ASSEMBL Y INSTRUCTIONS
20
CE3
-
Electronic Ignition Assembly:
The electrode set for main burner (CF), side stove (DF) and Instastart button (CE3) are
found under the control panel (CI) attached to the manifold (CA). Insert the electrode sets
into the electronic ignition (CE1)
(CE3)
InstaStart
Button
CE1
CE2
+
CE2
23
CE1
DF
CF
