Integrated Esoteric disc players -

Chip sets, key features and

proprietary transport comparisons

Rev 3

Need help?

Do you have a question about the SA-10 and is the answer not in the manual?

Questions and answers

Summary of Contents for Esoteric SA-10

Page 1 Integrated Esoteric disc players - Chip sets, key features and proprietary transport comparisons Rev 3...
Page 2 VRDS-Neo = Vibration free rigid disc clamping system – New. VRDS-VMKV = New entry level VRDS assembly used in the X-05 and P-05. VOSP = Vertically aligned optical stability platform ‘Z series’ SZ-1 Transport = VOSP (CD/SACD/DVD-A/DVD-V compatible) ‘Z series’ UZ-1 VOSP ‘SA series’ SA-60 SA-10 VOSP ‘DV series’ DV-60 VOSP...
Page 3 - Mid range (low profile design) - 2-channel analog output - CS4398 x1 (2 out/chip = 2ch) - i.LINK ‘SA’ SA-60 SA-10 VOSP SA-60 Mid range - Multi-channel analog output - Dual mono plus multi-channel - CS4398 x 3 (2 out/chip = 5.1ch)
Page 4 Universal players (CD/SACD/DVD-A/DVD-V compatible) ‘UX’ UX-1Pi/UX-1Ltd. UX-3Pi VRDS-NEO UX-1Pi/UX-1Ltd. - Super high end - Multi-channel analog output - PCM1704 x4 (2 x 2ch) - PCM1704 x4 (1 x 3.1ch) - i.LINK - HDMI 1080p extended mode UX-3Pi - High end - 2-channel analog output - PCM1704 x4 (2 x 2ch) - i.LINK...
Page 5 VRDS-Neo VMK1.1 = Vibration Free Rigid Disc Clamping System VOSP = Vertically aligned optical stability platform X-01D2 UX-1Pi X-03SE UX-3Pi/SE X-05 (P-05) - Duralumin turntable - Custom ceramic ball bearings - RoHs VOSP pickup - SS400 Steel T:20 mm bridge - Pressed steel mechanism base - SS400 + Al 2 piece bridge support - Shutter and aluminum tray...
Page 6 VOSP SZ-1 UZ-1 SA-60 DV-60 SA-10 - RoHs VOSP pickup - Aluminum tray - 3 series optical assembly - RoHs VOSP pickup - Resin tray with aluminum tray cap - Steel cover with 8mm stabilizer - Highly rigid bracket mount to chassis...
Page 7 X-03SE/PCM1704 x4 (2 x 2ch) X-05/CS4398 x4 (2 x 2 ch) Chip Chip ‘Z’ SZ-1 CS4398 x1 (2out/chip =2ch) 1 ch CS4398 1 ch ‘SA’ SA-60 CS4398 x3 (2out/chip =5.1ch) 1 ch CS4398 1 ch SA-10 CS4398 x2 (1 x 2ch) CS4398...
Page 8 Universal (DVD audio video compatible) - DAC - ‘UX’ UX-1Pi/UX-1 Ltd. PCM1704 x4 (2 x 2ch) PCM1704 x4 (1 x 4ch) 1704 1704 1 ch 1704 UX-3Pi/UX-3SE PCM1704 x4 (2 x 2ch) 1704 1704 ‘Z’ UZ-1 CS4398 x1 (2out/chip =2ch) 1 ch CS4398 1 ch...
Page 9 - Up-convert: x8 (FIR) / x32 (RDOT+FIR) - DSD direct: yes - PCM to DSD convert: yes - DSD to PCM convert: n/a SA-10 - DF: Wide / Narrow - Up-convert: x8 (auto) - DSD direct: yes - PCM to DSD convert: n/a...
Page 10 Universal (DVD-A/V compatible) - Digital Filter / DDC ‘UX’ UX-1Pi DF: On (narrow) / Off Up-convert: x8 (auto) DSD direct: n/a PCM to DSD convert: n/a DSD to PCM convert: n/a UX-3Pi DF: On (narrow) / Off Up-convert: x8 (auto) DSD direct: n/a PCM to DSD convert: n/a DSD to PCM convert: n/a...
Page 11 Universal (DVD-audio video compatible). Video Control ‘UX’ UX-1Pi UX-3Pi Video DAC: Analog Devices ADV7324 (14bit/216MHz) Scaler: Anchor Bay ABT1018 I/P converter: Genesis FLI2310 480i(576i)/480p(576p) 720p/1080i/1080p HDMI: version 1.3 RS-232C: yes Trigger In: n/a Remote In: n/a ‘Z’ UZ-1 Video DAC: Analog Devices ADV7314 (14bit/216MHz) Scaler &...
Page 12 Integrated Disc Player Comparisons...
