Larson Electronics EPL-MBC-1MLED-2023 Instruction Manual

Thank you for your purchase of the Larson Electronics EPL-MBC-1MLED-2023 Portable Explosion Proof LED
Light. Please follow the steps below in order to operate and maintain this product.
IMPORTANT
READ CAREFULLY BEFORE OPERATING THIS FIXTURE. SAVE THESE INSTRUCTIONS FOR FUTURE
REFERENCE. THE EPL-MBC-1MLED-2023 MUST BE OPERATED IN ACCORDANCE WITH NATIONAL ELECTRICAL
CODE AND ALL APPLICABLE LOCAL CODES. PROPER GROUNDING IS REQUIRED FOR SAFETY.
FOR PERSONAL SAFETY, ALWAYS CONFIRM THE RATING OF ANY KNOWN HAZARDOUS OR POTENTIALLY
HAZARDOUS LOCATION WHERE THE LIGHT IS TO BE USED.
WARNING:
TO PREVENT IGNITION OF A HAZARDOUS ATMOSPHERE, THE SUPPLY CIRCUIT SHOULD BE
DISCONNECTED WHEN INSTALLING OR PERFORMING ANY MAINTENANCE ON THIS UNIT.
WARNING:
WHEN INSTALLING THIS LIGHT IN HAZARDOUS LOCATIONS, CHECK THE OPERATING
TEMPERATURE LIMITS PRIOR TO INSTALLATION TO BE SURE IT CONFIRMS TO THE ENVIRONMENTAL
TEMPERATURE RESTRICTIONS AND NEC CLASSIFICATIONS. CHECK THE FIXTURE'S METAL NAMEPLATE FOR
TEMPERATURE (T) RATINGS.
WARNING:
DO NOT SCRATCH OR CHIP THE FRONT LENS. TURN THE POWER OFF BEFORE STARTING
INSTALLATION OR REPAIR.
WARNING:
OPERATE THIS FIXTURE ONLY AT THE VOLTAGE OF YOUR SPECIFIC SUPPLY CIRCUIT. FAILURE
TO DO SO WILL RESULT IN DAMAGE TO THE FIXTURE.
WARNING:
SUBSTITUTE COMPONENTS MAY IMPAIR EXPLOSION PROOF SAFETY.
•
PEOPLE WITH PACEMAKERS SHOULD CONSULT THEIR PHYSICIAN(S) BEFORE USE. ELECTROMAGNETIC
FIELDS IN CLOSE PROXIMITY TO HEART PACEMAKER COULD CAUSE PACEMAKER INTERFERENCE OR
PACEMAKER FAILURE.
•
KEEP FINGERS AWAY FROM MAGNET(S) WHEN MOUNTING AS INJURY COULD OCCUR.
OPERATING
Before operation, confirm that the power source will provide the correct voltage indicated on the product
nameplate. Ensure the receptacle will accept the cord cap attached to the light.
Check product nameplate for Ratings and Approvals.
Affix light in the desired location and run its power cord to a compatible power source.
Mount light to a metal surface that can structurally support the load. Six 200lb. grip
magnets hold the fixture in any position. Ensure all safety requirements are followed for
the hazardous area.
Avoid excess tension between cord and light to reduce stress on the magnets. Mark
area as needed to avoid potential trip hazards or cable snags causing the light to dismount.
The light head can be adjusted by loosening the hand screws on each side. Once loose,
position the light head in the desired angle and tighten the hand screws to hold the light
in place. Use caution while adjusting as to not pinch your fingers between light and
mount.
This light is "instant-on" once plugged in to a live circuit. Do not face the light while energizing to avoid direct
eye exposure.
AVOID DIRECT EYE EXPOSURE Do not look at the face of or directly into the light when plugging in or when
illuminated.
Larson Electronics, LLC
EPL-MBC-1MLED-2023 Instruction Guide
150 Watt Magnetic Explosion Proof LED Light
Phone: (800) 369-6671 Fax: (903) 498-3364
EPL-MBC-1MLED-2023
HAND SCREW
