Vanatoo TRANSPARENT ONE ENCORE PLUS Quick Start Manual

TRANSPARENT ONE ENCORE PLUS
VANATOO
®
POWERED SPEAKERS
Quick Start Guide
1

Unpack Your System

1) Active speaker
2) Passive speaker
3) 2 Grills
4) IR remote control
5) Optional isolation feet
6) USB A to USB B cable
2

Connect the Speakers

The included speaker interconnect cable with screw-on collar
connectors makes this quick and easy.
3

Connect Power

Make sure the power switch (2) is in the OFF position.
1.
2. Plug the AC power cord into the active speaker.
3. Plug the AC power cord into the power outlet.
4

Connect Your Audio Source

Turn the volume controls on the speaker (1) and on the audio
source both to minimum.
1. Analog (3) — Connect your source using the included
using 3.5mm to 3.5mm cable or 3.5mm to RCA cable as
appropriate for your source component.
2. Digital Coax (4) — Connect your source component using a
75 ohm digital coaxial RCA cable.
3. Optical (5) — Connect your source component to the
Vanatoo T1E Plus using a Toslink optical cable.
4. USB (6) — Connect your computer to the T1E Plus using
the supplied USB A to USB B cable. Select the Vanatoo
T1E Plus in your computer's audio settings.
5. Bluetooth —
a. Press and release the "Pair-Prog" button (7) on the
rear of the active speaker, or press "Enable" and
then "BT Pair" on the remote control. The bluetooth
interface will remain in pair mode for 2 minutes.
b. Ensure Bluetooth is turned-on on your source
device and pair with the Vanatoo T1E Plus.
c. Ensure your source device is connected to the
Vanatoo T1E Plus over Bluetooth and play music!
™
7) 3.5 mm to 3.5 mm cable
8) Four conductor
speaker wire
9) 3.5 mm to RCA "Y" cable
10) AC power cord
11) Quick Start Guide and a
Safety Sheet
1 2
6
5
4
1
PAIR-PROG
3
7
8
9
3
8 9
7
10
100-240V-50/60 Hz 148W
SERVICE
™
2
4
5
6
TURN OVER
