G509 Relay GPS Tracker
User Manual
Preface
Thank you for purchasing the tracker. This manual shows how to operate the
device smoothly and correctly. Make sure to read this manual carefully
before using this product. Please note that specification and information are
subject to changes without prior notice in this manual.
Any change will be integrated in the latest release. The manufacturer assumes
no responsibility for any errors or omissions in this document.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the G509 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for COBAN GROUP G509

Summary of Contents for COBAN GROUP G509

  • Page 1 G509 Relay GPS Tracker User Manual Preface Thank you for purchasing the tracker. This manual shows how to operate the device smoothly and correctly. Make sure to read this manual carefully before using this product. Please note that specification and information are subject to changes without prior notice in this manual.

  • Page 2: Quick Using

    ◆Quick using 1）Open device case, proper insert GSM card, connect external power supply. 2）Put device outside, around 30s three lights will keep lighting on stands for device can work normally. 3）Dialing device number, it will hang up and reply tracking message with valid Longitude and latitude.

  • Page 3: Installation Attentions

    ◆Installation attentions NOTE: device front side towards the sky. When install in car, if the windscreen glued by metal thermal insulation layer or heating layer, it will reduce the GPS receive signal and lead to GPS work disorder. Device light description Light Represents yellow...

  • Page 4: Installation Instructions

    1.Installation instructions 1.1 Preparation 1.1.1 Open the package to check the device model number is correct, be with full accessories, or else please contact your supplier.
  • Page 5 Choose SIM card, need insert a GSM SIM card into the device, please refer to the suggestion of your supplier for SIM card choice. Notice: Please insert SIM card before turning the device power switch to on; The SIM card need open the GPRS function; Please make sure SIM card with full balance.
  • Page 6 ◆Attentions ◆Device light 1）No yellow light: failed to read SIM card, need reinstall SIM card. 2）Blue light flash: no GPS signal, make sure device started outside. 3） Three lights off: lights entered sleep mode, make a call or move device can wake up. ◆Device failed located...
  • Page 7 1） Failed located: message replied with all 0, make sure device started outside not in room. 2）Can’t reach the call: make sure SIM card has balance and installed Properly and opened the switch. ◆Device can’t track on platform 1) Check three lights are stable on. 2) Make sure device can work and reply valid tracking long&Lat in SMS.
  • Page 8 3.Authorized number (All alarm messages will be sent to authorized number only) Text command Parameter Example Add Authorized number #admin#123456#phone number# #admin#123456#18575518750# Command Feedback admin ok Del Authorized number #noadmin#123456#phone number# #noadmin#123456#13409877890# Command Feedback noadmin ok（If notified not admin number,send #super# please） 4.Set password Text command Parameter...
  • Page 9 7.Set all alarm mode Text command Parameter Description Command #KC#123456#0# To close alarm function Command #KC#123456#1# Alarm will reply only SMS Command #KC#123456#2# Alarm will reply only call back Command #KC#123456#3# Alarm will reply via SMS and call 8.Timezone Setting Text command Parameter Example...

  • Page 10: Vibration Alarm

    the authorized number. 11.Overspeed alarm Text command Parameter Example Command #speed#password#speed number in #speed#123456#060# 3 digits# Command Feedback speed ok Sample means When the car moves exceeding 60 km/h, the unit will send Command description SMS alert “speed alarm +imei+ Coordinates ” to the authorized number. 12.Vibration alarm Text command Parameter...
  • Page 11 14.Power failure alarm If device was removed from car battery, device will end SMS “cut power Description alert! +IMEI number+Long&Lat” to the authorized number. Web based platform www.gpstky.net further details please contact manufacturer. 1.Setting APN 1.1 APN standards for Access Point Name and differs from country to country. For more information about the local APN, inquiry from your local GPRS network operator.

  • Page 12: Troubleshooting

    4.Cautions Please comply with the instructions to extend the unit life: 1. Keep the unit dry. Any liquid, i.e. rain, moisture, may destroy or damage the inside circuitry. 2. Don’t use & store the unit in dusty places. 3. Don’t put the unit in overheated or overcooled places. 4.
  • Page 13 Q: Can overseas customers use it? A: Overseas customers need to set up APN to use it normally. Request to send SMS "#apn#123456#APcontent#APNUsername#APN Password#" and send it to the sim card in the device, cmnet is the mainland operator APN, other operators please replace the corresponding APN, please consult your area APN SIM card Details of the operator.
