Summary of Contents for twaudio VERA S33
- Page 1 VERA S33 Operating Manual...
- Page 2 Thank you for choosing a high quality product "MADE IN GERMANY" from TW AUDiO. The VERA S33 is no normal subwoofer. It is literally pointing the way. Its special feature is an 18" speaker at the front and a 15" speaker at the back. With bi- amp operation and the respective presets, different dispersion characteristics can be produced.
- Page 3 VERA S33 Operating Manual Notes on the products Before setting up the device, read the operating manual carefully and keep this docu- Read manual ment in a safe place together with the VERA S33 loudspeaker. before use! General information Operating manual: OM-VERA S33 Version 1.1 en, 09/2016...
-
Page 4: Table Of Contents
VERA S33 Operating Manual Content Safety | Intended use .....................1 Overview ........................3 Components ........................3 Operating modes ........................ 4 Technical data ........................5 Data sheet .......................... 5 Wiring diagram ........................5 Setting up the loudspeaker ..................6 Setup ..........................6 Connecting cables ......................6 Operation .......................... -
Page 5: Safety | Intended Use
Please adhere to the following safety instructions to avoid risks when operating the loud- speakers. The VERA S33 loudspeaker was developed for professional use in sound systems. The loudspeaker may only be used by trained and qualified personnel. Note the operating modes described in this operating manual. - Page 6 VERA S33 Operating Manual Ensure that the loudspeaker is not exposed to permanent thermal overloads. This may cause a fire and result in serious personal injury and property damage. WARNING Note that TW AUDiO does not provide a warranty for damage that can be attributed to this type of overload and therefore cannot be held liable for any secondary damage.
-
Page 7: Overview
VERA S33 Operating Manual 2. Overview 2.1 Components front view rear view Figure 2.1 - Overview Rigging tracks (4 pieces) 18" cone driver (front) Cabinet flange M20 for attaching a distance rod 15 mm multiplex enclosure – polyurea finish Ergonomic carrying handles (two each, on the left and right) Rubber feet (4 pieces) 15"... -
Page 8: Operating Modes
VERA S33 Operating Manual 2.2 Operating modes The VERA S33 can be operated in one of two modes. The operating mode is selected by choosing the preset in the system amplifier. 2.2.1 Cardioid When the cardioid preset is selected, the 15" cone driver (rear) is phase-shifted and time-aligned relative to the 18"... -
Page 9: Technical Data
VERA S33 Operating Manual 3. Technical data 3.1 Data sheet 1x 18" LF front Components 1x 15" LF rear 33 – 120Hz Frequency response 2400 / 4800 W 18" Power handling, program/ 2000 / 4000 W 15" peak 8 Ω 18"... -
Page 10: Setting Up The Loudspeaker
The pin connections of the VERA S33 loudspeaker can be found in section 3.2 “Wiring diagram” on page 5. The two speakON NL4 connectors on the back of VERA S33 can be used to link multi- ple loudspeakers on a single amplifier output. Note that parallel connection reduces the total impedance (Ω) seen by the amplifier. -
Page 11: Operation
VERA S33 Operating Manual 4.3 Operation TW AUDiO recommends operating the VERA S33 loudspeaker with DSP controller. TW AUDiO only recommends using presets developed by TW AUDiO. The TW AUDiO system racks are ideal for this purpose. Ensure that the right preset is loaded before connecting the loudspeaker with the ampli- fier. -
Page 12: Transport And Storage
NOTE To enable a single person to transport up to two VERA S33 loudspeakers, TW AUDiO recommends using the quad dolly QDB30. When transporting and storing the unit, it is important to ensure that the finish and front grill of the loudspeaker are not damaged. -
Page 13: Ce Conformity Declaration
VERA S33 Operating Manual 6. CE Conformity Declaration Copy and translation of the original CE Conformity Declaration: We hereby declare that the below-referenced components by virtue of their design and construction, and in the configuration placed on the market by us, satisfy the safety and health requirements of the applicable EC directives. -
Page 14: Disposal
VERA S33 Operating Manual 7. Disposal It is prohibited to dispose of used electrical equipment with household refuse All products of TW AUDiO GmbH are so-called B2B products. This means that they are sold by a commercial business to a commercial business. TW AUDiO products that bear the trash can symbol shown here are only permitted to be disposed of by TW AUDiO. - Page 15 TW AUDiO GmbH Osterholzallee 140-2 71636 Ludwigsburg Germany P: + 49 (0) 71 41-48 89 89 0 F: + 49 (0) 71 41-48 89 89 99 E: info@twaudio.de W: www.twaudio.de...
