IP STANDARD MASTER STATION
Thank you for purchasing TOA's IP Standard Master
Station.
Please carefully follow the instructions in this manual to
ensure long, trouble-free use of your equipment.
1. SAFETY PRECAUTIONS
• Before installation or use, be sure to carefully read all the instructions in this section for correct and safe
operation.
• Be sure to follow all the precautionary instructions in this section, which contain important warnings and/or
cautions regarding safety.
• After reading, keep this manual handy for future reference.
CAUTION
When the Unit is in Use
• Use the dedicated AC adapter or its equivalent for the unit. Note that the use of other adapter may cause a
fire.
2. GENERAL DESCRIPTION
The N-8510MS is an IP standard master station designed for use with TOA's packet intercom N-8000 system (IP network-
compatible intercom system) that employs the packet audio technology*.
By directly connecting the N-8510MS to a network (LAN or WAN), high quality hands-free or handset conversations
between IP stations, and paging broadcasts (paging calls) can be made. Once an emergency message has been
programmed into the station, it can be broadcast to the pre-programmed zones with the key operation or external control
input.
The ideal system for in-house or wide-area information transmission applications such as conversations between IP
stations and N-8000 system's stations, paging broadcasts (paging calls), periodical broadcasts, and background music
broadcasts can be built in conjunction with the N-8000EX or N-8010EX IP intercom exchange, or the N-8000MI Multi
interface unit.
Using an optional YC-280 Wall mounting bracket, the station can be mounted on a wall, or tilted for easy key operation
when used on a desktop.
* Technology related to audio transmission over a network.
Warning
This is a class A product. In a domestic environment this product may cause radio interference in which case the user may
be required to take adequate measures.
Indicates a potentially hazardous situation which, if mishandled, could
result in moderate or minor personal injury, and/or property damage.
INSTALLATION MANUAL
N-8510MS
