S
uppressor
F31
User's Manual
Benutzerhandbuch
Mode d'emploi
Manual del usuario
Manuale dell'utente
Manual do Utilizador
安裝說明書
用戶手冊
ユーザーズマニュアル
Руководство пользователя
kullanıcı elkitabı
(EEE Yönetmeliğine Uygundur)
คู ่ ม ื อ การใช้
www.thermaltake.com
Advertisement
Table of Contents
Related Manuals for Thermaltake CA-1E3-00M1WN-03
Summary of Contents for Thermaltake CA-1E3-00M1WN-03
- Page 1 ユーザーズマニュアル Руководство пользователя kullanıcı elkitabı (EEE Yönetmeliğine Uygundur) คู ่ ม ื อ การใช้ © 2016 Thermaltake Technology Co., Ltd. All Rights Reserved. 2016.11 All other registered trademarks belong to their respective companies. www.thermaltake.com Tested To Comply With FCC Standards FOR HOME OR OFFICE USE www.thermaltake.com...
- Page 2 LCS chassis should be held to. The Tt LCS certification was created so that we at Thermaltake can designate to all power users which chassis have been tested to be best compatible with extreme liquid cooling configurations to ensure you get the best performance from the best features and fitment.
-
Page 3: Specification
Specification Case Type Mid Tower Dimension (H*W*D) 497 x 250 x 515 mm (19.5 x 9.8 x 20.3 inch) Contents Material SPCC Front: 2 x 120mm 2 x 140mm 1 x 200mm Top: 3 x 120mm Chapter 1. Product Introduction 3 x 140mm 2 x 200mm Specification... -
Page 4: Warning And Notice
Warning and Notice Atenção!! Limite de altura para o dissipador do CPU: O limite de altura para o dissipador do CPU é 180 mm (7,1 polegadas). Limite de comprimento para VGA (placa gráfica): O limite de comprimento para VGA (placa gráfica) é 278 mm (10.9 polegadas). 警告！！... -
Page 5: Side Panels Disassembly
Power Supply Unit (PSU) Installation Side Panels Disassembly Español / 1. Instale la PSU en la ubicación correcta. 2. Ajuste el puente de soporte de la PSU en la ubicación adecuada y asegúrela con tornillos. Italiano / 1. Posizionare la PSU in modo corretto. 2. -
Page 6: Motherboard Installation
Motherboard Installation 5.25" Device Installation English / 繁體中文 / 1. Remove the 5.25” drive bay cover. 1. 移除5.25”擴充槽檔板 2. Slide the 5.25” device into the drive bay to lock the device. 2. 將5.25”裝置至適當的位置 Note: Press the 5.25” tool-free mechanism to unlock the 注意: 如需移除5.25”裝置，先按壓5.25”無螺機機構，再將... - Page 7 3.5" & 2.5" HDD Installation Type A English / 繁體中文 / 1. Pull the HDD tray out. 1. 將硬碟托盤取出 3.5” HDD 2. Place the 2.5” or 3.5” hard drive on the tray 2. 將2.5”或3.5”硬碟放置在硬碟托盤上，用螺絲固 and secure it with screws. 定硬碟 2.5”...
-
Page 8: Pci Card Installation
PCI Card Installation Air Cooling Installation Type A Direct installing to Motherboard 20cm x 2 Rear 14cm x 3 12cm x 3 14cm x 1 12cm x 1 Type B Extend installing to Motherboard (Optional) For No Window Side Panel Only 14cm x 1 Front 12cm x 1... -
Page 9: Liquid Cooling Installation
Liquid Cooling Installation Maximum Radiator Installation Notice Top Radiator Installation Notice * Please consult radiator & memory height for proper installation 安裝前請參考水冷排與記憶體高度 36cm x 1 Rear 28cm x 1 14cm x 1 12cm x 1 36 cm Radiator 28 cm Radiator Front 12cm x 1 28cm x 1... -
Page 10: Filter Installation
Filter Installation Soundproofed cover installation Top panel Remove soundproofed cover for additional fan slots Side panel For No Window Side Panel Only... - Page 11 Door Lock Usage Flexible covers mounting, for balance air flow and sound absorbing Type A Type B Buckle the rubber band to fix the door Type C Type D...
-
Page 12: Leads Installation
Leads Installation Français English Leads Installation Guide Guide d'installation des fils Case LED Connection / On the front of the case, you can find some LEDs and switch leads. Please consult your user Connexion des voyants du boîtier / Sur la face avant du boîtier, vous trouverez plusieurs voyants et les fils des manual of your motherboard manufacturer, then connect these leads to the panel header on the motherboard. - Page 13 Italiano 繁體中文 Guida di installazione dei contatti 線材安裝說明 Connessione del LED del case / Nella parte anteriore del case, sono presenti alcuni contatti per interruttori e LED. 機殼LED連接方式 / 在機殼前方的面板後面，可以找到一些LED與開關線材（POWER Switch….），請參考主機板使用說明書， Consultare il manuale utente del produttore della scheda madre, quindi connettere i contatti alla parte superiore del 並將機殼上的線材正確地連接到主機板上，這些線材通常都會印有標籤在上面，如果沒有的話，請找出機殼前方面板上線材原...
