Summary of Contents for HSM Profi Pack P425
- Page 1 OPERATING INSTRUCTIONS Profi Pack P425 1.531.999.202 c – 05/2022...
-
Page 2: Explanation Of Symbols And Safety Instructions
Never pull the plug out of the socket using the power cable. Always pull out the plug directly. vice work may only be carried out by HSM customer service and the service engineers For our customer service addresses see page 168. -
Page 3: Transportation And Installation
• Lock the front castors by pressing down the brake lever. Note: The HSM Profi Pack 425 can also be sup- plied with a built-in suction device. Using a suction device you can extract dust while processing the cardboard. If your device has the built-in suction device, there is a connection for the suction device on the right side (9). -
Page 4: Operation
english 6 Operation Feed in cardboard Switching the system on • Unlock the emergency stop button by turning it anti-clockwise. 425 mm • Move the power switch at the right- hand side to position “I”. “Ready for operation” display fl ashes. The “Ready for operation”... - Page 5 Removing material residue CAUTION Observe the following for all work on the compression fl ap: Wear gloves. Perforating cardboard • Lever (1) is in lower position • Catch bolt is engaged • Feed in the cardboard Padding cardboard • Pull catch bolt (1) •...
-
Page 6: Troubleshooting
This makes the cutting unit run forwards you contact your local authorities at the slowly and shreds the remaining cardboard. appropriate time. As the manufacturer, HSM During this function, the “Ready for would be glad to advise you on the disposal operation”... -
Page 7: 10 Technical Data
english 10 Technical data Grid dimension 5 x 100 mm Cutting capacity Up to 3 positions Operating speed 8.5 – 14.0 m/min Working width 425 mm Infeed height 20 mm Power supply 100V-240V / 50-60Hz , 220V-240V / 50-60Hz Operating mode Continuous operation max. - Page 8 Fax +33 472 517481 HSM Vertrieb Österreich france@hsm.eu austria@hsm.eu www.hsm.eu HSM Vertrieb Schweiz schweiz@hsm.eu HSM Técnica de Ofi cina y HSM Verkoop België, Nederland,Luxemburg Medioambiente España, S.L.U. benelux@hsm.eu Calle de José Echegaray, 10 HSM Commerciale Italia 28100 Alcobendas, Madrid italia@hsm.eu Spain Tel.
