REFRIGERATOR-FREEZERS
FFRF24SS
BRF241FD
BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING INSTRUCTIONS.
Write Model and Serial Nos. (on lower left
corner of inside cabinet) here:
Model No.: _______________________
Serial No.: _______________________
FROST-FREE
Models:
FFRF24S1S
FFRF3070B
User Manual
LFD24S1
FFRF3075W
Felix Storch, Inc.
An ISO 9001:2015 registered company
770 Garrison Ave
Bronx, New York 10474
www.summitappliance.com
Advertisement
Table of Contents
Related Manuals for Summit FFRF24SS
Summary of Contents for Summit FFRF24SS
- Page 1 FROST-FREE REFRIGERATOR-FREEZERS Models: FFRF24SS FFRF24S1S LFD24S1 BRF241FD FFRF3070B FFRF3075W User Manual BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING INSTRUCTIONS. Write Model and Serial Nos. (on lower left corner of inside cabinet) here: Felix Storch, Inc. An ISO 9001:2015 registered company Model No.: _______________________...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Appliance Safety Important Safeguards Location of Parts Installation Instructions Before Using your Appliance Installation of your Appliance Electrical Connection Installing the Stainless Steel Handle Operating your Appliance 9-11 Control Panel Interior Light Sabbath Mode Temperature Memory Function Defrosting Using the Freezer Temperature Alarm/Door Alarm... -
Page 3: Appliance Safety
APPLIANCE SAFETY Your safety and the safety of others are very important. We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety messages. This is the Safety Alert Symbol. The symbol alerts you to potential hazards that can kill or injure you and others. - Page 4 In the event of any damage: · Avoid open flames and anything that creates a spark, Disconnect from the power supply, Air the room in which the appliance is located for several minutes, and Contact the Service Department for advice. ·...
-
Page 5: Location Of Parts
LOCATION OF PARTS MODEL FFRF24SS / FFRF24S1S / LFD24S1 / BRF241FD LED Light Digital Control Panel Handle Left Zone (Freezer) Right Zone (Refrigerator) Wire Shelves (3) Glass Shelves (3) Door Security Lock Adjustable Legs Ventilation Grille MODELS FFRF3070B / FFRF3075W... -
Page 6: Installation Instructions
INSTALLATION INSTRUCTIONS Before Using your Appliance · Remove the exterior and interior packing. CAUTION: After unpacking you MUST allow this appliance to stand upright for at least 2 hours to allow the lubricant and refrigerant to drain back into the compressor and stabilize. Failure to do so may adversely affect performance and the lifetime of the unit. -
Page 7: Electrical Connection
23½" / 596 29½" / 750 29¾" / 755 NOTE: 1. Models FFRF24S1S, LFD24S1 and BRF241FD have the same size as FFRF24SS. 2. Model FFRF3075W have the same size as FFRF3070B. Electrical Connection WARNING Improper use of the grounded plug can result in the risk of electrical shock. If the power cord is damaged, have it replaced by a qualified electrician or an authorized service center. -
Page 8: Installing The Stainless Steel Handle
Installing the Stainless Steel Handles This appliance includes two stainless steel handle that are not required to operate the unit. To install each handle, follow the instructions below: 1. Remove the door gasket 2 on the side you wish to install the handle - you can see two holes designated for handle installation. -
Page 9: Operating Your Appliance
OPERATING YOUR APPLIANCE It is recommended you install the appliance in a place where the ambient temperature is between 61º and 90ºF (16º to 32ºC). If the ambient temperature is above or below the recommended temperatures, the performance of the unit may be affected. For example, placing your unit in extremely cold or hot conditions may cause interior temperatures to fluctuate. -
Page 10: Interior Light
Interior Light The unit is equipped with the interior LED lights which will be turned ON when a door is opened. The LED type lights are designed for extremely long life. They are not user serviceable. To change them please contact the service department. NOTES: Please use only the original LED light fittings provided by the manufacturer. -
Page 11: Temperature Alarm/Door Alarm
Temperature Alarm/Door Alarm • An audible alarm sounds if the storage temperature is not cold enough. The temperature display flashes at the same time. • The cause of the temperature being too high may be: Warm fresh food was placed inside Too much warm ambient air flowed in when rearranging or removing food Power failure for some time The appliance is faulty... -
Page 12: Care And Maintenance
CARE AND MAINTENANCE Cleaning your Appliance · Turn off the power, unplug the appliance, and remove all items, including shelves. · Wash the inside surfaces with a solution of warm water and baking soda (about 2 tablespoons of baking soda to a quart of water). ·... -
Page 13: Troubleshooting
TROUBLESHOOTING You can solve many common problems easily, saving you the cost of a possible service call. Try the suggestions below to see if you can solve the problem before calling the servicer. PROBLEM POSSIBLE CAUSE REMEDY Appliance is not connected to a power Connect the appliance. - Page 14 “E3”, “E4”, “E1” or “E2” indicates that the air “E5” or “E7”. temperature sensor has failed. “E3” or “E4” indicates that the defrost sensor in the evaporator has failed. “E5” indicates a defrost heater failure. “E7” indicates a door switch failure. Has an appliance door been open for If yes, close the door.
- Page 15 NOTES...
-
Page 16: Limited Warranty
LIMITED WARRANTY ONE-YEAR LIMITED WARRANTY Within the 48 contiguous United States, for one year from the date of purchase, when this appliance is operated and maintained according to instructions attached to or furnished with the product, warrantor will pay for factory-specified parts and repair labor to correct defects in materials or workmanship. Service must be provided by a designated service company.
