15. Adjustment
+5°
-10°
Maintenance
• Check that the bracket is secure and safe to use at regular intervals(at least every three months).
• Please contact your distributor if you have any questions.
Flat Panel Mobile Cart/Floor Stand and Accessories
200x200/300x300
400x200/400x400
PDS-2011C
600x400/800x400
800x600/1000x600
200x200/300x300
400x200/400x400
PDS-2011S
600x400/800x400
800x600/1000x600
INSTALLATION MANUAL
Optional Accessories
PDS-2505
PDS-2502
PDS-2503
PDS-2504
PDS-2501
PDS-9501
Note: The accessories are not standard.
The accessories will be selected according to user
requirement.
CAUTION:
DO NOT EXCEED
RATED LISTED WEIGHT. SERIOUS
INJURY OR PROPERTY DAMAGE
MAY OCCUR!
All accessories
100"
MAX
100kg
100kg
10kg
10kg
(220lbs)
(220lbs)
(22lbs)
(22lbs)
100"
RATED
RATED
RATED
RATED
MAX
ISSUED: FEB. 2014
