4. Assembly/Adjustments

Your new Bischoff & Bischoff wheelchair will be delivered in a Bischoff
& Bischoff original cardboard box, assembled and folded.
In order to avoid transport damage, detachable attachments are
delivered separately with the product.
Refer to the technical data to see which options are possible on your
3.
wheelchair (see Chapter 5).

4.1. Folding and unfolding

Unfolding
• Position the folding wheelchair next to you (Fig. 3).
• Tip the wheelchair towards you until the weight is off one of the
drive wheels.
4.
• Push the seat tubes apart and push them down with the flat of
your hand, until they lock into place in the bracket on the frame
(Fig. 4).
• The seat pad must be completely unfolded.
• Apply the left and right parking brakes on the drive wheels.
• Fit the legrests.
• You can now sit down.
Folding
• Position the folding wheelchair next to you.
5.
• Flip the footplates up (Fig. 5).
• Remove the seat cushion if one is fitted, take hold of the front and
rear of the seat upholstery and pull it up.
66 66
| Lightweight wheelchair
When folding and unfolding, watch your fingers
as there is a risk of pinching.
Lightweight wheelchair |

4.2. Legrests

4.2.1. Swing-away legrests

You can flip the footplates up separately to the side and adjust to the
lower leg length of the user. You can remove the legrests, swing them
away and refit them without needing to use tools.
Attach legrests
• Hold the top of the legrest so that it is pointing outwards.
• Guide the legrest into the hole in the frame using the guide bolts
(Fig. 6).
• Swing the legrest to the front until you hear it clearly click into
place (Fig. 6).
• Flip the footplate down if necessary.
Swing the legrests away and remove them
In order to make it easier to transfer to and from your folding
wheelchair, you can swing the legrests inwards or outwards, without
having to remove them.
• Flip the footplate up if necessary.
• Pull the handle upwards and swing the legrest outwards (Fig. 7/8).
• In the outward position, the legrest can be pulled out by pulling it
upwards (Fig. 8).
Before setting off, fit the legrests as described above.
Never stand on the footplate and when swinging
it away, watch your fingers as there is a risk of
pinching.
Bischoff & Bischoff GmbH |2023-11-15 - Revision: 4
Pyro Light Optima
Pyro Light Optima XL
6.
7.
8.
67 67
