Operator's Manual
TWOPLEX
2-Man
Ladder Stand
MODEL RE665
Maximum Height
17' 1" to shooting rail
Maximum Field Rating
500 lbs; no more than
300 lbs per person.
Tree Diameter Range
12" to 20"
Wear Your Harness!
© 2022 RETI
C/N: 32690, 41452
All Rights Reserved
REV2: 01/31/22
P/N: 32692

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RE665 and is the answer not in the manual?

Questions and answers

Related Manuals for Rivers Edge Treestands RE665

Summary of Contents for Rivers Edge Treestands RE665

  • Page 1 Operator's Manual TWOPLEX WE ARE HUNTERS 2-Man Ladder Stand MODEL RE665 Maximum Height 17' 1” to shooting rail Maximum Field Rating 500 lbs; no more than 300 lbs per person. Tree Diameter Range 12" to 20" Wear Your Harness! PRODUCT MEETS...

  • Page 2: Table Of Contents

    Operator's Manual TWOPLEX 2-Man Ladder Stand INTRODUCTION Rivers Edge® Treestands are engineered with you the hunter in mind. We appreciate your purchase of one of our world class treestands. Follow these few simple instructions and your stand will provide you many years of trouble-free pleasure.

  • Page 3: Warnings

    Operator’s Manual TWOPLEX 2-Man Ladder Stand READ AND UNDERSTAND THE FOLLOWING WARNINGS BEFORE ASSEMBLY STOP MODEL RE665 WARNING MAXIMUM USE HEIGHT - 17' 1” TO SHOOTING RAIL Never jump or bounce on a treestand to seat it to the tree.

  • Page 4: Inspection And Maintenance

    Operator's Manual TWOPLEX 2-Man Ladder Stand WARNING INSPECTION AND MAINTENANCE Always lean forward as you climb and attach your harness BEFORE EACH USE PERFORM THE FOLLOWING: to the tree before securing the platform to the tree and stepping onto the platform. •...

  • Page 5: Hardware Identification Chart

    Bolts shown are for size reference. HARDWARE IDENTIFICATION CHART Extra hardware may be included in the parts bag. Quick Tip: Cut page out to use as a reference tool while following assembly instructions 1/4-20 X 1-1/4 IN Bolt - Qty 2 1/4-20 X 1-1/2 IN Bolt - Qty 8 1/4-20 Nut M6 Yellow Washer...

  • Page 7: Assembly Instructions

    Operator’s Manual TWOPLEX 2-Man Ladder Stand ASSEMBLY INSTRUCTIONS IMPORTANT ASSEMBLY TIP: All assembly must be done in this order at ground Do not tighten any nut and bolt combinations completely level before uprighting. until all parts are assembled together! Finger tighten plus one Do not remove labels/warnings from product, they turn of a wrench only! This will temporarily hold the lock nut on the bolt while helping alignment of all parts! After all parts...
  • Page 8 Operator's Manual TWOPLEX 2-Man Ladder Stand 4. Attach left (7) and right (8) seat supports to platform sections (6) using four 1/4-20 x 2-1/4 IN bolts (27) and locknuts (29). SEE FIGURE 3. 5. Attach platform braces (17) to platform section (6) and both left (7) and right (8) seat supports using four 1/4-20 x 1-1/2 IN bolts (25) and locknuts (29).
  • Page 9 Operator’s Manual TWOPLEX 2-Man Ladder Stand 8. Secure rear of the Teartuff seat assembly (31) to left (7) and right (8) seat supports using two 1/4-20 x 2-3/4 IN bolts (30), yellow plastic washers (21), plastic spacers (19) and locknuts (29). SEE FIGURE 5. NOTE: Be sure hardware is oriented as shown in FIGURE 5.
  • Page 10 Operator's Manual TWOPLEX 2-Man Ladder Stand 10. Slide top tree blade (11) through sleeve on rear of Teartuff seat assembly (31) so that top tree blade is centered on hole in Teartuff seat assembly (31). Install top tree blade (11) into brackets on ends of seat support (10) and secure using four 1/4-20 x 1-3/4 IN bolts (26) and locknuts (29).
  • Page 11 Operator’s Manual TWOPLEX 2-Man Ladder Stand 12. Install M6 knobs (23) and M6 bolt (22) onto left (7) and right (8) seat supports. SEE FIGURE 9. 13. Attach shooting rail assembly (14 and 15) to left (7) and right (8) seat supports using two 1/4-20 x 2-3/4 IN bolts (30), yellow plastic washers (21), plastic spacers (19) and locknuts (29).
  • Page 12 Operator's Manual TWOPLEX 2-Man Ladder Stand 17. Ladder sections are assembled on the ground in the following order: bottom ladder section (4), middle ladder section (3) and the top ladder section (2) with the treestand top assembly. Connect all sections together using the six lockpins (20).
  • Page 13 Operator’s Manual TWOPLEX 2-Man Ladder Stand 20. Attach the two long ends of the 16’ criss-cross straps (39) to the bottom tree blade (12). These long stabilizer straps should be attached by pulling the free end of the strap through the loop end of the strap to create a cinch knot around the frame tube.

  • Page 14: Warnings

    Operator's Manual TWOPLEX 2-Man Ladder Stand READ AND UNDERSTAND THE FOLLOWING WARNINGS BEFORE SETUP AND USE STOP WARNING WARNING Double check assembly steps to be certain you have Always maintain three (3) points of contact when climb- correctly assembled this product. ing a ladder treestand.

  • Page 15: Setup And Use Instructions

    Operator’s Manual TWOPLEX 2-Man Ladder Stand SETUP AND USE INSTRUCTIONS WARNING During installation and removal of ladder treestands, you must always and properly use the included Full Body Harness (Fall Arrest System). Refer to the Full Body Harness instructions Never use a treestand on a dead, leaning, diseased included with this product for proper use.
  • Page 16 Operator's Manual TWOPLEX 2-Man Ladder Stand 10. Make sure the criss cross straps and stabilizer bar strap are snug and the tree blades are still both contacting the tree. NOTE: This ground level ladder-to-tree attachment will prevent the ladder from pulling away from the tree while ascending to the top for final two 6’...

  • Page 17: Finished Ladder

    Operator’s Manual TWOPLEX 2-Man Ladder Stand FINISHED LADDER RATCHET STRAP PADDED FLIP-BACK SHOOTING RAIL RATCHET STRAP PLATFORM CRISS CROSS STRAPS STABILIZER BAR CAM STRAP LOCKPIN LADDER ATTACHMENT STABILIZER BAR Check for parts online at www.HuntRiversEdge.com or call 800-345-6007...

  • Page 18: Illustrated Parts Breakdown

    Operator's Manual TWOPLEX 2-Man Ladder Stand ILLUSTRATED PARTS BREAKDOWN 13 19 Check for parts online at www.HuntRiversEdge.com or call 800-345-6007...
  • Page 19 Operator’s Manual TWOPLEX 2-Man Ladder Stand PARTS LIST ITEM # PART # DESCRIPTION QTY. 28839 KNOB M6 27397 STABILIZER BAR 29712 SQUARE PLUG 22 MM 28708 TOP LADDER SECTION 48240B BOLT 1/4-20 X 1-1/2 IN 28710 MIDDLE LADDER SECTION 48250B BOLT 1/4-20 X 1-3/4 IN 28712 BOTTOM LADDER SECTION...
  • Page 20 WE ARE HUNTERS Rivers Edge® Treestands, Inc. Phone: 800-345-6007 1730 Industrial Avenue, PO Box 755 Fax: 715-822-2124 Cumberland, WI 54829 www.HuntRiversEdge.com *All weights, specifications and features are approximate and are subject to change without notice. Due to continuous product improvements, product images may not be exact. Warning labels in some product images may have been removed for photography purposes only.
