- Page 1 DUPLEX PRESS OPERATION’S MANUAL MEXICANTORTILLAMACHINE.COM AN-VT-07-I,310723-00 PDPX-110823-00...
- Page 2 The total or partial reproduction of this manual is prohibited by any means, whether printed or electronic; without the prior, express and written authorization of the author. DUPLEX PRESS OPERATION’S MANUAL...
- Page 3 INDEX GENERAL SAFETY INSTRUCTIONS CAUTION ELECTRICAL INSTALLATION COMPONENTS OPERATING INSTRUCTIONS CLEANING AND MAINTENANCE...
-
Page 4: General Safety Instructions
DUPLEX PRESS OPERATION’S MANUAL GENERAL SAFETY INSTRUCTIONS WARNING: To reduce the risk of injury, read all instructions properly. Failure to follow the instructions listed below can cause electric shock, fire, serious injuries, mutilation and/or damage to the equipment. A. SAFETY IN THE WORK AREA. - Page 5 DUPLEX PRESS OPERATION’S MANUAL CAUTION The following symbols indicate the safety measures that must be taken before and after starting up the equipment. HEAT HAZARD Some parts of the machine are hot while in operation. ELECTRICAL RISK In which you can suffer electric shocks, if you do not comply with the electrical safety provisions.
-
Page 6: Electrical Installation
It is recommended to use a 12 gauge cable for the installation of the Press. GAS INSTALLATION High-pressure regulator 10-080 or 2403 Stopcock at 1.5m (height) 1” Galvanized pipe gas natural. 1” Copper tubing Gas LP Low-pressure gas regulator Stopcock valve ELECTRICAL INSTALLATION Duplex Press 220v Duplex Oven 110v/220v 12 gauge cable (conduit cable) - Page 7 DUPLEX PRESS OPERATION’S MANUAL COMPONENTS ALUMINIUM PLATE CONTROL PANEL PYROMETER TEMPERATURE CONTROL AND PLATE OPENING SWITCHES...
- Page 8 DUPLEX PRESS OPERATION’S MANUAL Power switch Plate pilot lights plate opening (left) Switch disabled (repair) Left plate pyrometer Right plate pyrometer Pyrometer power Pyrometer power Plate pilot lights switch (left) switch (right) (left) Turn on pyrometer switch (left) Connect the press to a 220v outlet Rotate the pyrometer to 160°...
- Page 9 DUPLEX PRESS OPERATION’S MANUAL Rotate the pyrometer to 160° (35gr dough ball) Once the temperature is obtained, turn on the The pilot lights will turn on and will turn off plate opening switch. when the temperature is reached. Verify plate temperature by placing dough ball.
-
Page 10: Maintenance
DUPLEX PRESS OPERATION’S MANUAL MAINTENANCE Clean the machine before and after using it. The duration of the spare parts will depend on the preventive maintenance and care taken to the machine. The more frequently this maintenance is done, the parts will have a longer life. - Page 11 HEADQUARTERS AV. INDUSTRIAS #3665, ZONA INDUSTRIAL CP 78395 SAN LUIS POTOSÍ, SLP. MÉXICO 444 127 11 80 444 129 29 79 info@manufacturaslenin.mx MEXICANTORTILLAMACHINE.COM...
