Toa AS-110A Specifications

TOA INSTITUTIONAL COMMUNICATION SYSTEM
DESCRIPTION
The TOA AS-110 control station with handset is intended to
be used in conjunction with the IC-100 system. It is a
ruggedly constructed surface or flush-wall-mount unit that
can also be mounted in a console by using the supplied
brackets. The AS-110 handles all communication to remote
substation handsets and/or speakers, and also controls the
IC-100 system's paging, program and time functions.
All operations are indicated on the unit's integrated LCD
(liquid crystal display). The AS-110 measures 9.45"
(240mm)(H) x 10.47" (266mm)(W) x 3.31" (84mm)(D), and
weighs 573lbs. (2.6kg).
CONTROL STATION
AS-110
FEATURES
1. Full-duplex communication with remote substation
handsets, other AS-100(A)s and AS-110s, and PBX
systems.
2. Half-duplex communications with remote substation
speakers.
3. Full outside (C/O) telephone line or PBX functions.
4. 12-digit LCD shows dialing data, displays priorities,
current time, and messages from linked personal
computer.
5. Selectable High/Low speaker volume control.
6. Direct connection of external microphone or headset
7. Membrane key switch keypad.
8. Controls all system paging and time signal functions.
9. Jack included for 4-pin STD Modular telephone plug
connection.
10. Provides for 3-party conferences.
11. Programming from keypad possible.
12. Wall-mountable, with bracket for console mounting.
13. Uses 22-24 AWG two (2) pair nonpolar twisted wire.
14. Can initiate Duress Alarm.
