Omcan FP-IT-0009 Instruction Manual page 12

Parts Breakdown
Model FP-IT-0009
Item No. Description
16995 Shaft with Regular Knives for C9
37186 Rod Holder Pin for C9
37187 Clutch Washer for C9
37188 Frame Head for C9
37150 Clutch Base for C9
37151 Clutch Nut for C9
37152 Microswitch Cam for C9
61573 Cup Spring 12.2x25x0.7 for C9
37189 Arm Knob for C9
37190 Arm for C9
AC005 Steering Wheel Spacer for C9
37191 Bowl Guide for C9
AC006 Screw TSP + DIN 965 M4x20 for C9
18967 Lid with Gasket for C9 from OCT 03
37192 Lid Plug for C9
37193 Blade Holder Pin for C9
37194 Blade Holder for C9
64402 Door Knife for C9
16463 Upper Knife for C9
37209 Punched Upper Knife for C9
64404 Dough Upper Knife for C9
10834
Position Item No. Description
00 64403 Upper Knife for C9
02 37210 Serrated Upper Knife for C9
04 37195 Knife Spacer for C9
06 64405 Knife Spacer for C9
08A 16464 Lower Knife for C9
10 37211 Punched Bottom Knife for C9
12A 37212 Lower Serrated Knife for C9
15 AC007 Screw Holder for C9
18 26125 Bowl for C9
20 19350 Gum for C9 until 1999
27 AC004 Screw TC + DIN 7985 M5x12 for C9
28 37196 Frame Body for C9
30 37197 Stainless Steel Plate for C9
52 17765 Aluminum Shaft for C9
54 37198 Pulley Assembly for C9
60 AC008 Screw DIN 916 M8x10 NE for C9
62 19359 Belt for C9
62P 60294 Foot for C9
64 37199 Bottom Safety Grate for C9
64F 37200 Small Pulley for C9
64P 16494 Motor 110/60 for C9
Position Item No.
64V 64406
64Z 60296
68 60297
68P 37339
72 37180
72F 37202
72Z 37203
74 19360
76 AB998
80 19352
82 19353
90 AB999
102 AC000
104 37205
108 37176
110 37206
112 37178
114 17197
116 AC009
125 37207
136A AC010
12
Description Position
Motor Support for C9 160
Bowl Scraper Red for C9 170
Sharpening Stone for C9 174
Power Cord 110/60 USA for C9 200C
Strain Relief for C9 202
Speed Control Knob for C9 236
Speed Control Label for C9 238
110/60 Control Board + Variable
256B
Speed Drive for C9
Screw TC + DIN 7985 M3x16
260
for C9
Mechanical Microswitch for C9 262
Microswitch Holder for C9 264
Nut ES. DIN 439 M3 Lower for C9 268
Screw TSP + DIN 965 M3x8 for C9 270
Mechanical Microswitch for C9 276+272
Terminal Board for C9 280
Filter for C9 286
Lever Microswitch for C9 292
Control Panel Assembly for C9 600A
Large Button Mounting Body Y18
600B
for C9
Switch Gasket for C9 602
Circuit Board 110/60 Y18 for C9 604B
