Safety and Warranty
Please see https://omcan.com/disclaimer for complete info.
WARNING:
The packaging components are classified as normal solid urban waste and can therefore be disposed of
without difficulty.
In any case, for suitable recycling, we suggest disposing of the products separately (differentiated
waste) according to the current norms.
DO NOT DISCARD ANY PACKAGING MATERIALS IN THE ENVIRONMENT!

Technical Specifications

Model
Power
Capacity
RPM
Electrical
Dimensions
Weight
Item Number
Installation
SETTING UP OF THE MACHINE
The machine must be installed on a working table suitable for its overall dimensions, therefore it must be
adequately large, well levelled, dry, smooth, resistant, stable. Moreover the machine must be installed in a
room with max. 75% not saline humidity at a temperature between +5°C and +35°C; that is to say in a place
that does not provoke the machine failure.
ELECTRICAL CONNECTIONS
The appliance is equipped with a power supply cord which section 3x1.5mm², length 1.5m with a "NEMA"
plug. Connect the appliance to 110 Volt 60 Hz, by interposing a differential magnetothermic switch of 10A, Δ I =
0.03A. Check that the earthing is fully operational. Moreover check that the features on the rating plate - serial
FP-IT-0009
1 HP / 0.74 kW
8.5 L / 9 QT
1700 - 2800
110V / 60Hz / 1
17.9" x 14" x 15" / 455 x 355 x 380mm
50.7 lbs. / 23 kgs.
10834
6
