Rivers Edge Treestands RELAX WIDE RE631 Operator's Manual

One-man ladder stands
Hide thumbs

Advertisement

Quick Links

Download this manual
Operator's Manual
One-Man
Ladder Stands
PACK-N-STACK™
JUMBO JACK™
Model RE622
Model RE628
RELAX™ WIDE
Model RE631
Wear Your
Harness!
INCLUDES MODEL #'s:
GAS/OIL
RATIO
50:1
RE622, Pack-N-Stack™
RE627, Oasis™
RE628, Jumbo Jack™
RE631, Relax™ Wide
P/N: OMRELD001
REV3: 02/17/15
Get parts online at
© 2015 RETI
www.HuntRiversEdge.com
All Rights Reserved.

Advertisement

loading
Need help?

Need help?

Do you have a question about the RELAX WIDE RE631 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Rivers Edge Treestands RELAX WIDE RE631

Summary of Contents for Rivers Edge Treestands RELAX WIDE RE631

  • Page 1 Operator's Manual One-Man Ladder Stands PACK-N-STACK™ JUMBO JACK™ Model RE622 Model RE628 RELAX™ WIDE Model RE631 Wear Your Harness! INCLUDES MODEL #'s: GAS/OIL RATIO 50:1 RE622, Pack-N-Stack™ RE627, Oasis™ RE628, Jumbo Jack™ RE631, Relax™ Wide P/N: OMRELD001 REV3: 02/17/15 Get parts online at ©...

  • Page 2: Warranty

    Operator's Manual Rivers Edge® One-Man Ladder Stands INTRODUCTION Rivers Edge® Treestands are engineered with you the hunter in mind. We appreciate your purchase of one of our world class treestands. Follow these few simple instructions and your stand will provide you many years of trouble-free plea- sure.
  • Page 3 Operator's Manual Rivers Edge® One-Man Ladder Stands WARNINGS WARNING WARNING DO NOT USE THIS PRODUCT UNTIL YOU HAVE WATCHED REPLACE ANY AND ALL TREESTAND STRAPS EVERY TWO THE INCLUDED TREESTAND SAFETY DVD, UNDERSTAND YEARS OR WHEN ANY SIGNS OF DAMAGE OR WEAR EXIST IT AND PRACTICED THE TECHNIQUES FOR SAFE HUNTING BEFORE.

  • Page 4: Inspection And Maintenance Schedule

    Operator's Manual Rivers Edge® One-Man Ladder Stands ALWAYS… INSPECTION AND MAINTENANCE SCHEDULE • Be physically fit, mentally alert, and well rested before using this product. FOR ALL RIVERS EDGE® PRODUCTS • Read, understand and follow all warnings and instructions before • Inspect all webbing, rope, cord, and strap assemblies for wear or use and save for future reference. damage. • Use the provided Full Body Harness (Fall Arrest System) that meets • Inspect cables and cable ends for damage or kinking.
  • Page 5 Operator's Manual Rivers Edge® One-Man Ladder Stands ASSEMBLY INSTRUCTIONS (RE622) WARNING Tools needed – two 7/16" wrenches FOOT PLATFORM AND SITTING SECTION MUST ALWAYS IMPORTANT ASSEMBLY TIP: DO NOT TIGHTEN NUT& BOLT COMBINATIONS FACE THE SAME DIRECTION, TOWARDS THE TREE. COMPLETELY UNTIL ALL PARTS ARE ASSEMBLED TOGETHER! FINGER TIGHT- EN PLUS ONE TURN OF A WRENCH ONLY! THIS WILL TEMPORARILY HOLD THE LOCK NUT ON THE BOLT WHILE HELPING ALIGNMENT OF ALL PARTS! AFTER...
  • Page 6 Operator's Manual Rivers Edge® One-Man Ladder Stands 6. With all sections assembled together on ground, secure all sections together using (8) provided spring lock pins. Handle of spring lock pin must be put to the outside of ladder side rails. SEE FIGURE 3. 7. a. Attach the stabilizer bar extension tube (1ML23) to the third ladder section mounting bracket using (1) provided spring lock pin.
  • Page 7 Operator's Manual Rivers Edge® One-Man Ladder Stands RE622 BACKPACKING STRAP ATTACHMENT INSTRUCTIONS 1. Stack metal components of the ladder AS SHOWN IN FIGURE 1A AND 1B. 2. Lay stabilizer with extension tube along side of stacked ladder. Wrap the provided ladder ratchet strap around the stacked frame. Hook the two “S”-hooks together and ratchet tight. This will se- curely hold all ladder components together.
  • Page 8 Operator's Manual Rivers Edge® One-Man Ladder Stands FINISHED PACK-N-STACK™ LADDER top section ratchet strap fourth section 15' tie-off ropes third section 9' stabilizer bar rope stabilizer bar extension tube second section spring lock pins bottom section Check for parts online at www.HuntRiversEdge.com or call 800-450-EDGE (3343) M-F 8-5...
  • Page 9 Operator's Manual Rivers Edge® One-Man Ladder Stands LADDER PARTS (RE622) NO EXTENSIONS AVAILABLE FOR THIS MODEL. NEVER MODIFY OR EXCEED ORIGINAL STATED USE HEIGHT! LADDER PARTS LIST (RE622) KEY # PART # DESCRIPTION QTY. 48240B BOLT, HHCS GR5 BLK 1/4-20 X 1-1/2" 48271B BOLT, HHCS GR5 BLK 1/4-20 X 2-1/4" 48752B NUT, FLANGED NYLOCK 1/4-20 63281 SNAP PIN, 1/4 X 1-3/4, ROUNDED RETAINER...
  • Page 10 Operator's Manual Rivers Edge® One-Man Ladder Stands ASSEMBLY INSTRUCTIONS (RE627) Tools needed – two 7/16” wrenches, one 9/16" wrench IMPORTANT ASSEMBLY TIP: Do not tighten any nut and bolt combinations completely until all parts are assembled together! Finger tighten plus one turn of a wrench only! This will temporarily hold the lock nut on the bolt while front platform helping alignment of all parts! After all parts are assembled together, all nut...
  • Page 11 Operator's Manual Rivers Edge® One-Man Ladder Stands 4. Attach the front of the ladder side rails (410053) to the front plat- form using (2) provided 1/4-20 x 2” bolts (2), locknuts (4) and steel washers. SEE FIGURE 3. ladder side rails tree blade 5.

  • Page 12: Seat Assembly

    Operator's Manual Rivers Edge® One-Man Ladder Stands SEAT ASSEMBLY 8. a. Position the factory assembled mesh seat (360018) upside down Bolt will enter on a sturdy, hard surface. SEE FIGURE 6. at an angle. b. Insert (1) 1/4-20 x 2-3/4” bolt through the rear fixed brace (410122) and side rail of mesh seat.
  • Page 13 Operator's Manual Rivers Edge® One-Man Ladder Stands SEAT ASSEMBLY CONTINUED e. Remove the factory installed "locking" bolt and locknut from the front hinged brace (410112), and set aside. Hinge the brace slightly to aid in assembly. SEE FIGURE 10. f. Insert (2) 1/4-20 x 1-1/4" bolts through the front hinged brace and each side rail, and finger tighten locknuts.
  • Page 14 Operator's Manual Rivers Edge® One-Man Ladder Stands 9. Remove the locknuts from the (2) 1/4-20 x 2-1/4” bolts that were previ- 1/4-20 x 1-1/4" bolt ously attached to the rear of the seat assembly. Continue by attaching the seat assembly to the ladder side rails using (2) provided 1/4-20 x shooting 2-1/4”...
  • Page 15 Operator's Manual Rivers Edge® One-Man Ladder Stands 14. Thread the non-locking 3/8-16 nut onto the threaded end of spacer rod all the way to the bottom of threads and slide 3/8” lock washer on. Insert the threaded end of spacer rod through either backrest mount tube far enough to be able to insert the opposite end of spacer rod (end with welded-on washer) into opposite backrest mount tube.
  • Page 16 Operator's Manual Rivers Edge® One-Man Ladder Stands 19. a. Attach the stabilizer bar extension tube (1ML23) to the second ladder section mounting bracket using (1) provided spring lock pin. SEE FIGURE 22. b. Slide the stabilizer bar (L17) into the extension tube and attach the two pieces together using (1) provided spring lock pin.
  • Page 17 Operator's Manual Rivers Edge® One-Man Ladder Stands Finished Oasis™ Ladder ratchet strap top section 15' tie-off ropes third section 9' stabilizer bar rope second section stabilizer bar stabilizer bar extension tube spring lock pins bottom section Check for parts online at www.HuntRiversEdge.com or call 800-450-EDGE (3343) M-F 8-5...
  • Page 18 Operator's Manual Rivers Edge® One-Man Ladder Stands RE627 PARTS EXPLOSION Check for parts online at www.HuntRiversEdge.com or call 800-450-EDGE (3343) M-F 8-5...
  • Page 19 Operator's Manual Rivers Edge® One-Man Ladder Stands RE627 PARTS LIST NO EXTENSIONS AVAILABLE FOR THIS MODEL. NEVER MODIFY OR EXCEED ORIGINAL STATED USE HEIGHT! KEY # PART # DESCRIPTION KEY # PART # DESCRIPTION QTY. 48153B BOLT 1/4-20 X 2 HHCS GR5 BLK ZN 10347 SPACER NYLON 1/4 X 1 X 1/2 48240B BOLT 1/4-20 X 1-1/2 HHCS GR5 BLK ZN 1ML23 TUBE, STABILIZER, SUPPORT...
  • Page 20 Operator's Manual Rivers Edge® One-Man Ladder Stands ASSEMBLY INSTRUCTIONS (RE628) Tools needed – two 7/16” wrenches, one 9/16" wrench IMPORTANT ASSEMBLY TIP: Do not tighten any nut and bolt combinations completely until all parts are assembled together! Finger tighten plus one turn of a wrench only! This will temporarily hold the lock nut on the bolt front platform while helping alignment of all parts! After all parts are assembled together,...
  • Page 21 Operator's Manual Rivers Edge® One-Man Ladder Stands 4. Attach the front of the ladder side rails (410053) to the front plat- form using (2) provided 1/4-20 x 2” bolts (2), locknuts (4) and steel washers. SEE FIGURE 3. ladder side rails 5.
  • Page 22 Operator's Manual Rivers Edge® One-Man Ladder Stands SEAT ASSEMBLY 8. a. Position the factory assembled mesh seat (360019) upside down Bolt will enter on a sturdy, hard surface. SEE FIGURE 6. at an angle. b. Insert (1) 1/4-20 x 2-3/4” bolt through the rear fixed brace (410127) and side rail of mesh seat.
  • Page 23 Operator's Manual Rivers Edge® One-Man Ladder Stands SEAT ASSEMBLY CONTINUED e. Remove the factory installed "locking" bolt and locknut from the front hinged brace (410115), and set aside. Hinge the brace slightly to aid in assembly. SEE FIGURE 10. f. Insert (2) 1/4-20 x 1-1/4" bolts through the front hinged brace and each side rail, and finger tighten locknuts.
  • Page 24 Operator's Manual Rivers Edge® One-Man Ladder Stands 9. Remove the locknuts from the (2) 1/4-20 x 2-1/4” bolts that were previ- 1/4-20 x 1-1/4" ously attached to the rear of the seat assembly. Continue by attaching bolts the seat assembly to the ladder side rails using (2) provided 1/4-20 x 2-1/4” bolts, locknuts and nylon washers. SEE FIGURE 15. Make sure all (4) angle brackets are fully cradling fabric rails.
  • Page 25 Operator's Manual Rivers Edge® One-Man Ladder Stands 15. Sections are assembled on the ground in the following order; bot- tom section (410066 3-step ladder); second section (410068 3-step ladder with stabilizer bar mount); third section (410069 3-step ladder w/ mounting holes); top section (assembled top platform section).
  • Page 26 Operator's Manual Rivers Edge® One-Man Ladder Stands 19. a. Attach the stabilizer bar extension tube (1ML23) to the second ladder section mounting bracket using (1) provided spring lock pin. SEE FIGURE 22. b. Slide the stabilizer bar (L17) into the extension tube and attach the two pieces together using (1) provided spring lock pin.
  • Page 27 Operator's Manual Rivers Edge® One-Man Ladder Stands Finished Jumbo Jack™ Ladder ratchet strap section tie-off ropes third 9' stabilizer section bar rope second section stabilizer spring lock pins stabilizer bar extension tube bottom section Check for parts online at www.HuntRiversEdge.com or call 800-450-EDGE (3343) M-F 8-5...
  • Page 28 Operator's Manual Rivers Edge® One-Man Ladder Stands RE628 PARTS EXPLOSION 27 30 27 30 Check for parts online at www.HuntRiversEdge.com or call 800-450-EDGE (3343) M-F 8-5...
  • Page 29 Operator's Manual Rivers Edge® One-Man Ladder Stands RE628 PARTS LIST NO EXTENSIONS AVAILABLE FOR THIS MODEL. NEVER MODIFY OR EXCEED ORIGINAL STATED USE HEIGHT! KEY # PART # DESCRIPTION QTY. KEY # PART # DESCRIPTION QTY. 48153B BOLT 1/4-20 X 2 HHCS GR5 BLK ZN 10347 SPACER NYLON 1/4 X 1 X 1/2 48240B BOLT 1/4-20 X 1-1/2 HHCS GR5 BLK ZN 1ML23...
  • Page 30 Operator's Manual Rivers Edge® One-Man Ladder Stands ASSEMBLY INSTRUCTIONS (RE631) Tools needed – two 7/16” wrenches, Phillips screw driver IMPORTANT ASSEMBLY TIP: Do not tighten any nut and bolt combinations completely until all parts are assembled together! Finger tighten plus one turn of a wrench only! This will temporarily hold the lock nut on the bolt while helping alignment of all parts! After all parts are assembled together, all nut main ladder...
  • Page 31 Operator's Manual Rivers Edge® One-Man Ladder Stands 5. Attach the round tube, double flat braces (10377) to the upper lad- der support tubes using (4) provided 1/4-20 x 1-1/2” bolts and lock- nuts. SEE FIGURE 4. One double flat brace should be positioned on 1/4-20 x 1-3/4"...
  • Page 32 Operator's Manual Rivers Edge® One-Man Ladder Stands 10. Sections are assembled on the ground in the following order; bottom section (410044 base extension); second section (10468 shooting rail posts 3-step ladder); third section (10470 3-step ladder w/ stabilizer bar mount); fourth section (10468 3-step ladder); top section (assem- bled top platform section).
  • Page 33 Operator's Manual Rivers Edge® One-Man Ladder Stands Finished Relax™ Wide Ladder ratchet strap top section 15' tie-off ropes fourth section 9' stabilizer bar rope stabilizer bar spring lock pins stabilizer bar third section extension tube second section bottom section Check for parts online at www.HuntRiversEdge.com or call 800-450-EDGE (3343) M-F 8-5...
  • Page 34 Operator's Manual Rivers Edge® One-Man Ladder Stands RE631 PARTS EXPLOSION Check for parts online at www.HuntRiversEdge.com or call 800-450-EDGE (3343) M-F 8-5...
  • Page 35 Operator's Manual Rivers Edge® One-Man Ladder Stands RE631 PARTS LIST NO EXTENSIONS AVAILABLE FOR THIS MODEL. NEVER MODIFY OR EXCEED ORIGINAL STATED USE HEIGHT! KEY # PART # DESCRIPTION QTY. ITEMS NOT SHOWN 48415 RATCHET STRAP 10336 TUBE BRACE UPPER LADDER SUPPORT 10531 FULL BODY HARNESS (FAS) 10346 TUBE RAIL SIDE LADDER 48736 CAMO SLEEVE W/FOAM 9"...

  • Page 36: Setup And Use Instructions

    Operator's Manual Rivers Edge® One-Man Ladder Stands SETUP AND USE INSTRUCTIONS WARNING (FOR ALL LADDERS INCLUDED IN THIS MANUAL) DOUBLE CHECK ASSEMBLY STEPS TO BE CERTAIN YOU HAVE CORRECTLY ASSEMBLED THIS PRODUCT. During installation and removal of ladder treestands, you must always STUDY YOUR NEW STAND TO BECOME FAMILIAR WITH ALL and properly use the included Full Body Harness (Fall Arrest System).
  • Page 37 Operator's Manual Rivers Edge® One-Man Ladder Stands 3. With two people securely holding the ladder, use the three point WARNING contact climbing method to slowly climb the ladder and carefully keep a constant hand grip on the ladder at all times. Always lean BE CERTAIN TO ALWAYS LEAN FORWARD, TOWARD THE TREE forward, toward tree, to keep top section tree blades against the WHEN ASCENDING OR DESCENDING LADDER.

  • Page 38: Bolt Identification Chart

    Operator's Manual Rivers Edge® One-Man Ladder Stands BOLT IDENTIFICATION CHART Not all bolt sizes shown are included with all treestands. Bolts shown are for size reference only. Extra hardware may be included in the parts bag. 5/16-18 x 1-3/4" grade 5 hex head bolt 1/4-20 x 1-1/4"...
  • Page 39 Operator's Manual Rivers Edge® One-Man Ladder Stands NOTES Check for parts online at www.HuntRiversEdge.com or call 800-450-EDGE (3343) M-F 8-5...
  • Page 40 Rivers Edge® Treestands, Inc. 1160 Eighth Avenue, PO Box 755 Cumberland, WI 54829 800-450-EDGE (3343) | Fax 715-822-2124 Email: info@huntriversedge.com *All weights, specifications and features are approximate and are subject to change without notice. Due to continuous product improvements, product images may not be exact. Warning labels in some product images may have been removed for photography purposes only.

This manual is also suitable for:

Pack-n-stack re622Jumbo jack re628
