Edsal MRWB-4 Quick Start Manual

Heavy Duty Work Bench
Safety Instructions Safety Instructions
Safety Instructions
These units should be placed on a level surface. Failure to do so can result in poor product performance or create a
possible safety hazard. This unit should be securely anchored to a wall or floor with suitable fasteners, which are not
included. Do not use this unit for anything other than the manufactures intended purpose. DO NOT STAND ON ANY
PART OF THE UNIT, OR USE IT AS A LADDER. Evenly distribute the weight on each level and always keep the
heavier loads on the bottom. Use care when working with metal parts.
General Instructions General Instructions General Instructions
Assembly is done with the rivets of the beams and braces fitting into the slots of the post. A rubber mallet may be used
on the beams and braces to seat the rivets properly. A hammer can also be used, providing one uses a cloth or a block
of wood between the hammer head and the parts to prevent damage. Tap gently and be sure the rivets are straight and
fully engaged.
Should you have any comments, damage, missing parts, or problems with assembly of this unit please feel
free to contact our Edsal manufacturing facility at, (773) 475-3000 and request customer service. We can
also be reached on the internet at the following email address : customerservice@edsal.com.
To obtain replacement parts, please provide the following information :
- Model # - Part # & Description
Heavy Duty 4'
1 Drawer Work Bench
- Location Purchased
MRWB - 4 3 Shelf 1 Drawer
MRWB MRWB - - 4 3 Shelf 1 Drawer 4 3 Shelf 1 Drawer
Description
36" Post (Top Back)
36" Post (Bottom Front)
Brace
Beam
24" Post (Bottom Back)
Top Shelf Support
Drawer Mount
Drawer Slide
Drawer Shelf Braces
Peg Board
Wood Shelf
Wood Drawer Shelf
Wood Top Shelf
Hardware
- Date Purchased
MODEL NUMBER
MRWB - 4
- 60"h x 24"d x 48"w
- - 60"h x 24"d x 48"w 60"h x 24"d x 48"w
Qty. Part Number
2 HWPT3602T
2 HWPT3602
4 RWBE2303
5 RWBE4703
2 HWPT2402
1 RWSS4803
2 RWDM2305
2 RWDS2003
2 RWDB4302
1 PGBD4820
2 RLPB2448
1 RPB43017
1 RPB2489
4 NB4
Consumer Products Division
Edsal Manufacturing Company
4400 South Packers Avenue
Chicago, IL 60609
Part Size
36"
36'
24"
48"
24"
48"
N/A
N/A
43"
20" x 48"
24" x 48"
17" x 43"
9" x 48"
#10-24
www.edsal.com
