB storage. ■ X-1-3. The example of description \newcontents folder of USB storage is copied to below the MEDIAEDGE folder of the default drive of USDP-R1000. #!UPDATE Page130...
Page 137: X-2. Renewal Of Firmware
USDP-R1000 add_contents newcontents Firmware is updated by firmware file usdp_r1000_x.x.x.system. #!UPDATE update_firm usdp_r1000_x.x.x.system A preset value is updated by settings.txt. #!UPDATE set_config settings.txt X-2. Renewal of firmware ■ X-2-1. Update by a web browser 1) Copy the renewal file of firmware to PC linked to USDP-R1000. 2) Using a web browser, connect with the Web console of USDP-R1000.
Page 138: X-2-3. Return To The State Before Renewal Of Firmware
Operation manual #!UPDATE update_firm usdp_r1000_x.x.x.system <- the actual renewal file name of firmware It describes. If option is specified when updating to firmware older than the present. update_firm ?f usdp_r1000_x.x.x.system 2) Connect USB storage to USB 3.0 of USDP-R1000, or 2.0 ports. 3) In the case of firmware newer than the present, update.
Page 139: X-3. About An Uninterruptible Power Supply
USDP-R1000 system. 5) A system starts by the version before renewal of firmware.Update firmware again after starting. X-3. About an uninterruptible power supply Confirmed UPS of operation USDP-R1000 is connectable with UPS by OMRON Corp. Operation by the following UPS is checked. BN150XR by OMRON Corp.
Page 140: X-4. Specification
Operation manual X-4. Specification ■ X-4-1. Renewable contents Animation It corresponds to reproduction of the movie file compressed by H265, H.264, or MPEG-2. (A renewable file changes restriction according to the conditions of the contents reproduced simultaneously or others) ITU-T Rec. H.265 (ISO/IEC 23008-2 HEVC The maximum resolution: 3840x2160 The maximum bit rate: 50Mbps The maximum frame rate: 60p...
Page 141: X-4-2. Hardware Specification
"Display Content Manager" (an option, the following DCM and the notation). Extension smil, smi, sml ※ Specification may be changed without a preliminary announcement. ■ X-4-2. Hardware specification USDP-R1000SH Network interface Cable LAN Form 1000Base-TX Ethernet/IEEE802.3 It is based on frame form.
Page 142 Operation manual ※ It is the signal with SDI OUT1/OUT2 [ same ]. ※ The accuracy of a picture signal is 8 bits. ※ It does not correspond to 12 G-SDI output. When a format setup is set to 3840x2160, a signal does not come out from a SDI output.
Page 143 10%-90%RH (don't dew) conditions operation posture Level operation RoHS Correspondence Size (USDP-R1000SH) External 215 (W) x 295(D) x 40(H) mm * projection thing is not included. configuration size Mass About 2.0 kg (except for an AC/DC adaptor) USDP-R1000H Network interface...
Page 144 Operation manual form. Auto negotiation correspondence Full duplex correspondence Terminal RJ45 modular-connector x 1 Image sound HDMI output Form HDMI Ver2.0, HDCP un-corresponding, and CEC Only (*), DeepColor un- corresponding, HDR un-corresponding, and color space RGB are (*) USB CEC. It corresponds by an adapter.
Page 145 USDP-R1000 Recording region Loading model SSD loading model M.2 SATA SSD 256GB SSD a non-carrying model eMMC 3GB Built-in storage It is a use feasible region as an object for contents registration. SSD loading model About 256 GB (in 8Mbps, registration of animation contents of about 70 hours is possible) SSD a non-carrying model About 3 GB (in 8Mbps, registration of the animation contents...
Page 146: X-4-3. Appearance, Size
Operation manual ■ X-4-3. Appearance, size USDP-R1000SH main part Ø USDP-R1000H main part Ø ※ Please do not plug up the air intake hole on top. ※ Back required space changes with cables to be used. ※ These machines are a front air intake and a back exhaust gas.
Page 147: X-4-4. Connector Pin Configuration
USDP-R1000 AC/DC adaptor Ø (Unit mm) ■ X-4-4. Connector pin configuration 100Base-TX/1000Base-T Ethernet (LAN) RJ45 Pin# Signal Name Tx_D1+ Tx_D1- Rx_D2+ BI_D3+ BI_D3- Rx_D2- BI_D4+ BI_D4- Page141...
Page 148 Operation manual RS-232C D-SUB 9 pin Pin# Signal Alias Input and name output The connection method with PC HW control is used. HW control is not used. Page142...
Page 149 USDP-R1000 USDP-R1000SH / USDP-R1000H Operation manual 2022.10 Ver.2.0 Copyright c 2021-2022 MEDIAEDGE Corporation All rights reserved. 5-1-14, Hamabe-dori, Chuo-ku, Kobe-shi, 651-0083 23F TEL:078-265-1551 www.mediaedge.co.jp Page143...
