Edsal PREMIER 7224PRBWWD3 Manual

Safety Instructions
Follow these instructions carefully, failure to do so can result in
property damage or personal injuries. Caution: contains small
parts, keep children away during installation. This unit should be
placed on a level surface. Failure to do so can result in poor
product performance or create a possible safety hazard. This
unit should be securely anchored to a wall or floor with suitable
fasteners, not included.
DO NOT STAND ON ANY PART OF
THE UNIT, OR USE IT AS A LADDER.
DO NOT MOUNT CASTERS TO THIS
UNIT. DO NOT USE THIS UNIT TO
STORE AQUARIUMS.
Use care when working with metal
parts. Wear gloves for protection.
Do not exceed the maximum weight capacity of 1,500 lb. (kg)
per shelf (not to exceed 6,000 lbs for the entire unit). Always
evenly distribute the weight on each level and keep the heavier
loads on the bottom.
Do not use this unit for anything other than the manufacture's
intended purpose. Keep this manual for future reference.
General Instructions
Before beginning assembly, read through all instructions and
make sure all parts are present. Assembly of this unit is done by
fitting the inside bracket tabs of the beam ends into the post
slots of the end frames. The bracket tabs should engage and fit
firmly into the tapered slot of the post frame. This engagement
is a tight swaged fit and will apply resistance as it fully engages.
A visual inspection should be made to show that the bracket is
properly engaged in the slot.
A rubber mallet should be used on the ledge of the beams to
properly seat the beam bracket tabs. If a hammer is used care
should be taken to protect the beam surface to avoid damage by
using a protective cloth or block of wood.
The stepped surface of the beam ledge is the top, and should
face upwards. This is the surface that the wire deck will rest on.
The beam will have small rounded holes on the top ledge and
long slotted holes on the bottom ledge. The long slotted holes
will be used to secure the tie channel to the beams.
After assembly re-check each beam for proper engagement.
3-LEVEL WELDED STEEL STORAGE RACK
77"W x 24"D x 72"H
Contents
Helpful Items for Assembly (not included)
Warranty
Edsal Manufacturing Company, LLC products are guaranteed for a
period of one (1) year from the date of purchase. The SOLE AND EX-
CLUSIVE REMEDY for such defects is the repair or replacement of a
defective product or parts thereof by Edsal Manufacturing Company,
LLC or, at Edsal Manufacturing Company, LLC option, refund of the
purchase price upon return of the item to Edsal Manufacturing Com-
pany, LLC. This warranty shall not apply in the event the products are
damaged as a result of misuse, neglect, accident, moisture, improper
application, improper assembly, or assembly not in conformity with
the instructions of Edsal Manufacturing Company, LLC, failure to
abide by safety precautions prescribed by Edsal Manufacturing Com-
pany, LLC or modification or repair by persons not authorized by
Edsal Manufacturing Company, LLC.
A: end frame
E: canoe clip
Description Quantity
A: End frame
B: Beam
C: Tie Channel
D: Wire Deck
Hardware Kit:
Includes (12) canoe clips (E), (18) bolts (F), (18) nuts (G)
Rubber Mallet,
Screwdriver, Wrench,
Gloves
Model: 7224PRBWWD3
B: beam
C: tie channel
D: wire deck
F: bolt
G: nut
Part Number
2 ERFR2472-BLK
6 ERBM72-BLK
9 ERTBV624-BK
3 2472W-S
