Edsal Muscle Rack URWB-3 Quick Start Manual

Safety Instructions Safety Instructions
Safety Instructions
These units should be placed on a level surface. Failure to do so can result in poor product performance or create a
possible safety hazard. This unit should be securely anchored to a wall or floor with suitable fasteners, which are not
included. Do not use this unit for anything other than the manufactures intended purpose. DO NOT STAND ON ANY
PART OF THE UNIT, OR USE IT AS A LADDER. Evenly distribute the weight on each level and always keep the
heavier loads on the bottom. Use care when working with metal parts.
General Instructions
General Instructions General Instructions
Assembly is done with the rivets of the beams and braces fitting into the slots of the post. A rubber mallet may be used
on the beams and braces to seat the rivets properly. A hammer can also be used, providing one uses a cloth or a block
of wood between the hammer head and the parts to prevent damage. Tap gently and be sure the rivets are straight and
fully engaged.
Should you have any comments, damage, missing parts, or problems with assembly of this unit please feel
free to contact our Edsal manufacturing facility at, (773) 475-3000 and request customer service. We can
also be reached on the internet at the following email address : customerservice@edsal.com.
To obtain replacement parts, please provide the following information :
- Model # - Part # & Description
Heavy Duty 3'
1 Drawer Work Bench
URWB URWB
URWB
Description
Top Back Post Right
Top Back Post Left
Bottom Back Post
Front Post
Braces
Beams
Left Top Support Extension
Right Top Support Extension
Top Shelf Flat Beam
Left Drawer Mount
Right Drawer Mount
Left Drawer Slide
Right Drawer Slide
Front Drawer Shelf Brace
Back Drawer Shelf Brace
Steel Peg Board
Laminate Shelves
Laminate Drawer Shelf
Laminate Top Shelf
Nuts, Bolts, Washers
Handle
Wall Anchor
Post Connector
- Location Purchased - Date Purchased
- - 3 3 Shelf 1 Drawer 3 3 Shelf 1 Drawer
- 3 3 Shelf 1 Drawer
Qty. Part Number
1 RUPTSPR3702S
1 RUPTSPL3702S
2 RUPTSP3802S
2 RUPT3502S
4
4
1 RWTE0902L
1 RWTE0902R
2
1 SVRWDM1705L
1 SVRWDM1705R
1 SVRWDS1403L
1 SVRWDS1403R
1 SVRWDB3102F
1 SVRWDB3102B
2 SPGBD1536
2 RPB21836LM
1 RPB31011LM
1 RPB2369LM
8
1
2
1
Consumer Products Division
Edsal Manufacturing Company
4400 South Packers Avenue
Chicago, IL 60609
MADE IN CHINA
MODEL NUMBER
URWB - 3
- - 72"h x 18"d x 36"w 72"h x 18"d x 36"w
- 72"h x 18"d x 36"w
Part Size
36"
36"
38 3/8"
35"
RUBE1702 18"
RUBE3502 36"
9"
9"
RMBE3502 36"
N/A
N/A
N/A
N/A
31"
31"
15 3/4" x 36"
18" x 36"
11" x 31"
9" x 36"
NB8 N/A
HDL1000 N/A
N/A N/A
N/A N/A
Required Tools
Required Tools Required Tools
- Rubber Mallet
www.edsal.com
