Summary of Contents for Thermaltake LEVEL 20

  • Page 2: Table Of Contents

    Contents SyncALL, Say “Hello TT” 20 Years of Excellence Level 20 Level 20 GT Level 20 GT RGB Plus Level 20 XT Level 20 VT Specification...

  • Page 3: Syncall, Say "Hello Tt

    T T R G B P L U S E C O S Y S T E M SyncALL, Say “Hello TT” Android app on Download on the App Store...
  • Page 4 WHAT IS TT RGB PLUS ECOSYSTEM? TT RGB PLUS Ecosystem is the intelligent lighting system for PCs that combines the most advanced addressable LED lighting with Thermaltake’s patented TT RGB PLUS Software. TT RGB PLUS ecosystem provides nearly unlimited possibilities for playing with colors,...

  • Page 5: 20 Years Of Excellence

    20 Years of Excellence Founded in 1999, Thermaltake has been evolving continuously over the past two decades in the PC DIY industry. From developing thermal ventilation optimization, gaming oriented design to architectural aesthetics, we never stop striving to provide the best to the consumers.
  • Page 6 Full Tower Chassis Individual Aerodynamic Clear View with Quality Chamber Design Tempered Glass Panels Preinstalled RGB Aluminum Framed Illumination System Exterior...

  • Page 7: Level

    Aluminum Frame Level 20 features aluminum panels of which the aluminum anodizing process establishes water and corrosion resistant performance. Clear View of PC Gaming Three hinged swing-doors with premium-quality 4mm thick tempered glass design guarantee window durability and viewing capability to encourage users to thoroughly display superb inner components.
  • Page 8 Individual Aerodynamic Chamber Design Level 20 utilizes trio chamber design to achieve ventilation and space management optimization. By separating PSU, Motherboard, and Storage/LCS into different compartments, Level 20 creates a unique component landscape with tempered glass to celebrate the ensemble of the individual modules.
  • Page 9 Full Tower Chassis Modern I/O Support (USB Type-C™ & USB 3.0) Tempered Glass Aesthetic Patented Rotational PCI-E Go Vertical with 8 Slots Design Radiator Placement...
  • Page 10 Tempered Glass Aesthetic The Level 20 GT is built with tempered glass panels on the front, top and both sides. The left and right hinged doors are also equipped with smart lock security systems to secure the inner components of your case.

  • Page 11: Level 20 Gt

    Go Vertical with Radiator Placement Whether you’re building a custom loop or running an AIO CPU cooler, the Level 20 GT lets you mount your radiator against the back panel to show off your RGB fans. The back panel provides adequate exhaust while putting your RGB fans on display, with support for up to a 420mm radiator as well as radiator support on the front and top of the chassis.
  • Page 12 GT RGB Plus Full Tower Chassis Modern I/O Support (USB Type-C™ & USB 3.0) Tempered Glass Aesthetic Patented Rotational PCI-E Built to Shine RGB 8 Slots Design...
  • Page 13 16.8 million RGB colors! Tempered Glass Aesthetic The Level 20 GT RGB is built with tempered glass panels on the front, top and both sides. The left and right hinged doors are also equipped with smart lock security systems to secure the inner components of your case.
  • Page 14 GT RGB Plus Patented Rotational PCI-E 8 Slots Design Our brand new rotational PCI-E system allows you to stack multiple GPUs either vertically or horizontally, depending on how you want to build your system. Modern I/O Support The top-right panel features two USB 3.0 and two USB 2.0 data transfer ports, along with one USB 3.1 Type-C port.
  • Page 15 E-ATX Cube Chassis Modern I/O Support Clearly Gorgeous with Tempered Glass Panels Split-Level Design Advanced Ventilation...
  • Page 16 This means the panels are more resistant to dust and scratches than acrylic and provide a clearer view of internal components. Chamber Design The Level 20 XT carries over the innovations of some of our earlier cube case designs by splitting the chassis into two chambers.

  • Page 17: Level 20 Xt

    Advanced Ventilation Level 20 XT is preinstalled with one 140mm rear fan. Level 20 XT enables users to build a complete high-end system with ample room for up to two front 200mm fans and is fully compatible with 420mm, 360mm, 280mm, 240mm, 140mm and 120mm radiators.
  • Page 18 Micro Chassis Speedy Transmission Clearly Gorgeous Small Footprint with with Tempered Glass Big Possibilities Panels Chamber Concept...
  • Page 19 Small Footprint with Big Possibilities The Level 20 VT is all about big things coming in small packages. The VT supports M-ATX motherboards, as well as CPU coolers up to 185mm in height, VGA lengths up to 350mm and PSU sizes up to 200mm in length.
  • Page 20 Chamber Concept The Level 20 VT is optimized for space management. It’s divided into two main chambers: the upper chamber is made to house the motherboard and PCI-E components, while the lower one is made for the PSU and drive bays. Thanks to the removable 2.5”/3.5” drive device racks, there is plenty of flexibility to fit larger components or build a custom liquid cooling loop.

  • Page 21: Specification

    Specification...
  • Page 22 Specification...
  • Page 23 Specification GT RGB Plus...
  • Page 24 Specification...
  • Page 25 Specification...
