Factory Test & Alignment Specification For MS63F-LA Series (V0.10)
Appendix "NETWORK CONNECTION AND TEST"

1.Network connection

You can set up your TV so that it can access the Internet through your local area network (LAN)
using a wired or wireless connection.
1.1Connecting to a wired network
You can attach your TV to your LAN using cable in three ways:
• You can attach your TV to your LAN by connecting the LAN port on your TV to an external modem
using a Cat 5 cable.
• You can attach your TV to your LAN by connecting the LAN port on your TV to a IP Sharer which is
connected to an external modem. Use Cat 5 cable for the connection.
• Depending on how your network is configured, you may be able to attach your TV to your LAN by
connecting the LAN port on your TV directly to a network wall outlet using a Cat 5 cable. Note that the
wall outlet is attached to a modem or router elsewhere in your house.
Select Options > Network > Configuration >Interface, then select Ethernet to connect to a wired
network.
1.2 Connecting to a wireless network
To connect your TV to your network wirelessly, you need a wireless router or modem and a Wireless
LAN Adapter. Connect your Wireless High Gain USB
Adapter (USB dongle) delivered with your TV to your TV's USB 1 port.
1.2.1 Select Options > Network > Configuration >Interface, then select Wireless to connect to a
wireless network.
1.2.2. Select Wireless setting and press OK/• to enter.
1.2.3. Connection Methods: You can setup the wireless network connection three ways.
1.2.3.1 Scan
• Select Wireless setting > Scan, then press OK/• , the TV will scan all access points within range.
The access points found by the TV will be displayed.
• Select an available access point, then press OK/• to connect the TV to it.
Notes:
- If you select a protected access point, you will have to enter the corresponding password.Press
Menu on the remote control to display virtual keyboard to enable you to enter the password.
- This set has a memory function of available access point, which enables your set to be connected
to the network even if you switch on TV after power off.
1.2.3.2 Manual
Select Wireless setting > Manual, then press OK/• , you will be prompted to enter the correct SSID
of an available wireless router to setup the connection.
-1.2.3.3 Auto
If your AP supports WPS (Wi-Fi Protected Setup), you can connect to the network via PIN (Personal
Identification Number) or PBC (Push Button Configuration). WPS will automatically configure the
SSID and WPA key in either mode. Select Wireless setting > Auto, then press OK/• to enter.
• PIN: Select PIN and press OK/• to enter. Generate a random PIN code. Make sure this code is
installed to the AP. (For the procedures, refer to your router manual.) Press OK/• again to setup the
connection.
• PBC: If your router has a PBC push button, select PBC, then press OK/• to enter. Press PBC
push button on your router within 2 EN 12 minutes after you press OK/• again. Your TV will
automatically acquire all the network setting values it needs and connect to your network.
Network setup
1. Press Menu on the remote control and select
