Summary of Contents for twaudio B10
- Page 1 Operation manual...
- Page 2 One single B10 in stereo mode together with two C5 tops, two B10 switched to mono each with one M8, or four B10 together with two M10, all variations powered by one standard amplifier.
- Page 3 TW AUDiO products on the basis of practical experience. Notes on the products Read manual Before using the device, carefully read the operating manual and keep it with the B10 loudspe- before use! aker.
-
Page 4: Table Of Contents
Operation manual B10 Content 1. Safety | Intended use ...................... 5 2. Overview ........................7 Components ......................7 Variants ........................8 2.2.1 B10A / B10P model ................... 8 Operation modes ..................... 9 2.3.1 Selector switch S3 - MONO/STEREO mode ............9 2.3.2... -
Page 5: Safety | Intended Use
1. Safety | Intended use Please adhere to the following safety instructions to avoid risks when operating loudspeakers. The B10 loudspeaker was developed for use in professional sound systems. The loudspea- ker may only be used by trained and qualified personnel. - Page 6 Operation manual B10 Ensure that the loudspeaker is not exposed to permanent thermal overloads. Thermal over- loads may cause a fire and result in serious personal injury and property damage. WARNING Note that TWAMBO does not provide a warranty for damage that can be attributed to this type of overload and therefore cannot be held liable for any secondary damage.
-
Page 7: Overview
Operation manual B10 2. Overview Components B10 passive B10 active Figure 2.1 - Overview 10“ cone driver 15 mm multiplex housing – Warnex texture paint surface finish M20 pole mount flange for attaching a distance rod Milling for rubber feet for safely stacking loudspeakers... -
Page 8: Variants
(ACTIVE model) and B10P (PASSIVE model). 2.2.1 B10A / B10P model The standard version of the B10 loudspeaker is the B10A variant which can only be operated in „ACTIVE“ mode. It comes with a standard connection panel. The separation takes place in the amplifier DSP. -
Page 9: Operation Modes
Operation manual B10 Operation modes 2.3.1 Selector switch S3 - MONO/STEREO mode One input channel is required for operation in „MONO“ mode. 1. Connect loudspeaker high pass output (TOP A)! Never connect an amplifier to this connector! 2. Switch the switch S3 to „MONO“. -
Page 10: Selector Switch S1 And S2 - Top Output Mode
Operation manual B10 Two input channels are required for operation in „STEREO“ mode. The left input is assigned to pin 1+/-, the right input to pin 2+/-. If only single-channel cables (PIN 1+/-) are used, connect the left channel’s cable to the “Input”... -
Page 11: Technical Data
Operation manual B10 3. Technical data Data sheet Variant B10A B10P Drivers 1x 10“ LF Frequency 40 - 400 Hz 40 - 200 Hz response Power handling 700 / 1400 W 700 / 1400 W (program/Peak) 1x 8 Ω 1x 6 Ω or 2x 12 Ω... -
Page 12: Variant: B10P
Operation manual B10 3.2.2 Variant: B10P TOP A ON TOP A PIN 1+ PIN 1- dual-coil INPUT PIN 2+ 10" PIN 2- MONO MODE TOP B OFF PIN 1+ PIN 1+ PIN 1- PIN 1- LINK REVERSED PIN 2+ PIN 2+... -
Page 13: Commissioning
Operation manual B10 4. Commissioning Setup The B10 loudspeaker is designed for standing operation. Make sure that all system structures are located on a firm, level surface and that the surface can bear the total weight! WARNING Make sure the speakers are securely fastened to prevent personal injury and property damage. - Page 14 6 bft (22 to 27 kn / 39 to 49 kph / 24.2 to 30.45 mph) and that there are no persons in the immediate vicinity of the system structure! WARNING Please note that only centered loads are allowed to be placed on the M20 pole mount flange – Figure 2.1 – Item 2. WARNING Figure 4.2.1 - system setup B10...
- Page 15 Operation manual B10 Figure 4.2.2 - B10 – improper installation Figure 4.2.3 - B10 – improper wall mounting...
-
Page 16: Operation
(1/2) are correct. Incorrect connection can lead to a significant change in the loudspeaker’s sound characteristics and may damage the driver. The pin connections of the B10 loudspeaker can be found in section 3.2 (“Connection dia- gram”) on page 11 and 12. -
Page 17: Transport And Storage
Operation manual B10 5. Transport and storage Due to the B10 loudspeaker weighing over 20 kg [44.09 lbs.], two persons are required to handle and transport the unit. To enable a single person to transport several multiple B10 loudspeakers, TW AUDiO recom- mends using the QDB10 quad dolly. -
Page 18: Ce Conformity Declaration
Operation manual B10 6. CE Conformity Declaration Copy and translation of the original CE Conformity Declaration: We hereby declare that the below-referenced components by virtue of their design and construction, and in the configuration placed on the market by us, satisfy the safety and health requirements of the applicable EC directives. -
Page 19: Disposal
Operation manual B10 7. Disposal It is prohibited to dispose of used electrical equipment with household refuse. All TWAMBO GmbH products are so-called B2B-products. This means that they are sold by a commercial business to a commercial business. TWAMBO products that bear the trash can symbol shown here may only be disposed of by TWAMBO. - Page 20 Operation manual B10 TWAMBO GmbH Karl-Hofer-Str. 42 14163 Berlin Germany Phone: + 49 (0) 71 41-48 89 89 0 Fax: + 49 (0) 71 41-48 89 89 99 E-Mail: info@twaudio.de WWW: www.twaudio.de...
