GIGABYTE GS27F, GS27Q, GS32Q - Gaming Monitor GS Series Manual

INTRODUCTION

Package Contents

The following items come with your packaging box. If any of them is missing, please contact your local dealer.

Note: Please keep the packaging box and packing materials for possible transportation of the monitor.

Product Overview

Front View

Product Overview - Front View

  1. Power LED
  2. Control button

Rear View

Product Overview - Rear View

  1. HDMI ports (x2)
  2. DisplayPort
  3. Headphone jack
  4. AC IN jack

GETTING STARTED

Installing the Stand Base

  1. Position the monitor face down on a flat surface with its protective foam underneath and with its Styrofoam bag covered.
  2. Fit the stand riser and stand base together with a coin, a screwdriver, or the pull ring attached on the stand base.
    Installing the Stand Base - Step 1
  3. Tear apart the Styrofoam bag. Fit the stand riser to the groove on the back of the monitor. Push the stand until it snaps into place.
  4. Take the monitor from the protective foam by holding its stand riser. Place it upright on a table.
    Installing the Stand Base - Step 2

Cable Management

  1. Take out the cable clip from the EPS.
    Cable Management - Step 1 - Take out a cable clip
  2. Snap the cable clip into the stand, then pass the power cord and the cable through the cable clip in the stand to connect them to the monitor.
    Cable Management - Step 2

Adjusting the Viewing Angle

  1. Place one hand on the base to prevent the monitor from tipping over during the adjustment.
  2. Place the other hand on the top-center of the screen and apply forward or backward pressure to adjust the angle to the desired viewing angle (-5° to 20°).
    Adjusting the Viewing Angle

Installing a Wall-Mount Bracket (Optional)

Use only 100 x 100 mm compliant wall mount kit. Install the wall mount according to the manufacturer's instructions.

  1. Position the monitor face down with its protective foam or with a nonabrasive cloth underneath.
  2. Align the wall-mount bracket installation holes with the screw holes on the back of the monitor.
  3. Use the screws to secure the bracket in place.
    Installing a Wall-Mount Bracket

Note: To mount the monitor on the wall, refer to the installation guide that is included in the wall-mount bracket kit.

USING THE DEVICE

Turning the Power On/Off

Make sure the power switch next to the AC power input jack is switched to ON.

Power On

  1. Connect one end of the power cable to the AC IN jack at the rear of the monitor.
  2. Connect other end of the power cable to a power outlet.
  3. Press the Control button to turn on the monitor. The Power LED will light in white, indicating the monitor is ready to use.
    Turning the Power On

Power Off
Press the Control button for 2 seconds to turn off the monitor.
Note: When the Main menu appears on the screen, you can also turn off the monitor by moving the Control button down ( ).

Selecting the Input Source

  1. Move the Control button right ( ) to enter the Input menu.
  2. Move the Control button center ( ) to select the desired input source. Then press the Control button to confirm.
    Selecting the Input Source

OPERATIONS

Quick Menu

Hot Key
By default, the Control button has been assigned with the specific function.
Note: To change the preset hot key function, refer to the "Quick Switch" section.

To access the hot key function, do the following:

  • Move the Control button up ( ) to enter the Black Equalizer menu. Move the Control button up/down ( ) to adjust the setting and press the Control button to confirm.
    Accessing the hot key function - Step 1
  • Move the Control button down ( ) to enter the Picture Mode menu.
    Move the Control button center ( ) to select the desired option and press the Control button to confirm.
    Accessing the hot key function - Step 2
  • Move the Control button left ( ) to enter the Crosshair menu.
    Move the Control button up/down ( ) to select the desired option and press the Control button to confirm.
    Accessing the hot key function - Step 3
  • Move the Control button right ( ) to enter the Input menu. Refer to the "Selecting the Input Source" section.

Note: To close the menu, move the Control button left ( ).

Function Key Guide

  • Press the Control button to display the Main menu.
    Then use the Control button to select the desired function and configure the related settings.
    Main Menu

Game Assist

  • When the Main menu appears on the screen, move the Control button right ( ) to enter the Game Assist menu.
  • Game INFO: Configure the FPS (First Person Shooting) game related settings.
    • Select Gaming Timer to select countdown timer mode. To disable this function, set the setting to OFF.
    • Select Refresh Rate to enable/disable real-time refresh rate setting.
    • Select Info Location to specify the location of the information to be shown on the screen.
  • Display Alignment: When the function is enabled, it displays the alignment lines on the four sides of the screen, providing handy tool for you to line up multiple monitors perfectly.

Configure the Device Settings
When the Main menu appears on the screen, move the Control button up ( ) to enter the Settings menu.
Note: Use the Control button to navigate through the menu and make adjustments.

Gaming


Configure the game related settings.

Item Description
Aim Stabilizer

When this function is enabled, it reduces the motion blur in a fast moving games.

Note: This function is not available under the following conditions:

  • when the frequency setting is lower than 100Hz.
  • when the FreeSync Premium function is activated.
Black Equalizer Adjust the brightness of the black areas.
Super Resolution Sharpen the low resolution images.
Display Mode Select the aspect ratio of the screen.
  • Full: Scale the input image to fill the screen. Ideal for 16:9 aspect images.
  • Aspect: Display the input image without geometric distortion filling as much of the screen as possible.
Note: This option is not compatible with FreeSync Premium and PIP/PBP functions.
Overdrive Improve the response time of the LCD monitor.
FreeSync Premium When this function is enabled, it eliminates the screen lag and tearing while playing games.



Configure the image related settings.

Item Description
Standard For editing documents or browsing websites.
Gaming For playing games.
Movie For watching movies.
Reader For viewing documents.
sRGB For viewing photos and graphics on the computer.
Custom Customized picture mode settings.
ECO For Energy saving mode.

Note: Picture mode "Standard", Low blue light "Level 10" is the optimized setting in compliance with TÜV Low Blue Light Certification.

Display


Configure the display screen related settings.

Item Description
Input Select the input source.
Overclock Select ON/OFF (only for GS27Q/GS32Q)
RGB Range Select an appropriate RGB range setting or let the monitor to detect it automatically.
Note: This option is only available for HDMI input.
Overscan When this function is enabled, it slightly enlarges the input image to hide the outermost edges of the image.

PIP/PBP

Only for GS27Q/GS32Q


Configure multi-image related settings.

Item Description
OFF Disable PIP/PBP function.
PIP Divide the screen into two parts (main window and inserted window)
  • Signal source: Change the input source of the inserted window.
  • PIP size: Adjust size of the inserted window.
  • Position: Move the inserted window to a different position.
  • Display switch: Switch between the two windows.
  • Audio switch: Select the audio source of the desired sound.
PBP Display 1x1 split screen (with left and right windows).
  • Signal source: Change the input source of the right window.
  • PBP size: Adjust size of the window.
  • Display switch: Switch between the two windows.
  • Audio switch: Select the audio source of the desired sound.

Note: PIP/PBP is not compatible with HDR and FreeSync Premium functions.

System


Configure the system related settings.

Item Description
Audio Configure the headphone settings.
  • Volume: Adjust the volume level.
  • Mute: Enable/Disable the mute function.
OSD Settings Configure the on-screen display (OSD) menu related settings.
  • Display Time: Set the length of time the OSD menu remains on the screen.
  • OSD Transparency: Adjust the OSD menu transparency.
  • OSD Lock: When this function is enabled, no OSD adjustment is allowed.
Note: To disable the OSD lock function, press the Control key. When the message appears on the screen, select Yes to confirm.
Quick Switch

Assign the function of the hot keys.

Available options: Aim Stabilizer, Black Equalizer, Crosshair, Low Blue Light, Volume, Input, Contrast, Brightness, and Picture Mode.

The default setting of the hot keys as below:

  • Up ( ): Black Equalizer
  • Down ( ): Picture Mode
  • Right ( ): Input
  • Left ( ): Crosshair
Other Settings
  • Resolution Notice: When this function is enabled, the current resolution message will appear on the screen when the monitor switches to another input source.
  • Input Auto Switch: When this function is enabled, it automatically switches to an available input source.
  • Auto Power Off: When this function is enabled, the monitor will automatically turn off after a certain amount of time.
  • LED Indicator: By default, the LED indicator is set to Always ON.
    • Always OFF: Turn off the Power LED.
    • Always ON: The Power LED lights white during operation and lights interval every 1 sec. in standby mode.
    • Standby ON: The Power LED turns off during operation and lights interval every 1 sec. in standby mode.
      (Note: The Power LED will turn on for 1 minute after restarting the display in Standby ON mode.)
  • Quick Boot: When this function is enabled, it slightly improves the boot-up speed of the screen. (Only for GS27Q/GS32Q)

Language

Item Description
Language Select an available language for the OSD menu.

Reset All


Restore the monitor to its factory default settings.

Specifications

Item Specifications
Model GS27F GS27Q GS32Q
Panel Size 27-inch 32-inch
Aspect Ratio 16:9
Resolution 1920 x 1080 2560 x 1440
LED Life 30,000 hours (min.)
Pixel Pitch 0.3108 (H) x 0.3108 (V) 0.2331 (H) x 0.2331 (V) 0.2727 (H) x 0.2727 (V)
Brightness 300 nits (typ.) / 250 nits (min.)
Contrast Ratio 1000:1 (typ.) 1200:1 (typ.)
Color Depth 16.7M (8Bit) 1.07B (8Bit+FRC)
Active Display Area 596.736(H) × 335.664(V) 596.736(H) × 335.664(V) 698.112(H) × 392.688(V)
Viewing Angle 178° (H)/178° (V)
Input/Output Terminals

2 x HDMI 2.0

1 x DP 1.4

1 x Headphone

Power Supply AC100~240V, 50/60Hz
Power Consumptions
  • On Mode: 23W
  • Standby: 0.5W
  • Off Mode: 0.3W
  • On Mode: 33W
  • Standby: 0.5W
  • Off Mode: 0.3W
  • On Mode: 36W
  • Standby: 0.5W
  • Off Mode: 0.3W
Note: The test conditions follow the CEC standards.
Dimensions (W x H x D) 619 x 447.4 x 172 mm (with Stand) 714 x 500.8 x 238 mm (with Stand)
Weight 5.02 kg (Net) 5.26 kg (Net) 7.2 kg (Net)
Temperature Range (operation) 0°C to 40°C

Supported Timing List

FHD QHD
Timing List HDMI 1 HDMI 2 DP HDMI 1 HDMI 2 DP
720X400 / 70Hz V V V V V V
720X400 / 88Hz V V V V V V
640X480 / 60Hz V V V V V V
640X480 / 67Hz V V V V V V
640X480 / 72Hz V V V V V V
640X480 / 75Hz V V V V V V
800X600 / 56Hz V V V V V V
800X600 / 60Hz V V V V V V
800X600 / 72Hz V V V V V V
800X600 / 75Hz V V V V V V
832X624 / 75Hz V V V V V V
1024X768 / 87Hz V V V V V V
1024X768 / 60Hz V V V V V V
1024X768 / 70Hz V V V V V V
1024X768 / 75Hz V V V V V V
1280X1024 / 75Hz V V V V V V
1152X870 / 75Hz V V V V V V
1152X864 / 75Hz V V V V V V
1280X720 / 60Hz V V V V V V
1280X800 / 60Hz V V V V V V
1280X960 / 60Hz V V V V V V
1280X1024 / 60Hz V V V V V V
1440X900 / 60Hz V V V V V V
1600X900 / 60Hz V V V V V V
1680X1050 / 60Hz V V V V V V
720X480 / 60Hz V V V V V V
1280X720 / 50Hz V V V V V V
1280X720 / 60Hz V V V V V V
1280X720 / 100Hz V V V V V V
1440X480 / 60Hz V V V V V V
1920X1080 / 50Hz V V V V V V
1920X1080 / 60Hz V V V V V V
1920X1080 / 100Hz V V V V V V
1920X1080 / 120Hz V V V V V V
1920X1080 / 144Hz V V V V V V
1920X1080 / 165Hz V V V V
2560x1440 / 60Hz V V V
2560x1440 / 120Hz V V V
2560x1440 / 144Hz V V
2560x1440 / 165Hz V

Troubleshooting

Problem Possible Solution(s)

No power
  • Make sure the power cable is properly connected to the power source and the monitor.
  • Check the cable and plug to make sure they are not broken.
  • Make sure the monitor is turned on.

No image appears on the screen
  • Make sure the monitor and the computer are properly connected and both devices are turned on.
  • Make sure you have selected the correct input source.

The image does not fill the entire screen
  • Try different Display Mode (aspect ratio) setting.

The colors are distorted
  • Make sure the input signal cable is properly connected.
  • Configure the image related settings. Refer to the "Picture" section.

No sound or volume is low
  • Make sure the headphone cable is properly connected.
  • Adjust the volume level.
  • Check the Audio Source setting.
  • Adjust your computer sound related settings.

Note: If the problem persists, please contact our customer service for further assistance.

Basic Care

  • Wipe the screen with a soft, lint-free cloth to remove any residual dust.
  • Spray or apply the cleaning fluid onto a soft cloth. Then wipe the screen gently with the damp cloth.

Note:

  • Make sure that the cloth is damp, but not wet.
  • When wiping, avoid applying excessive pressure on the screen.
  • Acidic or abrasive cleaners can damage the screen.

GIGABYTE Service Information

More service information, please visit GIGABYTE official website.
https://www.gigabyte.com/

SAFETY INFORMATION

Safety Precautions

Read through the following Safety Precautions before using the monitor.

  • Only use the accessories that are provided with the monitor or that which are recommended by the manufacturer.
  • Keep the plastic packaging bag for the product in a place that cannot be reached by children.
  • Before connecting the monitor to the power outlet, make sure that the voltage rating of the power cable is compatible with the power specification in the country where you are located.
  • The power cord plug must be connected to a properly wired and grounded power outlet.
  • shock hazard Do not touch the plug with wet hands, otherwise easily cause electric shock.
  • Place the monitor in a stable and well-ventilated place.
  • Do not place the monitor near any heat sources such as electric radiators or direct sunlight.
  • The holes or openings on the monitor are for ventilation. Do not cover or block the ventilation holes with any objects.
  • shock hazard Do not use the monitor near water, drinks, or all types of liquids. Failure to do so may result in electric shock or damage to the monitor.
  • Make sure to unplug the monitor from the power outlet before cleaning.
  • As the screen surface is easy to be scratched, avoid touching the surface with any hard or sharp object.
  • Use a soft lint-free cloth instead of a tissue to wipe the screen. You may use a glass cleaner to clean the monitor if required. However, never spray the cleaner directly onto the screen.
  • Disconnect the power cable if the monitor is not being used for a long period of time.
  • Do not attempt to disassemble or repair the monitor yourself.

Stability Hazard Precautions

The product may fall, causing serious personal injury or death. To prevent injury, this product must be securely attached to the floor/wall in accordance with the installation instructions.

Many injuries, particularly to children, can be avoided by taking simple precautions such as:

  • ALWAYS use stands or installation methods recommended by the manufacturer of the product set.
  • ALWAYS use furniture that can safely support the product.
  • ALWAYS ensure the product is not overhanging the edge of the supporting furniture.
  • ALWAYS educate children about the dangers of climbing on furniture to reach the product or its controls.
  • ALWAYS route cords and cables connected to your product so they cannot be tripped over, pulled or grabbed.
  • NEVER place a product in an unstable location.
  • NEVER place the product on tall furniture (for example, cupboards or bookcases) without anchoring both the furniture and the product to a suitable support.
  • NEVER place the product on cloth or other materials that may be located between the product and supporting furniture.
  • NEVER place items that might tempt children to climb, such as toys and remote controls, on the top of the product or furniture on which the product is placed.
  • If the existing product is going to be retained and relocated, the same considerations as above should be applied.
  • To prevent personal injury or damage to the product caused by tipping over due to earthquakes or other shocks, make sure to install the product in a stable location and take measures to prevent falling.

User Comfort Recommendations

The monitor adopts Flicker-Free technology which clears the eye visible monitor flicker and prevents users from suffering eye strain and fatigue.

The following are some tips for comfortable viewing of your monitor:

  • Optimal viewing distances for monitors range from approximately 510 mm to 760 mm (20" to 30").
  • A general guideline is to position the monitor such that the top of the screen is at or slightly below your eye-height when you are comfortably seated.
  • Use adequate lighting for the type of work you are performing.
  • Take regular and frequent breaks (at least for 10 minutes) every half-hour.
  • Be sure to periodically look away from your monitor screen and focus on a far object for at least 20 seconds during the breaks.
  • Eye exercise can help reduce eye strain. Repeat these exercises frequently:
  1. look up and down
  2. slowly roll your eye
  3. move your eyes diagonally.

This model has passed Flicker Free and Low Blue Light verification by TÜV Rheinland.
To learn more:
https://www.gigabyte.com/tw/Support/FAQ/4310


The terms HDMI, HDMI High-Definition Multimedia Interface, HDMI Trade Dress and the HDMI Logos are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.

Documents / Resources

References

Download manual

Here you can download full pdf version of manual, it may contain additional safety instructions, warranty information, FCC rules, etc.

Download GIGABYTE GS27F, GS27Q, GS32Q - Gaming Monitor GS Series Manual

Advertisement

Need help?

Need help?

Do you have a question about the GS27F and is the answer not in the manual?

Questions and answers

Related Manuals for Gigabyte GS27F

Save Article as PDF

Table of Contents
